Data sheet No. PD60282
IPS6041(G)(R)(S)PbF
INTELLIGENT POWER HIGH SIDE SWITCH
Features
•
•
•
•
•
•
•
•
•
Over temperature shutdown (with auto-restart)
Short circuit protection (current limit)
Reverse battery protection (turns On the MOSFET)
Full diagnostic capability (short circuit to battery)
Active clamp
Open load detection in On and Off state
Ground loss protection
Logic ground isolated from power ground
ESD protection
Product Summary
Rds(on)
Vclamp
I Limit
Open load
Packages
130mΩ max.
39V
7A
3V / 0.22A
Description
The IPS6041(G)(R)(S)PbF is a five terminal Intelligent
Power Switch (IPS) for use in a high side configuration. It
features short circuit, over-temperature, ESD protection,
inductive load capability and diagnostic feedback. The
output current is limited to the Ilim value. The current
limitation is activated until the thermal protection acts. The
over-temperature protection turns off the device if the
junction temperature exceeds the Tshutdown value. It will
automatically restart after the junction has cooled 7°C
below the Tshutdown value. The reverse battery
protection turns On the MOSFET. A diagnostic pin
provides different voltage levels for each fault condition.
The double level shifter circuitry will allow large offsets
between the logic and load ground.
SO8
IPS6041GPbF
D-Pak
IPS6041RPbF
TO220
IPS6041PbF
D2Pak
IPS6041SPbF
Typical Connection
+5V
+Bat
Rdgp
Vcc(5-6-7-8)
Dg(3)
Control
Rdgs
Pull-up resistors required for
open load off and short
circuit to Vbat detection
In(2)
V Diag
Rin
Gnd(1)
Out(4)
Input Signal
Load
www.irf.com
1
IPS6041(G)(R)(S)PbF
Absolute Maximum Ratings
Absolute maximum ratings indicate sustained limits beyond which damage to the device may occur. All voltage parameters
are referenced to Ground lead. (Tambient=25°C unless otherwise specified).
Symbol
Vout
Voffset
Vin
Vcc max.
Vcc cont.
Iin max.
Idg max.
Vdg
Pd
Parameter
Maximum output voltage
Maximum logic ground to load ground offset
Maximum input voltage
Maximum Vcc voltage
Maximum continuous Vcc voltage
Maximum IN current
Maximum diagnostic output current
Maximum diagnostic output voltage
Maximum power dissipation (internally limited by thermal protection)
Rth=100°C/W IPS6041G
Rth=50°C/W IPS6041R 1”sqrt. footprint
Electrostatic discharge voltage (Human body) C=100pF, R=1500Ω
Between In and Vcc
Other combinations
Electrostatic discharge voltage (Machine Model) C=200pF,R=0Ω,L=10µH
Between In and Vcc
Other combinations
Max. storage & operating temperature junction temperature
Soldering temperature (10 seconds)
Min.
Max.
Units
V
Vcc-35 Vcc+0.3
Vcc-35 Vcc+0.3
-0.3
5.5
⎯
36
⎯
28
-3
10
-3
10
-0.3
5.5
⎯
⎯
⎯
⎯
⎯
⎯
mA
V
W
1.25
2.5
1500
4000
100
500
150
300
ESD
V
Tj max.
Tsoldering
-40
⎯
°C
°C
Thermal Characteristics
Symbol
Rth1
Rth1
Rth2
Rth3
Rth1
Rth2
Parameter
Thermal resistance junction to ambient IPS6041G
Thermal resistance junction to ambient IPS6041R D-Pak std. footprint
Thermal resistance junction to ambient IPS6041R D-Pak 1” sqrt. footprint
Thermal resistance junction to case IPS6041(R)(S) D-Pak/D2pak/TO220
Thermal resistance junction to ambient IPS6041(S) D2Pak/TO220 std.
footprint
Thermal resistance junction to ambient IPS6041S D2Pak 1” sqrt. footprint
Typ.
100
70
50
6
60
40
Max.
⎯
⎯
⎯
⎯
⎯
⎯
Units
°C/W
Recommended Operating Conditions
These values are given for a quick design. For operation outside these conditions, please consult the application notes.
Symbol
VIH
VIL
Iout
Parameter
High level input voltage
Low level input voltage
Continuous drain current, Tambient=85°C, Tj=125°C, Vin=5V
Rth=100°C/W IPS6041G
Rth=50°C/W IPS6041R 1” sqrt. footprint
Recommended resistor in series with IN pin
Recommended resistor in series with DG pin for reverse battery protection
Recommended pull-up resistor for DG
Recommended pull-up resistor for open load detection
Max. switching frequency
Min.
4
0
⎯
⎯
Max.
