THESE DRAWINGS ARE THE PROPERTY OF QUALTEK
ELECTRONICS AND NOT TO BE REPRODUCED FOR
OR COMMUNICATED TO A THIRD PARTY WITHOUT
THE EXPRESS WRITTEN PERMISSION OF AN OFFICER
OF QUALTEK ELECTRONICS.
REVISION
REV.
B
C
DESCRIPTION
RoHS Compliancy
Reduction in Size of the Insulator Between Terminals
DATE
06-01-06
05-05-16
APPROVED
DP
LY
R1
3
21
4.8
6.5 6.5
22.3
6 ± 0.1
2 ±.05
R3.
5
23.5 ± 0.2
31.6 ± 0.2
0.2
0
10.2REF
5 ± 0.1
13 ± 0.2
29 ±
0.5
0
42
53REF
8 ± 0.2
21 ±
0.5
0
30REF
32 ±
0.2
0
42 ± 0.2
PANEL CUTOUT
24 ±
NOTES:
RATING:
UL, CSA: 20A 125V AC/ 20A 250V AC
VDE: 16A 250V AC
APPROVALS: UL,CSA, VDE
UL FILE: E139592
CSA FILE: LR75389
IEC 60320 C20
BODY COLOR: BLACK
RoHS COMPLIANT
Dim
range
(mm)
0-1
1-6
6-18
18-50
50-120
120-250
250-500
Tolerance
+/-
(mm)
0.15
0.20
0.30
0.50
0.70
0.90
1.20
CONTROLLED
Qualtek Electronics Corp.
Part Number:
Description:
PPC DIVISION
744W-00/03
AC RECEPTACLE
UNIT: mm
REV. C
Approved / Date
JJH / 02-26-03
Drawn / Date
B.Zhang
02-26-03
14.4
Checked / Date
02-26-03
2.5
R3
X
MA
.
R4
5
