19-1864; Rev 0; 11/00
MAX1817 Evaluation Kit
General Description
The MAX1817 evaluation kit (EV kit) is a fully assembled
and tested surface-mount circuit board that demon-
strates the MAX1817 dual-output, step-up DC-DC con-
verter. The main output is configured for +3.3V and pro-
vides up to 125mA of current. The LCD bias output is
configured for +18.0V and provides up to 10mA. The
EV kit can support the dual output with a +1.5V to
+3.3V input voltage range.
o
Dual Output Voltages
+3.3V Main Output
+18V LCD Bias Output
o
Adjustable Output Voltages
o
125mA Available from the Main Output
o
10mA Available from the LCD Bias Output
o
Input Voltage as Low as +1.5V
o
Low 15µA Quiescent Supply Current
o
Surface-Mount Construction
Features
Evaluates: MAX1817
Component List
DESIGNATION
QTY
DESCRIPTION
10µF, 6.3V, X5R ceramic
capacitor (1206)
Taiyo Yuden JMK316BJ106ML or
TDK C3216X5R0J106KT
1µF, 35V, X7R ceramic
capacitor (1206)
Taiyo Yuden GMK316BJ105ML or
equivalent
22µF, 6.3V, X5R ceramic
capacitor (1210)
Taiyo Yuden JMK325BJ226MM
5.0pF, 50V ceramic capacitor (0603)
Murata GRM39COG050B050 or
Taiyo Yuden UMK107CH050CZ
Not installed (0603)
1MΩ
±1%
resistor (0805)
75kΩ
±1%
resistor (0805)
Not installed (0805)
200mA, 75V junction diode (SOT-23)
Central Semiconductor CMPD4448
0.5A, 30V Schottky diode (SOD-123)
Nihon EP05Q03L
10µH, 1A inductors
Sumida CR43-100MC
MAX1817EUB (10-pin
µMAX)
3-pin headers
Shunts (JU1, JU2)
MAX1817 PC board
MAX1817 data sheet
MAX1817 EV kit data sheet
o
Fully Assembled and Tested
Ordering Information
PART
MAX1817EVKIT
TEMP. RANGE
0°C to +70°C
IC PACKAGE
10 µMAX
C1
1
Component Suppliers
SUPPLIER
Central Semiconductor
Murata
Nihon
Sumida
Taiyo Yuden
TDK
PHONE
631-435-1110
814-237-1431
661-867-2555
847-956-0666
408-573-4150
847-803-6100
FAX
631-435-3388
814-238-0490
661-867-2698
847-956-0702
408-573-4159
847-803-6296
C2
1
C3
1
C4
C5, C6
R1
R2
R3, R4
D1
D2
L1, L2
U1
JU1, JU2
None
None
None
None
1
0
1
1
0
1
1
2
1
2
2
1
1
1
Note:
Please indicate that you are using the MAX1817 when
contacting these component suppliers.
Quick Start
The MAX1817 EV kit is a fully assembled and tested
surface-mount board. Follow the steps below for board
operation.
Do not turn on the power supply until all
connections are completed.
1) Verify that shunts are across pins 1 and 2 of
jumpers JU1 and JU2 to enable the main output
and the LCD output, respectively.
2) Connect a voltmeter across the VOM pad and the
nearest GND pad to monitor the main output voltage.
3) Connect a voltmeter across the VOLCD pad and
the nearest GND pad to monitor the LCD output
voltage.
4) Connect a +1.5V to +3.3V supply to the VBATT
pad. Connect the ground to the GND pad.
5) Turn on the power supply and verify that the main
output VOM is at +3.3V and the VOLCD output is at
+18.0V.
1
________________________________________________________________
Maxim Integrated Products
For price, delivery, and to place orders, please contact Maxim Distribution at 1-888-629-4642,
or visit Maxim’s website at www.maxim-ic.com.
