Product is End of Life Mar-2016 and Replaced by FSE
HLZ
www.vishay.com
Vishay Dale
Wirewound Resistors, Industrial Power, Edgewound
FEATURES
• High temperature silicon coating
• Complete welded construction
• Excellent for intermittent power and pulsing
applications
• Designed to meet heavy-duty requirement
where space is at a premium
• Excellent stability in operation (< 3 % change
in resistance)
• Material categorization:
for definitions of compliance please see
www.vishay.com/doc?99912
Available
Available
Available
Note
*
This datasheet provides information about parts that are
RoHS-compliant and / or parts that are non-RoHS-compliant. For
example, parts with lead (Pb) terminations are not RoHS-compliant.
Please see the information / tables in this datasheet for details.
Available
STANDARD ELECTRICAL SPECIFICATIONS
GLOBAL
MODEL
HLZ033
HLZ090
HLZ099
HLZ105
HLZ110
HLZ140
HLZ165
HLZ220
HLZ240
HLZ275
HLZ300
HLZ375
HISTORICAL
MODEL
HLZ-33
HLZ-90
HLZ-99
HLZ-105
HLZ-110
HLZ-140
HLZ-165
HLZ-220
HLZ-240
HLZ-275
HLZ-300
HLZ-375
POWER RATING
P
25 °C
W
35
90
100
105
110
140
165
220
240
275
300
375
RESISTANCE RANGE
0.05 to 1.9
0.10 to 5.7
0.15 to 6.1
0.20 to 7.4
0.20 to 8.6
0.08 to 9.0
0.35 to 13.0
0.10 to 16.0
0.10 to 18.0
0.15 to 23.0
0.15 to 25.0
0.20 to 32.0
TOLERANCE
±%
5, 10
5, 10
5, 10
5, 10
5, 10
5, 10
5, 10
5, 10
5, 10
5, 10
5, 10
5, 10
WEIGHT
(typical)
g
18
36
41
49
54
109
91
163
186
224
236
286
TECHNICAL SPECIFICATIONS
PARAMETER
Temperature Coefficient
Short Time Overload
Terminal Strength
Dielectric Withstanding Voltage
Maximum Working Voltage
Insulation Resistance
Operating Temperature Range
UNIT
ppm/°C
-
lb
V
AC
V
°C
HLZ RESISTOR CHARACTERISTICS
± 30 for 10
and above; ± 50 for 1
to 9.9
;
± 90 for 0.1
to 0.99
10 x rated power for 5 s
10 minimum
1000,
from terminal to mounting hardware
(P x
R)
1/2
1000 M minimum dry, 100 M minimum after moisture test
-55 to +350
GLOBAL PART NUMBER INFORMATION
Global Part Numbering example: HLZ16506Z10R00KJ
H
GLOBAL
MODEL
L
Z
1
6
5
0
6
Z
1
0
R
0
0
K
J
SPECIAL
(dash number)
(up to 2 digits)
from
1 to 99
as applicable
TERMINAL
DESIGNATION
06
07
15
TERMINAL
FINISH
E
= lead
(Pb)-free
RESISTANCE
VALUE
TOLERANCE
J
= ± 5.0 %
K
= ± 10.0 %
Note
PACKAGING CODE
E
= lead (Pb)-free skin pack
J
(1)
= skin pack (J01)
HLZ165
(see “Standard
Electrical
Specifications”
table above for
additional P/N’s)
R
= decimal
K
= thousand
10R00
= 10.0
Z
= tin / lead
1K000
= 1 k
N
= nickel
(1)
Tin / lead for type “Z”, lead (Pb)-free for type “N”
Historical Part Numbering example: HLZ-165-06Z 10
10 % J01
HLZ-165
06Z
10
HISTORICAL MODEL
Revision: 26-Feb-16
TERMINAL/FINISH
RESISTANCE VALUE
10 %
TOLERANCE
J01
PACKAGING
Document Number: 30245
1
For technical questions, contact:
ww2dresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
Product is End of Life Mar-2016 and Replaced by FSE
HLZ
www.vishay.com
DIMENSIONS
in inches [millimeters]
TERMINAL SETBACK
Vishay Dale
A
O.D.
