5180-2PG-515 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> The connector> 5180-2PG-515

5180-2PG-515: DescriptionStandard Circular Connector MULTI-CON CBL-CBL CRIMP; CategoryThe connector The connector; File Size2MB，36 Pages; ManufacturerSwitchcraft

Download Datasheet Parametric View All

5180-2PG-515 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	5180-2PG-515	-	-	View	Buy Now

5180-2PG-515 Overview

Standard Circular Connector MULTI-CON CBL-CBL CRIMP

5180-2PG-515 Parametric

Parameter Name	Attribute value
Reach Compliance Code	compliant
Back shell type	SOLID
Connector type	CIRCULAR CONNECTOR
Contact to complete cooperation	GOLD OVER NICKEL
Contact completed and terminated	GOLD OVER NICKEL
Contact point gender	MALE
Coupling type	THREADED
DIN compliance	NO
empty shell	NO
Environmental characteristics	CORROSION/ENVIRONMENT RESISTANT
Filter function	NO
IEC compliance	NO
JESD-609 code	e4
MIL compliance	NO
Plug information	MULTIPLE MATING PARTS AVAILABLE
Mixed contacts	NO
Installation type	CABLE
Options	WATERPROOF
Shell material	POLYAMIDE
Termination type	CRIMP
Total number of contacts	2
Base Number Matches	1

Preview

Download Datasheet

View All

* Please visit the product pages on our website for the most up-to-date product information
