BZX84C2V4
THRU
BZX84C47
SURFACE MOUNT
SILICON ZENER DIODE
350mW, 2.4 THRU 47 VOLTS
w w w. c e n t r a l s e m i . c o m
DESCRIPTION:
The CENTRAL SEMICONDUCTOR BZX84C2V4
Series are surface mount silicon Zener diodes. These
high quality voltage regulating diodes are designed
for use in industrial, commercial, entertainment and
computer applications.
MARKING CODE: SEE ELECTRICAL
CHARACTERISTICS TABLE
SOT-23 CASE
MAXIMUM RATINGS:
(TA=25°C)
Power Dissipation
Operating and Storage Junction Temperature
Thermal Resistance
SYMBOL
PD
TJ, Tstg
Θ
JA
UNITS
mW
°C
°C/W
350
-65 to +150
357
ELECTRICAL CHARACTERISTICS:
(TA=25°C), VF=0.9V MAX @ IF=10mA (for all types)
ZENER
VOLTAGE
VZ @ IZT
MIN
V
BZX84C2V4
BZX84C2V7
BZX84C3V0
BZX84C3V3
BZX84C3V6
BZX84C3V9
BZX84C4V3
BZX84C4V7
BZX84C5V1
BZX84C5V6
BZX84C6V2
BZX84C6V8
BZX84C7V5
BZX84C8V2
BZX84C9V1
BZX84C10
2.2
2.5
2.8
3.1
3.4
3.7
4.0
4.4
4.8
5.2
5.8
6.4
7.0
7.7
8.5
9.4
NOM
V
2.4
2.7
3.0
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
MAX
V
2.6
2.9
3.2
3.5
3.8
4.1
4.6
5.0
5.4
6.0
6.6
7.2
7.9
8.7
9.6
10.6
TEST
CURRENT
IZT
mA
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
5.0
MAXIMUM
ZENER
IMPEDENCE
ZZT @ IZT
Ω
100
100
95
95
90
90
90
80
60
40
10
15
15
15
15
20
ZZK @ IZK
Ω
mA
600
600
600
600
600
600
600
500
480
400
150
80
80
80
100
150
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
MAXIMUM
REVERSE
CURRENT
IR @
μA
50
20
10
5.0
5.0
3.0
3.0
3.0
2.0
1.0
3.0
2.0
1.0
0.7
0.5
0.2
VR
V
1.0
1.0
1.0
1.0
1.0
1.0
1.0
2.0
2.0
2.0
4.0
4.0
5.0
5.0
6.0
7.0
MAXIMUM
MAXIMUM
ZENER
ZENER
VOLTAGE
TEMP.
CURRENT
COEFF.
IZM
ΘV
Z
mA
104
92
83
76
69
64
58
53
49
45
40
37
33
30
27
25
% / °C
-0.06
-0.06
-0.06
-0.06
-0.06
-0.06
-0.05
-0.03
0.02
0.03
0.04
0.05
0.05
0.06
0.06
0.07
W3
W4
W5
W6
W7
W8
W9
Z1
Z2
Z3
Z4
Z5
Z6
Z7
Z8
Z9
TYPE
MARKING
CODE
Tolerance Code
A
B
Tolerance
±1%
±2%
Part Number Identification
B Z X 84 C 4V 7
Nominal Value Code(i.e. 4.7 Volts)
Tolerance Code
Device Series
R7 (20-November 2009)
OUTSTANDING SUPPORT AND SUPERIOR SERVICES
PRODUCT SUPPORT
Central’s operations team provides the highest level of support to insure product is delivered on-time.
• Supply management (Customer portals)
• Custom bar coding for shipments
• Inventory bonding
• Custom product packing
• Consolidated shipping options
DESIGNER SUPPORT/SERVICES
Central’s applications engineering team is ready to discuss your design challenges. Just ask.
• Free quick ship samples (2
nd
day air)
• Special wafer diffusions
• Online technical data and parametric search
• PbSn plating options
• SPICE models
• Package details
• Custom electrical curves
• Application notes
• Environmental regulation compliance
• Application and design sample kits
• Customer specific screening
• Custom product and package development
• Up-screening capabilities
REQUESTING PRODUCT PLATING
1.
2.
If requesting Tin/Lead plated devices, add the suffix “ TIN/LEAD” to the part number when
ordering (example: 2N2222A TIN/LEAD).
If requesting Lead (Pb) Free plated devices, add the suffix “ PBFREE” to the part number
when ordering (example: 2N2222A PBFREE).
