Preliminary
"High Frequency Ceramic Solutions"
P/N 5400BL14A0200
Page 1 of 2
Phase Difference
5400BL14A0200
4900~5950
50
Ω
200
Ω
1.2 dB max.
9.5 dB min.
Bulk
T&R
100% Tin
Suffix = S
Suffix = T
Suffix = None
Amplitude Difference
Operating Temperature
Storage Temperature
Reel Quanity
Power Capacity
Eg. 5400BL14A0200S
Eg. 5400BL14A0200T
Eg. 5400BL14A0200(T or S)
180° ± 10
1.5 dB max.
-40 to +85°C
+5 ~ +35 °C, Humidity
45~75%RH, 18 mos. max
4,000
0.5 watts max.
5.4GHz 50:200Ω Balun
Detail Specification: 12/14/10
General Specifications
Part Number
Frequency (MHz)
Unbalanced Impedence
Balanced Impedence (diff.)
Insertion Loss
Return Loss
Packaging
Style
Termination Style
Evaluation Board
P/N
Suffix
Terminal Configuration
No.
1
3
Function
Unbalanced Port (IN)
Balanced Port (OUT1)
Balanced Port (OUT2)
GND
NC
3
2
1
5400BL140200-EB1SMA
2
GND or DC feed + RF GND
Mechanical Dimensions
In
L
W
T
a
b
c
g
p
0.063 ± 0.004
0.031 ± 0.004
0.024 ± 0.004
0.008 ± 0.004
0.008 +.004/-.006
0.006 ± 0.004
0.012 ± 0.004
0.020 ± 0.002
mm
1.60 ± 0.10
0.80 ± 0.10
0.60 ± 0.10
0.20 ± 0.10
0.20 +0.1/-0.15
0.15 ± 0.10
0.30 ± 0.10
0.50 ± 0.05
g
b
T
L
W
4
5
6
c
a
p
4
5
6
Mounting Considerations
Mount these devices with brown mark facing up.
*
Line width should be designed to provide proper impedance matching characteristics.
**
A 2.7-4.7pF by-pass capacitor should be connected to GND (acting as RF GND) when using the DC feed feature.
Without DC Feed
With DC Feed**
Solder Resist
*
0.3
0.25
*
0.55
0.3
*
0.25
*
0.55
Land
Through-hole (Φ 0.3)
RF by pass capacitor (DC Block)
Johanson p/n***:
500R07S2R7CV4T
500R07S4R7CV4T
***Either
2 values will work well as
RF bypass (can use values in
between)
*
0.25
*
0.25
Johanson Technology, Inc. reserves the right to make design changes without notice.
All sales are subject to Johanson Technology, Inc. terms and conditions.
www.johansontechnology.com
4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821
2010 Johanson Technology, Inc. All Rights Reserved
Preliminary
"High Frequency Ceramic Solutions"
P/N 5400BL14A0200
Page 2 of 2
5.4GHz 50:200Ω Balun
Detail Specification: 12/14/10
Typical Electrical Performance (T=25°C)
Insertion and Return Loss
0
-5
dB(RL)
dB(IL)
-10
-15
-20
3.0
3.5
4.0
4.5
freq, GHz
Amplitude and Phase Balance
5.0
5.5
6.0
2
Amp_difference
1
0
-1
-2
4.5
5.0
freq, GHz
5.5
6.0
200
Phase_difference
190
180
170
160
Johanson Technology, Inc. reserves the right to make design changes without notice.
All sales are subject to Johanson Technology, Inc. terms and conditions.
www.johansontechnology.com
4001 Calle Tecate • Camarillo, CA 93012 • TEL 805.389.1166 FAX 805.389.1821
2010 Johanson Technology, Inc. All Rights Reserved
