A = Available Value (may have greater minimum order quantity)
Environmental Characteristics
Description
Short Time Overload
Load Life
Resistance to
Soldering Heat
Thermal Shock
2.5 x (PR)
1/2
for 5 seconds.
(IEC 115-1 4.13)
(PR)
1/2
for 1000 hours; 1.5 hours on; 0.5 hours off.
(IEC 115-1 4.25.1)
260 °C for 10 seconds.
(IEC 115-1 4.18)
5 cycles from -55 °C to +125 °C, 30 minutes at temperature.
(IEC 115-1 4.19)
Method
Limit
1 % Tolerance:
ΔR ≤
±(1 % + 0.001
Ω)
5 % Tolerance:
ΔR ≤
±(2 % + 0.001
Ω)
1 % Tolerance:
ΔR ≤
±(1 % + 0.001
Ω)
5 % Tolerance:
ΔR ≤
±(2 % + 0.001
Ω)
1 % Tolerance:
ΔR ≤
±(0.5 % + 0.001
Ω)
5 % Tolerance:
ΔR ≤
±(1 % + 0.001
Ω)
1 % Tolerance:
ΔR ≤
±(0.5 % + 0.001
Ω)
5 % Tolerance:
ΔR ≤
±(1 % + 0.001
Ω)
*RoHS Directive 2002/95/EC Jan. 27, 2003 including annex and RoHS Recast 2011/65/EU June 8, 2011.
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
CRL Series - Low Value Chip Resistors
Chip Dimensions
Dimension
L
W
H
I1
I2
Model
CRL0603
1.60 ± 0.10
(0.063 ± 0.004)
0.80 ± 0.10
(0.031 ± 0.004)
0.45 ± 0.10
(0.018 ± 0.004)
0.30 ± 0.20
(0.012 ± 0.008)
0.30 ± 0.20
(0.012 ± 0.008)
Model
CRL0805
2.00 ± 0.15
(0.079 ± 0.006)
1.25 ± 0.10
(0.049 ± 0.004)
0.50 ± 0.10
(0.020 ± 0.004)
0.40 ± 0.20
(0.016 ± 0.008)
0.40 ± 0.20
(0.016 ± 0.008)
Model
CRL1206
3.20 ± 0.15
(0.126 ± 0.006)
1.60 ± 0.15
(0.063 ± 0.006)
0.60 ± 0.10
(0.024 ± 0.004)
0.50 ± 0.25
(0.020 ± 0.010)
0.50 ± 0.25
(0.020 ± 0.010)
Model
CRL2010
5.00 ± 0.20
(0.197 ± 0.008)
2.50 ± 0.20
(0.098 ± 0.008)
0.60 ± 0.10
(0.024 ± 0.004)
0.60 ± 0.25
(0.024 ± 0.010)
0.60 ± 0.25
(0.024 ± 0.010)
Model
CRL2512
6.30 ± 0.20
(0.248 ± 0.008)
3.10 ± 0.20
(0.122 ± 0.008)
0.60 ± 0.10
(0.024 ± 0.004)
0.60 ± 0.25
(0.024 ± 0.010)
0.60 ± 0.20
(0.024 ± 0.008)
Dimensional Drawing
I1
I1
Derating Curve
Rated power in percentage (%)
100
80
60
40
20
0
-55
0
70
(°C) Ambient temperature
125
H
DIMENSIONS:
MM
(INCHES)
I2
L
I2
W
How to Order
CRL 0603 - F W - R090 E LF
Model
(CRL = Chip Resistor Low Value)
Size
• 0603
• 0805
• 1206
• 2010
• 2512
Resistance Tolerance
F = ±1 %
J = ±5 %
TCR (PPM/°C)
W = ±200 (0.05 to 9.10
Ω)
V = ±400 (0.03 to 0.04
Ω)
U = ±600 (0.02
Ω)
Resistance Value (1 % or 5 %)
• R stands for decimal point. Three significant digits: (R090 = 0.09
Ω;
9R10 = 9.10
Ω)
Packaging
• CRL0603, CRL0805, CRL1206: E = Paper Tape, Plastic Reel, 5,000 pcs.
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
CRL Series - Low Value Chip Resistors
Packaging Dimensions - Tape
Dimension
A
B
W
F
P0
Model
CRL0603
1.10 ± 0.10
(0.043 ± 0.004)
1.90 ± 0.10
(0.075 ± 0.004)
8.00 ± 0.20
(0.315 ± 0.008)
3.50 ± 0.05
(0.138 ± 0.002)
4.00 ± 0.10
(0.157 ± 0.004)
Model
CRL0805
1.65 +0.20 / -0.10
(0.065 +0.008 / -.004)
2.40 +0.20 / -0.10
(0.094 +0.008 / -.004)
8.00 ± 0.20
(0.315 ± 0.008)
3.50 ± 0.05
(0.138 ± 0.002)
4.00 ± 0.10
(0.157 ± 0.004)
Model
CRL1206
1.95 +0.10 / -0.05
(0.077 +0.004 / -.002)
3.50 ± 0.10
(0.138 ± 0.004)
8.00 ± 0.20
(0.315 ± 0.008)
3.50 ± 0.05
(0.138 ± 0.002)
4.00 ± 0.10
(0.157 ± 0.004)
Model
CRL2010
2.80 ± 0.20
(0.110 ± 0.008)
5.50 ± 0.20
(0.217 ± 0.008)
12.0 ± 0.30
(0.472 ± 0.012)
5.50 ± 0.05
(0.217 ± 0.002)
4.00 ± 0.10
(0.157 ± 0.004)
Model
CRL2512
3.50 ± 0.20
(0.138 ± 0.008)
6.70 ± 0.20
(0.264 ± 0.008)
12.00 ± 0.30
(0.472 ± 0.012)
5.50 ± 0.05
(0.217 ± 0.002)
4.00 ± 0.10
(0.157 ± 0.004)
Packaging Dimensions - Reel
Dimension
N
D
T
Model
CRL0603
80.00 ± 1.00
(3.150 ± 0.040)
20.50
(0.807)
10.00 ± 1.50
(0.394 ± 0.059)
Model
CRL0805
80.00 ± 1.00
(3.150 ± 0.040)
20.50
(0.807)
10.00 ± 1.50
(0.394 ± 0.059)
Model
CRL1206
80.00 ± 1.00
(3.150 ± 0.040)
20.50
(0.807)
10.00 ± 1.50
(0.394 ± 0.059)
Model
CRL2010
80.00 ± 0.20
(3.150 ± 0.008)
20.00 MIN.
(0.787)
16.70 MAX.
(0.657)
Model
CRL2512
80.00 ± 0.20
(3.150 ± 0.008)
20.00 MIN.
(0.787)
16.70 MAX.
(0.657)
4.0 ± 0.1
(.157 ± .004)
A
B
F
W
13.0 ± 0.5
(0.512 ± .020)
N
P0
1.5 +0.1/-0
(.056 + .004/-0)
1.75 ± 0.1
(.059 ± .004)
2.0 ± 0.5
(.080 ± .020)
2.0 ± 0.05
(.079 ± .002)
DIMENSIONS:
MM
(INCHES)
D
178.0 ± 2.0
(7.008 ± .080)
T
REV. 02/15
Specifications are subject to change without notice.
The device characteristics and parameters in this data sheet can and do vary in different applications and actual device performance may vary over time.
Users should verify actual device performance in their specific applications.
