BCR-119S-E6433 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> Discrete semiconductor> BCR-119S-E6433

BCR-119S-E6433: DescriptionBipolar Transistors - Pre-Biased NPN silicon Digital TRANSISTOR; Categorysemiconductor Discrete semiconductor; File Size250KB，12 Pages; ManufacturerInfineon; Websitehttp://www.infineon.com/

Download Datasheet Parametric Compare View All

BCR-119S-E6433 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	BCR-119S-E6433	-	-	View	Buy Now

BCR-119S-E6433 Overview

Bipolar Transistors - Pre-Biased NPN silicon Digital TRANSISTOR

BCR-119S-E6433 Parametric

Parameter Name	Attribute value
Product Category	Bipolar Transistors - Pre-Biased
Manufacturer	Infineon
RoHS	Details
Configuration	Dual
Transistor Polarity	NPN
Typical Input Resistor	4.7 kOhms
Mounting Style	SMD/SMT
Package / Case	SOT-363-6
DC Collector/Base Gain hfe Min	120
Collector- Emitter Voltage VCEO Max	50 V
Continuous Collector Current	100 mA
Peak DC Collector Current	100 mA
Maximum Operating Temperature	+ 150 C
Packaging	Cut Tape
Packaging	Reel
Height	0.9 mm
Length	2 mm
Minimum Operating Temperature	- 65 C
Factory Pack Quantity	10000
Width	1.25 mm
Unit Weight	0.000265 oz

Preview

Download Datasheet

View All

BCR119...

NPN silicon Digital Transistor

•

Switching circuit, inverter, interface circuit,

driver circuit

•

Built in resistor (R

=4.7 kΩ)

•

BCR119S: Two internally isolated

transistors with good matching

in one multichip package

•

BCR119S: For orientation in reel see

package information below

•

Pb-free (RoHS compliant) package

•

Qualified according AEC Q101

BCR119/F/W

BCR119S

TR1

TR2

EHA07264

EHA07265

Type

BCR119

BCR119F

BCR119S

BCR119W

Pb-containing

Marking

WKs

1=B

Pin Configuration

2=E

3=C

Package

SOT23

TSFP-3

SOT323

1=E1 2=B1 3=C2 4=E2 5=B2 6=C1 SOT363

package may be available upon special request

2007-08-02
