3,50 ±0,50 0,138 ±0,020
8,89 0,350
3,05 0,120
21,56 0,849
16,35 0,644
1
8
DATE CODE
DATUMSCODE
PART NO.
IDENT-NR.
6,60 0,260
LED 2
LED 1
16,51 0,650
15,95 0,628
RECOMMENDED PANEL CUTOUT
EMPFOHLENER FRONTPLATTEN AUSSCHNITT
16,66 0,656
Copyright by ERNI GmbH
Proprietary notice pursuant to ISO 16016 to be observed.
MATERIALS AND FINISH
HOUSING: GLASS FILLED POLYESTER UL 94 V-0 BLACK
SHIELDING: Cu ALLOY, PLATED WITH Ni
CONTACTS: PHOSPHOR BRONZE
CONTACT FINISH: Au, 0.8 µm (30 µin) OVER Ni
TERMINAL FINISH: Sn MATTE
LED LENS: EPOXY
MECHANICAL CHARACTERISTICS
DURABILITY: 1000 MATING CYCLES
ELECTRICAL CHARACTERISTICS
CONTACT RESISTANCE: 30 MILLIOHMS MAX
OPERATING TEMPERATURE: 0°C TO 70°C
17,26 0,680
XXXXXX
XXXX RC
NOTE 1: RoHS COMPLIANT; PRINT "RC" WITH DATE CODE
NO.
IDENT.-NR.
203497
LED 2 LEFT
LED 2 LINKS
YELLOW
LED 1 RIGHT
LED 1 RECHTS
GREEN
LED
CODE
L1
Information:
Tolerances
All Dimensions
in mm [in]
Scale
2:1
All rights reserved.
Only for Information.
To insure that this is the latest
version of this drawing, please
contact one of the ERNI companies
before using.
C
Index
23.02.2009
Date
Designation
Subject to modification without
prior notice.
Drawing will not be updated.
MOD - JACK MJIMV
1x1, 8C8T, VERTICAL, INT. MAG., LED
www.ERNI.com
Class
203498
MJIM
I (1/2)
A3
ELECTRICAL SCHEMATIC 10/100 BASE TX - M3F01
ELEKTRISCHES DIAGRAMM
RECOMMENDED PCB LAYOUT (COMPONENT SIDE VIEW)
EMPFOHLENES LEITERPLATTEN-LAYOUT (BESTÜCKUNGSSEITE)
TOL ±0.05 [.002] UNLESS NOTED
1,27 0,050
0,64 0,025
2,54 0,100
PCB
TD+ P1
CT P4
TD- P2
RD+ P3
CT P5
2
1
8
CABLE
J1 TX+
J2 TX-
J3 RX+
RD- P6
J6 RX-
0,89 0,035
1,60 0,063
3,25 0,128
1,02 0,040
x8
x2
9
7
2,540 0,100
J4,5
8,89 0,350
GND P8
1000pF/2KV
4X 75
J7,8
10
11
12
x2
x4
4,57 0,180
3,05 0,120
2,54 0,100
2,54 0,100
8,38 0,330
LED SPECIFICATIONS
LED ANWEISUNG
COLOR
FARBE
YELLOW
GREEN
Vf
TYP
2.1
2.2
Vf
MAX
2.5
2.5
If
mA
20
20
CIRCUIT DIAGRAM
SCHALTPLAN
9 10
11 12
MAGNETICS SPECIFICATIONS @ 25°C
TURNS RATIO:
(P1-P2 : J1-J2)
(P3-P6 : J3-J6)
11,43 0,450
15,49 0,610
1CT : 1 ±3%
1CT : 1 ±3%
OCL(100 KHz, 0.1 Vrms, 8 mA)
(P1-P2 : P3-P6)
350µH MIN
INSERTION LOSS:
0.1-100 MHz
RETURN LOSS:
0.5 - 30 MHz:
40 MHz:
50 MHz
60 - 80 MHz
CROSSTALK:
1-100 MHz
CMR:
0.1 - 30 MHz
30 - 60 MHz
60 - 100 MHz
ISOLATION
9 10
11 12
-1.1 dB TYP
-18 dB MIN
-15.5 dB MIN
-13.6 dB MIN
-12 dB MIN
-40 dB TYP
-50 dB TYP
-40 dB TYP
-35 dB TYP
1500 Vrms
Copyright by ERNI GmbH
Proprietary notice pursuant to ISO 16016 to be observed.
Information:
Tolerances
All Dimensions
in mm [in]
Scale
2:1
All rights reserved.
Only for Information.
To insure that this is the latest
version of this drawing, please
contact one of the ERNI companies
before using.
Designation
Subject to modification without
prior notice.
Drawing will not be updated.
MOD - JACK MJIMV
1x1, 8C8T, VERTICAL, INT. MAG., LED
www.ERNI.com
Class
203498
MJIM
I (2/2)
A3
