MC100LVEL90
−3.3V / −5V Triple ECL Input
to LVPECL Output Translator
Description
The MC100LVEL90 is a triple ECL to LVPECL translator. The device
receives either
−3.3
V or
−5
V differential ECL signals, determined by the
V
EE
supply level, and translates them to +3.3 V differential LVPECL
output signals.
To accomplish the level translation, the LVEL90 requires three power
rails. The V
CC
supply should be connected to the positive supply, and the
V
EE
pin should be connected to the negative power supply. The GND
pins, as expected, are connected to the system ground plane. Both V
EE
and V
CC
should be bypassed to ground via 0.01
mF
capacitors.
Under open input conditions, the D input will be biased at V
EE
/2 and
the D input will be pulled to V
EE
. This condition will force the Q output
to a LOW, ensuring stability.
The V
BB
pin, an internally generated voltage supply, is available to this
device only. For single-ended input conditions, the unused differential
input is connected to V
BB
as a switching reference voltage. V
BB
may also
rebias AC coupled inputs. When used, decouple V
BB
and V
CC
via a
0.01
mF
capacitor and limit current sourcing or sinking to 0.5 mA. When
not used, V
BB
should be left open.
Features
http://onsemi.com
SO−20 WB
DW SUFFIX
CASE 751D
MARKING DIAGRAM*
•
•
•
•
500 ps Propagation Delays
ESD Protection: >2 kV HBM, >200 V MM
The 100 Series Contains Temperature Compensation
20
100LVEL90
AWLYYWWG
Operating Range: V
CC
= 3.0 V to 3.8 V;
V
EE
=
−3.0
V to
−5.5
V; GND = 0 V
•
Internal Input Pulldown Resistors
1
A
WL
YY
WW
G
= Assembly Location
= Wafer Lot
= Year
= Work Week
= Pb−Free Package
•
Q Output will Default LOW with Inputs Open or at V
EE
•
Meets or Exceeds JEDEC Spec EIA/JESD78 IC Latchup Test
•
Moisture Sensitivity;
Pb Pkg
Level 1,
Pb−Free Pkg
Level 3
For Additional Information, see Application Note AND8003/D
•
Flammability Rating: UL 94 V−0 @ 0.125 in,
Oxygen Index: 28 to 34
•
Transistor Count = 261 devices
*For additional marking information, refer to
Application Note AND8002/D.
•
Pb−Free Packages are Available*
ORDERING INFORMATION
See detailed ordering and shipping information in the package
dimensions section on page 5 of this data sheet.
*For additional information on our Pb−Free strategy and soldering details, please
download the ON Semiconductor Soldering and Mounting Techniques
Reference Manual, SOLDERRM/D.
©
Semiconductor Components Industries, LLC, 2006
November, 2006
−
Rev. 11
1
Publication Order Number:
MC100LVEL90/D
MC100LVEL90
V
CC
20
LVPECL
Q0
19
Q0
18
GND Q1
17
LVPECL
16
Q1 GND
15
14
LVPECL
Q2
13
Q2
12
V
CC
11
Table 1. PIN DESCRIPTION
PIN
Dn, Dn
Qn, Qn
ECL V
BB
V
CC
V
EE
GND
FUNCTION
ECL Inputs
LVPECL Outputs
ECL Reference Voltage Output
Positive Supply
Negative Supply
Ground
ECL
ECL
ECL
1
V
CC
2
D0
3
D0
4
ECL V
BB
5
D1
6
D1
7
ECL V
BB
8
D2
9
D2
10
V
EE
* All V
CC
pins are tied together on the die.
Warning: All V
CC
, V
EE
, and GND pins must be externally
connected to Power Supply to guarantee proper operation.
Figure 1. Logic Diagram and Pinout: 20-Lead SOIC
(Top View)
Table 2. MAXIMUM RATINGS
Symbol
V
CC
V
EE
V
I
I
out
I
BB
T
A
T
stg
q
JA
q
JC
T
sol
Parameter
PECL Power Supply
NECL Power Supply
NECL Mode Input Voltage
Output Current
ECL V
BB
Sink/Source
Operating Temperature Range
Storage Temperature Range
Thermal Resistance (Junction−to−Ambient)
Thermal Resistance (Junction−to−Case)
Wave Solder
0 lfpm
500 lfpm
Standard Board
20 SOIC
20 SOIC
20 SOIC
Condition 1
GND = 0 V
GND = 0 V
GND = 0 V
Continuous
Surge
V
I
w
V
EE
Condition 2
Rating
8 to 0
−8
to 0
−6
to 0
50
100
±
0.5
−40
to +85
−65
to +150
90
60
30 to 35
265
Unit
V
V
V
mA
mA
mA
°C
°C
°C/W
°C/W
°C/W
°C
Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the
Recommended Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect
device reliability.
http://onsemi.com
2
MC100LVEL90
Table 3. NECL INPUT DC CHARACTERISTICS
V
CC
= 3.3 V; V
EE
=
−3.3
V; GND= 0 V (Note 1)
−40°C
Symbol
I
EE
V
IH
V
IL
ECL V
BB
V
IHCMR
Characteristic
V
EE
Power Supply Current
Input HIGH Voltage (Single−Ended)
Input LOW Voltage (Single−Ended)
Output Voltage Reference
Input HIGH Voltage Common Mode
Range (Differential) (Note 2)
Vpp < 500 mV
Vpp
y
500 mV
Input HIGH Current
Input LOW Current
D
D
0.5
−600
−1165
−1810
−1.38
Min
Typ
Max
8.0
−880
−1475
−1.26
−1165
−1810
−1.38
Min
25°C
Typ
6.0
Max
8.0
−880
−1475
−1.26
−1165
−1810
−1.38
Min
85°C
Typ
Max
8.0
−880
−1475
−1.26
Unit
mA
mV
mV
V
V
EE
+1.3
VEE+1.5
−0.4
−0.4
150
V
EE
+1.2
VEE+1.4
−0.4
−0.4
150
V
EE
+1.2
VEE+1.4
−0.4
−0.4
150
V
V
mA
mA
I
IH
I
IL
0.5
−600
0.5
−600
NOTE: Device will meet the specifications after thermal equilibrium has been established when mounted in a test socket or printed circuit
board with maintained transverse airflow greater than 500 lfpm. Electrical parameters are guaranteed only over the declared
operating temperature range. Functional operation of the device exceeding these conditions is not implied. Device specification limit
values are applied individually under normal operating conditions and not valid simultaneously.
