Part Number:
7713A
VideoFLEX® Snake, RG6, #18-10 Coax, CMR
Product Description
VideoFLEX® Digital Coax Snake Cable, Riser-CMR, 10-RG6 18 AWG, solid bare copper conductors, foam HDPE core, Duofoil® +95% tinned copper braid,
PVC jacket
Technical Specifications
Product Overview
Environmental Space:
Suitable Applications:
Physical Characteristics (Overall)
Conductor
AWG
18
Indoor/Outdoor
SMPTE 2081-1 6 Gb/s UHDTV, SMPTE 424M 3 Gb/s HD-SDI 1080p, SDI/HDTV Digital Video, High Definition (HD),
Standard Definition (SDI)
Material
Nominal Diameter No. of Coax
10
BC - Bare Copper 0.04 in
Total Number of Conductors:
Insulation
Material
10
Nominal Diameter
Gas-injected FHDPE - Foam High Density Polyethylene 0.18 in
Color Chart
Number Color
1
2
3
4
5
6
7
8
9
10
White
Black
Brown
Red
Orange
Yellow
Green
Blue
Purple
Gray
Inner Shield Material
Type Layer
Tape
Braid
1
2
Material
TC - Tinned Copper
Material Trade Name Coverage [%]
100 %
95 %
Aluminum Foil-Polyester Tape-Aluminum Foil Duofoil®
Inner Jacket Material
Material
Nominal Diameter
PVC - Polyvinyl Chloride 0.275 in
Outer Jacket Material
Material
Nominal Diameter
PVC - Polyvinyl Chloride 1.386 in
Electrical Characteristics
Capacitance
Nom. Capacitance Conductor to Shield
16.3 pF/ft
Conductor DCR
Nominal Conductor DCR Nominal Conductor DCR Conductor Resistance Nominal Inner Shield DCR Outer Conductor DCR
6.4 Ohm/1000ft
6.4 Ohm/1000ft
3 Ohm/1000ft
3.0 Ohm/1000ft
Impedance
Nominal Characteristic Impedance
75 Ohm
Return Loss
Frequency [MHz] Min. Structural Return Loss (SRL)
5-1600 MHz
1600-4500 MHz
4500-6000 MHz
23 dB
21 dB
15 dB
High Frequency (Nominal/Typical)
Frequency [MHz] Nom. Insertion Loss
1 MHz
3.58 MHz
5 MHz
7 MHz
10 MHz
67.5 MHz
71.5 MHz
88.5 MHz
100 MHz
135 MHz
143 MHz
180 MHz
270 MHz
360 MHz
540 MHz
720 MHz
750 MHz
1000 MHz
1500 MHz
2000 MHz
2250 MHz
3000 MHz
4500 MHz
6000 MHz
0.24 dB/100ft
0.44 dB/100ft
0.52 dB/100ft
0.61 dB/100ft
0.71 dB/100ft
1.65 dB/100ft
1.69 dB/100ft
1.86 dB/100ft
1.95 dB/100ft
2.24 dB/100ft
2.3 dB/100ft
2.57 dB/100ft
3.17 dB/100ft
3.69 dB/100ft
4.6 dB/100ft
5.38 dB/100ft
5.5 dB/100ft
6.42 dB/100ft
7.99 dB/100ft
9.37 dB/100ft
10.01 dB/100ft
11.78 dB/100ft
14.7 dB/100ft
17.7 dB/100ft
Delay
Nominal Delay Nominal Velocity of Propagation (VP) [%]
1.24 ns/ft
82 %
High Freq
Frequency [MHz]
2250 MHz
3000 MHz
4500 MHz
6000 MHz
Voltage
UL Voltage Rating
300 V RMS
Temperature Range
Non-UL Temp Rating:
UL Temp Rating:
Operating Temp Range:
Mechanical Characteristics
Bulk Cable Weight:
786(lbs/1000ft)
75°C
60°C
-40°C To +75°C
Max Recommended Pulling Tension: 690(lbs)
Min Bend Radius/Minor Axis:
Standards
NEC/(UL) Specification:
CEC/C(UL) Specification:
UL AWM Style:
RG Type:
Series Type:
CMR
CMG
UL Style 1354 (each coax); UL Style 2688 (overall)
RG-6/U Type
Series 6
14(in)
Applicable Environmental and Other Programs
EU Directive 2000/53/EC (ELV):
EU Directive 2003/11/EC (BFR):
EU Directive 2011/65/EU (ROHS II):
EU Directive 2012/19/EU (WEEE):
EU Directive 2015/863/EU:
EU Directive Compliance:
EU CE Mark:
EU RoHS Compliance Date
(yyyy-mm-dd):
CA Prop 65 (CJ for Wire & Cable):
MII Order #39 (China RoHS):
Suitability
Suitability - Aerial:
Suitability - Burial:
Suitability - Indoor:
Suitability - Outdoor:
Flammability, LS0H, Toxicity Testing
UL Flammability:
CSA Flammability:
Part Number
Plenum (Y/N):
Suggested Connectors:
© 2018 Belden, Inc
All Rights Reserved.
Although Belden makes every reasonable effort to ensure their accuracy at the time of this publication, information and specifications described here in are subject to error or omission and to change without
notice, and the listing of such information and specifications does not ensure product availability.
Belden provides the information and specifications herein on an "ASIS" basis, with no representations or warranties, whether express, statutory or implied. In no event will Belden be liable for any damages
(including consequential, indirect, incidental, special, punitive, or exemplary damages) whatsoever, even if Belden has been advised of the possibility of such damages, whether in an action under contract,
negligence or any other theory, arising out of or in connection with the use, or inability to use, the information or specifications described herein.
All sales of Belden products are subject to Belden's standard terms and conditions of sale.
Belden believes this product to be incompliance with EU RoHS(Directive 2002/95/EC, 27-Jan-2003). Material manufactured prior to the compliance date may be instock at Belden facilities and in our Distributor's
inventory. The information provided in this Product Disclosure, and the identification of materials listed as reportable or restricted within the Product Disclosure, is correct to the best of Belden's knowledge,
information, and belief at the date of its publication. The information provided in this Product Disclosure is designed only as a general guide for the safe handling, storage, and any other operation of the product
itself or the one that it becomes a part of. This Product Disclosure is not to be considered a warranty or quality specification. Regulatory information is for guidance purposes only. Product users are responsible for
determining the applicability of legislation and regulations based on their individual usage of the product.
Yes
Yes
Yes
Yes
Yes
EU Directive 2003/11/EC (BFR)
No
2004-01-01
Yes
Yes
Yes - Black only, when supported by messenger wire
No
Yes
Yes - Black only
UL1666 Vertical Shaft
FT4
No
Kings 2065-10-9 75 Ohm BNC, each coax
