“ZNR” Transient/Surge Absorbers (Type D)
“ZNR” Transient/Surge Absorbers
Type:
Series:
D
V
Features
●
Large
withstanding surge current capability in compact sizes
●
Large “Energy Handling Capability” absorbing transient overvoltages in compact sizes
●
Wide range of varistor voltages
●
RoHS compliant
Recommended Applications
●
Transistor,
diode, IC, thyristor or triac semiconductor protection
●
Surge protection in consumer electronic equipment
●
Surge protection in communication, measuring or controller electronics
●
Surge protection in electronic home appliances, gas or petroleum appliances
Applicable Standards
●
UL1449
(VZCA2/UL, VZCA8/C-UL)
●
VDE IEC61051-1, -2, -2-2, IEC60950-1 Annex.Q
●
CSA C22.2 No.1
●
CQC(GB/T10193, GB/T10194, GB4943.1, GB8898)
Refer to page 5 to 8, and 27, for the details
■
As for Handling Precautions and Minimum Quantity / Packing Unit
Please see Related Information
Explanation of Part Numbers (Bulk)
1
2
3
4
5
6
7
8
9
10
11
12
E
R
Product Code
Z
V
Series
D
Design No.
Element Size
f
10 mm
f
5 mm
10
f
14 mm
f
7 mm
14
f
20 mm
f
10 mm
20
Lead Configuration
D Straight Lead
V Crimped Lead
½
½
Excluding
f20.
½
Only the lead cut
05
07
09
Norminal Varistor Voltage
The first two digits are significant
figures and the third one denotes
the number of zeros following.
Explanation of Part Numbers (Taping)
1
2
3
4
5
6
7
8
9
10
11
12
E
R
Product Code
Z
V
Series
Element Size
f
5 mm
5
f
7 mm
7
f
10 mm
9
f
10 mm
A
f
14 mm
E
D
Design No.
Lead Configuration
D
Straight Lead
Crimped Lead
V
Nominal Varistor Voltage
The first two digits are significant
figures and the third one denotes
the number of zeros following.
A to D
E to H
Taping / Packaging
Radial Taping (P
0
=12.7 mm)
Radial Taping (P
0
=15.0 mm)
