Fuseholders
For 3AG, 5 x 20mm, or 2AG Fuses
Shock-Safe for 3AG or 5x20mm Fuses
PC Board Type
Similar to Shock-Safe fuseholders shown on preceding page, but
designed for P.C. board mounting. Shock-Safe design per IEC Standards
60127 and 60065. Two different knob styles available for use with 3AG
(1/4" x 11/4") or 5 x 20mm fuses.
APPROVALS:
Recognized under the Components Program of
Underwriters Laboratories (16A, 250V).
Certified by CSA (15A, 250V).
VDE approved (10A, 250V).
®
®
D
V
E
SPECIFICATIONS:
Electrical:
Rating: See APPROVALS.
Insulation Resistance:
10,000 megohm minimum at 500 VDC.
Contact Resistance:
Less than .005 ohm average at a current of
one ampere.
Reference Dimensions
1.77"
.44"
.49"
Dielectric Strength:
4000 volts minimum.
Mounting:
Intended for soldering to printed circuit boards.
Molded Parts:
Body Material: Black glass-filled thermoplastic
(UL 94V0).
Knob:
Screwdriver slot, fuse extractor type with nickel-plated, copper
alloy insert. Spring-loaded, bayonet style.
Knob Material:
Grey or Black glass-filled thermoplastic (UL94 V-0).
Terminals:
Brass. Tin-plated.
Ambient Temperature:
–40°C to +85°C.
ORDERING INFORMATION:
Catalog
Number
345
101
345
121
* Please refer to Fuseology section for information on
proper fuseholder de-rating.
Body only:
345
101-010
Knob only:
345
101-020 (
1
/
4
" x 1
1
/
4
") Grey;
345
121-020 (5 x 20mm) Black.
yy
;;
.68"
.20"
.24"
.598"
.602"
.698"
.702"
.15" MAX
.86"
.92"
DIA.
.032"
.76"
1.31"
1.75"
2.08"
2.40"
.15" MAX
.890"
1.310"
.446"
.48"
.12"
.040"
.242"
.246"
.056"
DIA.
Fuse
Size
1
1
4
" x 1 /
4
" Fuses
/
5 x 20mm Fuses
For Midget Fuses
Panel Mount Type
Two panel mount fuseholder designs are available for supplementary or
Class CC branch circuit protection. Class CC fuses have a rejection
feature on one end cap which mates with the rejection feature of
Littelfuse Class CC fuse blocks and fuseholders to prevent the
installation of fuses with lower voltage ratings or interrupting ratings.
®
®
APPROVALS:
Recognized under the Components Program of
Underwriters Laboratories and Certified by CSA.
SPECIFICATIONS:
Electrical:
Rated at 30 amperes for any voltage up to 600 volts.
Dielectric Strength:
4000 volts minimum.
Mounting:
Flange mounting either in front of or behind panel.
Watertight version must be front panel mounted. Maximum panel thick-
ness is .75".
Molded Parts:
Black thermoplastic (UL94 V-0).
Reference Dimensions
.172" DIA.
(2)
1.12"
STANDARD MOUNTING
(FLANGE IN FRONT OF PANEL)
13
FUSEHOLDERS
Knob:
Screw type, with engraved markings: unfilled characters (571
007,
571
008,
571
007P,
571
008P), light blue characters (571 027,
571
028,
571
027P,
571
028P).
Terminals:
Brass. Tin-plated. Combination solder and
1
/
4
" Quick-
Connect. Side terminal has .125" diameter hole. Bottom terminal has
.156" x .124" elongated hole.
Ambient Temperature:
– 40°C to +85°C.
Hardware:
571
007,
571
008,
571
027,
571
028,
571
OCC, and
571
RCC, none;
571
007P,
571
008P,
571
027P,
571
028P,
571
OCCP, and
571
RCCP, two O-rings for watertight seal per MIL-PRF-19207.
2 MOUNTING
HOLES FOR
No. 8 SCREWS
ORDERING INFORMATION:
Catalog Number
Standard
Watertight
571
027
571
027P
571
028
571
028P
571
007
571
007P
571
008
571
008P
571
OCC
571
OCCP
571
RCC
571
RCCP
*Fuse diameter is
13
/
32
".
471
* Please refer to Fuseology section for information on
proper fuseholder de-rating.
Bottom
Terminal
Straight
Rt. Angle
Straight
Rt. Angle
Straight
Rt. Angle
Fuse Length
Range*
1
5
/
16
" – 1
3
/
8
"
1
13
/
32
" – 1
1
/
2
"
1
1
/
2
"
w w w. l i t t e l f u s e . c o m