1. Input parameters vary 1:1 with GND. V
EE
can vary
−3.0
V to
−5.5
V.
2. V
IHCMR
min varies 1:1 with V
EE
. V
IHCMR
max varies 1:1 with GND.
Table 4. LVPECL OUTPUT DC CHARACTERISTICS
V
CC
= 3.3 V; V
EE
=
−3.3
V; GND= 0 V (Note 3)
−40°C
Symbol
I
CC
V
OH
V
OL
Characteristic
V
CC
Power Supply Current
Output HIGH Voltage (Note 4)
Output LOW Voltage (Note 4)
2215
1470
2295
1605
Min
Typ
Max
24
2420
1745
2275
1490
Min
25°C
Typ
20
2345
1600
Max
24
2420
1680
2275
1490
2345
1595
Min
85°C
Typ
Max
26
2420
1680
Unit
mA
mV
mV
NOTE: Device will meet the specifications after thermal equilibrium has been established when mounted in a test socket or printed circuit
board with maintained transverse airflow greater than 500 lfpm. Electrical parameters are guaranteed only over the declared
operating temperature range. Functional operation of the device exceeding these conditions is not implied. Device specification limit
values are applied individually under normal operating conditions and not valid simultaneously.
3. Output parameters vary 1:1 with V
CC
. V
CC
can vary +0.5 V /
−0.3
V. V
EE
can vary
−3.0
V to
−5.5
V.
4. Outputs are terminated through a 50
W
resistor to V
CC
−2
volts.
http://onsemi.com
3
MC100LVEL90
Table 5. AC CHARACTERISTICS
V
CC
= 3.0 V to 3.8 V; V
EE
=
−3.0
V to
−5.5
V; GND = 0 V
−40°C
Symbol
fmax
t
PLH
t
PHL
t
SKEW
Characteristic
Maximum Toggle Frequency
Propagation Delay
D to Q
Skew
Diff
S.E.
390
340
20
25
TBD
150
1000
150
Min
Typ
560
590
640
100
200
420
370
20
25
TBD
1000
150
Max
Min
25°C
Typ
650
620
670
100
200
460
410
20
25
TBD
1000
Max
Min
85°C
Typ
700
660
710
100
200
Max
Unit
MHz
ps
ps
Output−to−Output (Note 5)
Part−to−Part (Diff) (Note 5)
Duty Cycle (Diff) (Note 6)
tJITTER
V
PP
t
r
t
f
Random Clock Jitter
Input Voltage Swing (Differential Configuration)
(Note 7)
Output Rise/Fall Times Q
(20%
−
80%)
ps
mV
ps
230
500
230
500
230
500
NOTE: Device will meet the specifications after thermal equilibrium has been established when mounted in a test socket or printed circuit
board with maintained transverse airflow greater than 500 lfpm. Electrical parameters are guaranteed only over the declared
operating temperature range. Functional operation of the device exceeding these conditions is not implied. Device specification limit
values are applied individually under normal operating conditions and not valid simultaneously.
5. Skews are valid across specified voltage range, part−to−part skew is for a given temperature.
6. Duty cycle skew is the difference between a TPLH and TPHL propagation delay through a device.
7. V
PP
(min) is swing measured single−ended on each input in differential configuration. The device has a DC gain of
≈40.
Q
Driver
Device
Q
Z
o
= 50
W
D
Receiver
Device
Z
o
= 50
W
50
W
50
W
D
V
TT
V
TT
= V
CC
−
2.0 V
Figure 2. Typical Termination for Output Driver and Device Evaluation
(See Application Note AND8020/D
−
Termination of ECL Logic Devices.)
http://onsemi.com
4
MC100LVEL90
ORDERING INFORMATION
Device
MC100LVEL90DW
MC100LVEL90DWG
MC100LVEL90DWR2
MC100LVEL90DWR2G
Package
SOIC−20
SOIC−20
(Pb−Free)
SOIC−20
SOIC−20
(Pb−Free)
Package
†
38 Units / Rail
38 Units / Rail
1000 / Tape & Reel
1000 / Tape & Reel
†For information on tape and reel specifications, including part orientation and tape sizes, please refer to our Tape and Reel Packaging
Specifications Brochure, BRD8011/D.
Resource Reference of Application Notes
AN1405/D
AN1406/D
AN1503/D
AN1504/D
AN1568/D
AN1672/D
AND8001/D
AND8002/D
AND8020/D
AND8066/D
AND8090/D
−
ECL Clock Distribution Techniques
−
Designing with PECL (ECL at +5.0 V)
−
ECLinPS I/O SPiCE Modeling Kit
−
Metastability and the ECLinPS Family
−
Interfacing Between LVDS and ECL
−
The ECL Translator Guide
−
Odd Number Counters Design
−
Marking and Date Codes
−
Termination of ECL Logic Devices
−
Interfacing with ECLinPS
−
AC Characteristics of ECL Devices
http://onsemi.com
5
