F1953NCGI

Description
Low Signal Relays - PCB 1A 5VDC DPDT NON-LATCHING PCB
CategoryTopical application    Wireless rf/communication
File Size2MB,17 Pages
ManufacturerIDT (Integrated Device Technology, Inc.)
Websitehttp://www.idt.com/
Download Datasheet Parametric View All

F1953NCGI Online Shopping

Suppliers Part Number Price MOQ In stock
F1953NCGI - - View Buy Now

F1953NCGI Overview

Low Signal Relays - PCB 1A 5VDC DPDT NON-LATCHING PCB

F1953NCGI Parametric

Parameter NameAttribute value
Product CategoryAttenuators
ManufacturerIDT (Integrated Device Technology, Inc.)
RoHSDetails
Maximum Attenuation32.4 dB
Maximum Frequency4 GHz
Number of Bits6 bit
Number of Channels1 Channel
Impedance50 Ohms
Maximum VSWR-
Package / CaseQFN-20
Minimum Operating Temperature- 40 C
Maximum Operating Temperature+ 100 C
Height0.75 mm
Insertion Loss1.4 dB
Length4 mm
Minimum Frequency0.4 GHz
Mounting StyleSMD/SMT
Operating Supply Voltage2.7 V to 3.3 V
PackagingTray
Factory Pack Quantity490
TechnologySilicon
TypeDigital Step Attenuator
Width4 mm
F1953
DATASHEET
6-bit Digital Step Attenuator
400 to 4000 MHz IDTF1953
G
ENERAL
D
ESCRIPTION
This document describes the specification for the
IDTF1953 Digital Step Attenuator. The F1953 is part of a
family of
Glitch-Free
TM
DSAs optimized for the demanding
requirements of communications Infrastructure. These
devices are offered in a compact 4x4 QFN package with
50
Ω
impedances for ease of integration.
F
EATURES
Glitch-Free
TM
, < 0.6 dB transient overshoot
C
OMPETITIVE
A
DVANTAGE
Digital step attenuators are used in Receivers and
Transmitters to provide gain control. The IDTF1953 is a
6-bit step attenuator optimized for these demanding
applications. The silicon design has very low insertion
loss and low distortion (> +60 dBm IP3
I
.) The device
has pinpoint accuracy and settles to final attenuation
value within 400 nsec. Most importantly, the F1953
includes IDT’s
Glitch-Free
TM
technology which results in
less than 0.5 dB of overshoot ringing during MSB
transitions. This is in stark contrast to competing DSAs
that
glitch as much as 10 dB
(see p. 10.)
Lowest insertion loss for best SNR
Glitch-Free
TM
when transitioning – won’t
damage PA or ADC
Extremely accurate with low distortion
TM
Glitch-Free
TM
Spurious Free Design
2.7 to 3.3 V supply
Attenuation Error < 0.5 dB @ 2 GHz
Low Insertion Loss < 1.4 dB @ 2 GHz
Excellent Linearity >+60 dBm IP3
I
Fast settling time, < 400 nsec
Serial or Parallel Interface 31.5 dB Range
Stable Integral Non-Linearity over temperature
Low Power Consumption < 200 uA
Integrated DC blocking capacitors
Drop-In replacement
4x4 mm Thin QFN 20 pin package
D
EVICE
B
LOCK
D
IAGRAM
RF
1
RF
2
A
PPLICATIONS
Base Station 2G, 3G, 4G, TDD radiocards
Repeaters and E911 systems
Digital Pre-Distortion
Point to Point Infrastructure
Public Safety Infrastructure
WIMAX Receivers and Transmitters
Military Systems, JTRS radios
RFID handheld and portable readers
Cable Infrastructure
V
MODE
V
DD
D[5:0]
CLK DATA LE
6
Bias
DEC
SPI
O
RDERING
I
NFORMATION
Omit IDT
prefix
0.8 mm height
package
Tape &
Reel
P
ART
# M
ATRIX
Part#
Freq range
Resolution
/ Range
0.25 / 31.75
0.50 / 31.5
0.50 / 15.5
0.50 / 31.5
Control
Parallel &
Serial
Serial Only
Serial Only
Parallel &
Serial
IL
Pinout
PE43702
PE43701
HMC305
HMC305
PE4302
DAT-31R5
IDTF1953NCGI8
RF product Line
Green
Industrial
Temp range
F1950
F1951
F1952
F1953
150 - 4000
100 - 4000
100 – 4000
400 - 4000
-1.3
-1.2
-0.9
-1.3
Glitch-Free
TM
Digital Step Attenuator
1
Rev2 April2014
