Qualified to AEC-Q101 Standards for High Reliability
PPAP Capable (Note 4)
Part Number
DDTA123ECA
DDTA143ECA
DDTA114ECA
DDTA124ECA
DDTA144ECA
DDTA115ECA
SOT23
Mechanical Data
Case: SOT23
Case Material: Molded Plastic, “Green” Molding Compound
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Finish – Matte Tin Plated Leads, Solderable per
MIL-STD-202, Method 208
Weight: 0.008 grams (approximate)
R1, R2 (NOM)
2.2KΩ
4.7KΩ
10KΩ
22KΩ
47KΩ
100KΩ
OUT
3
C
B
R1
R2
IN B
1
3
C OUT
E
1
IN
2
GND(+)
GND (0)
Top View
Device Schematic
Equivalent Inverter Circuit
Ordering Information
(Notes 3 & 4)
Product
DDTA123ECA-7-F
DDTA143ECA-7-F
DDTA114ECA-7-F
DDTA114ECAQ-7-F
DDTA114ECAQ-13-F
DDTA124ECA-7-F
DDTA144ECA-7-F
DDTA144ECAQ-13-F
DDTA115ECA-7-F
Notes:
Compliance
AEC-Q101
AEC-Q101
AEC-Q101
Automotive
Automotive
AEC-Q101
AEC-Q101
Automotive
AEC-Q101
Marking
P04
P08
P13
P13
P13
P17
P20
P20
P24
Reel size (inches)
7
7
7
7
13
7
7
13
7
Tape width (mm)
8
8
8
8
8
8
8
8
8
2
E
Quantity per reel
3,000
3,000
3,000
3,000
10,000
3,000
3,000
10,000
3,000
1. No purposely added lead. Fully EU Directive 2002/95/EC (RoHS) & 2011/65/EU (RoHS 2) compliant.
2. See http://www.diodes.com/quality/lead_free.html for more information about Diodes Incorporated’s definitions of Halogen- and Antimony-free, "Green"
and Lead-free.
3. Halogen- and Antimony-free "Green” products are defined as those which contain <900ppm bromine, <900ppm chlorine (<1500ppm total Br + Cl) and
<1000ppm antimony compounds.
4. Automotive products are AEC-Q101 qualified and are PPAP capable. Automotive, AEC-Q101 and standard products are electrically and thermally the
same, except where specified. For more information, please refer to http://www.diodes.com/quality/product_compliance_definitions/.
5. For packaging details, go to our website at http://www.diodes.com/products/packages.html.
Marking Information
XXX = Product Type Marking Code, See Ordering Information