5.5
0.9
1.6
2.3
10
20
20
100
3.5
Units
A
Rin
Rdgs
Rdgp
Rol
F max.
4
4
4
5
⎯
kΩ
kHz
www.irf.com
2
IPS6041(G)(R)(S)PbF
Static Electrical Characteristics
Tj=25°C, Vcc=14V (unless otherwise specified)
Symbol
Rds(on)
Parameter
ON state resistance Tj=25°C
ON state resistance Tj=150°C
ON state resistance Tj=25°C, Vcc=6V
ON state resistance during reverse battery
Operating voltage range
Vcc to Out clamp voltage 1
Vcc to Out clamp voltage 2
Supply current when Off
Supply current when On
Input high threshold voltage
Input low threshold voltage
Input hysteresis
Input current when device is On
Dg leakage current
Low level DG voltage
Min.
⎯
⎯
⎯
⎯
Typ.
110
190
125
140
⎯
Max.
130
230
155
180
28
⎯
Units
mΩ
Test Conditions
Vin=5V, Iout=2.5A
Vin=5V, Iout=2.5A
Vin=5V, Iout=1.5A
Vcc-Gnd=14V
Iout=20mA
Iout=2.5A (see Fig. 1)
Vin=0V, Vout=0V
Vin=5V
Vcc op.
V clamp 1
V clamp 2
Icc Off
Icc On
Vih
Vil
In hyst.
Iin On
Idg
Vdg
6
37
⎯
⎯
⎯
⎯
1.5
0.2
⎯
⎯
⎯
39
40
4
2.2
2.5
2
0.5
45
0.1
0.25
V
µA
mA
V
µA
V
42
9
5
2.9
⎯
1
100
10
0.4
Vin=5V
Vdg=5V
Idg=1.6mA
Switching Electrical Characteristics
Vcc=14V, Resistive load=6
Ω,
Vin=5V, Tj=25°C
Symbol
Tdon
Tr1
Tr2
dV/dt (On)
EOn
Tdoff
Tf
dV/dt (Off)
EOff
Parameter
Turn-on delay time
Rise time to Vout=Vcc-5V
Rise time to Vout=0.9 x Vcc
Turn On dV/dt
Turn On energy
Turn-off delay time
Fall time to Vout=0.1 x Vcc
Turn Off dV/dt
Turn Off energy
Min.
⎯
⎯
⎯
⎯
⎯
⎯
⎯
⎯
⎯
Typ.
5
3
4
2.5
100
10
3
6.5
50
Max.
15
10
20
5
⎯
Units
µs
V/µs
µJ
µs
V/µs
µJ
Test Conditions
see Fig. 3
20
10
20
⎯
www.irf.com
3
IPS6041(G)(R)(S)PbF
Protection Characteristics
Symbol
Ilim
Tsd+
Tsd-
Vsc
UV
UV hyst.
VOL Off
I OL On
Parameter
Internal current limit
Over temperature high threshold
Over temperature low threshold
Short-circuit detection voltage(2)
Min.
4
150(1)
⎯
Typ.
7
165
158
3
5
⎯
Max.
10
⎯
⎯
Units
A
°C
Test Conditions
Vout=0V
See fig. 2
2
⎯
Open load detection threshold
Open load detection threshold
0.25
2
0.05
3
0.15
4
5.9
1.6
4
0.22
V
A
(1) Guaranteed by design
(2) Reference to Vcc
True Table
Operating Conditions
IN
OUT
DG
Normal
H
H
H
Normal
L
L
H
Open Load
H
H
L
Open Load (3)
L
H
L
Short circuit to Gnd
H
L
L
Short circuit to Gnd
L
L
H
Short circuit to Vcc
H
H
L (4)
Short circuit to Vcc (5)
L
H
L
Over-temperature
H
L
L
Over-temperature
L
L
H
(3) With a pull-up resistor connected between the output and Vcc.
(4) Vds lower than 10mV.
(5) Without a pull-up resistor connected between the output and Vcc.
Lead Assignments
3- Vcc
8765
3- Vcc
1234
1- Gnd
2- In
3- DG
4- Out
5-6-7-8 Vcc
1- Gnd
2- In
3- Vcc
4- Dg
5- Out
12345
SO8
1 2 3 4 5
D²Pak – D Pak
TO220
www.irf.com
4
IPS6041(G)(R)(S)PbF
Functional Block Diagram
All values are typical
VCC
165°C
Tj
43V
158°C
Vcc-gnd >UV
2.5V
Level
Shifter
Charge
Pump
37V
Driver
43V
IN
6V
150k
Ω
2.0V
-
Over-temp
Open load off
+
I Limit
+
-
I sense
DG
6V
Short circuit
3V
-
+
3V
Open load on
Ground
Disconnect
-
+
20mV
GND
OUT
www.irf.com
5