I.D.
LENGTH
CORE DIMENSIONS
MODEL
LENGTH
± 0.062
[± 1.59]
2.000 [50.8]
4.000 [101.6]
3.500 [88.9]
4.000 [101.6]
4.500 [114.3]
4.000 [101.6]
6.500 [165.1]
6.000 [152.4]
6.500 [165.1]
8.000 [203.2]
8.500 [215.9]
10.500 [266.7]
O.D.
0.563 [14.29]
0.563 [14.29]
0.750 [19.05]
0.750 [19.05]
0.750 [19.05]
1.125 [28.58]
0.750 [19.05]
1.125 [28.58]
1.125 [28.58]
1.125 [28.58]
1.125 [28.58]
1.125 [28.58]
I.D.
± 0.031
[± 0.79]
0.313 [7.94]
0.313 [7.94]
0.500 [12.70]
0.500 [12.70]
0.500 [12.70]
0.750 [19.05]
0.750 [19.05]
0.750 [19.05]
0.750 [19.05]
0.750 [19.05]
0.750 [19.05]
0.750 [19.05]
TERMINAL
SETBACK
± 0.031
[± 0.79]
0.094 [2.38]
0.094 [2.38]
0.125 [3.18]
0.125 [3.18]
0.125 [3.18]
0.219 [5.56]
0.125 [3.18]
0.219 [5.56]
0.219 [5.56]
0.219 [5.56]
0.219 [5.56]
0.219 [5.56]
DISTANCE
BETWEEN
TERMINALS
(REF.)
1.437
3.312
2.75
3.25
3.75
2.812
5.75
4.812
5.312
6.812
7.312
9.312
TERMINAL DESIGNATION
STANDARD
06Z
06Z
06Z
06Z
06Z
07Z
06Z
07Z
07Z
07Z
07Z
07Z
OPTIONAL
15N
15N
15N
15N
15N
15N
15N
15N
15N
15N
15N
15N
BRACKET
TYPE
(1)
101, 203, 301
101, 203, 301
102, 206, 303
102, 206, 303
102, 206, 303
103, 205, 303
102, 206, 303
103, 205, 303
103, 205, 303
103, 205, 303
103, 205, 303
103, 205, 303
HLZ033
HLZ090
HLZ099
HLZ105
HLZ110
HLZ140
HLZ165
HLZ220
HLZ240
HLZ275
HLZ300
HLZ375
Note
(1)
Brackets are available for mounting HLZ series resistors - see “Mounting Hardware” section.
TERMINAL DIMENSIONS
DIMENSION
A
C
Style 06
and 07
B
D
A
C
Style 15
D
B
A
B
C
D
06
0.250 [6.35]
0.563 [14.29]
0.166 [4.22]
0.020 [0.51]
TERMINAL STYLE
07
15
0.375 [9.53]
0.250 [6.35]
0.625 [15.88]
0.594 [15.08]
0.173 [4.39]
0.065 [1.65]
0.020 [0.51]
0.031 [0.79]
TERMINAL FINISH
MATERIAL SPECIFICATIONS
Element:
copper-nickel alloy of nickel-chrome alloy,
depending on resistance range
Core:
ceramic, steatite
Coating:
special high temperature silicone
Standard Terminals:
model “E” terminals are tinned steel
Terminal Bands:
steel
Part Marking:
Vishay Dale, model, wattage, value,
tolerance, date code
“E” finish - 100 % Sn coated steel. “Z” finish - 60/40 Sn/Pb
coated steel. “N” finish - nickel coated steel. Finish for
terminal style 14 and 15 are limited to nickel plated steel (N).
RATED POWER IN %
120
100
80
60
40
20
0
- 65
0
25
Derating
MOUNTING HARDWARE
50
150
250
350
AMBIENT TEMPERATURE IN °C
Mounting Hardware is available for HLZ resistors, see HL Brackets and Sliders datasheet for more information:
www.vishay.com/doc?30279
Revision: 26-Feb-16
Document Number: 30245
2
For technical questions, contact:
ww2dresistors@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
