Type 3 surge protection plug - PT 2-PE/S-120AC-ST - 2839334
Please be informed that the data shown in this PDF Document is generated from our Online Catalog. Please find the complete data in the user's
documentation. Our General Terms of Use for Downloads are valid
(http://phoenixcontact.com/download)
Protective plug PT with surge voltage equipment protection for power supply units, visual fault warning. Nominal
voltage: 120 V AC
The illustration shows version PT 2-
PE/S-230AC-ST
Product Features
■
■
■
Plugs can be checked with CHECKMASTER
Tool-free plug replacement
Optical signaling of disconnection via LED
Key Commercial Data
Packing unit
Weight per Piece (excluding packing)
Custom tariff number
Country of origin
1 pc
26.36 g
85363090
Germany
Technical data
Dimensions
Height
Width
Depth
Horizontal pitch
Complete module height
Complete module width
Complete module depth
45 mm
17.7 mm
52 mm
1 Div.
90 mm
17.7 mm
65.5 mm
Ambient conditions
04/18/2016 Page 1 / 6
https://www.phoenixcontact.com/us/products/2839334
Type 3 surge protection plug - PT 2-PE/S-120AC-ST - 2839334
Technical data
Ambient conditions
Degree of protection
Ambient temperature (operation)
IP20
-40 °C ... 85 °C (non-Ex)
-40 °C ... 80 °C (Class I Div. 2 Gr. A, B, C, D)
General
Housing material
Flammability rating according to UL 94
Color
Standards for cearances and creepage distances
Overvoltage category
Degree of pollution
Type
Mounting type
Number of positions
Arrester can be tested with CHECKMASTER from software version:
Direction of action
PA 6.6
V0
black
DIN VDE 0110-1
IEC 60664-1
III
2
DIN rail module, two-section, divisible
On base element
2
From SW rev. 1.00
1L-N & N-PE
Protective circuit
IEC test classification
EN type
Nominal voltage U
N
Arrester rated voltage U
C
Nominal frequency f
N
Nominal current I
N
Operating effective current I
C
at U
C
Standby power consumption P
C
Residual current I
PE
Nominal discharge current I
n
(8/20) µs
Combination wave U
OC
Voltage protection level U
p
(L-N)
Voltage protection level U
p
(L-PE)
Voltage protection level U
p
(N-PE)
Residual voltage at In, (L-N)
Residual voltage at In, (L-PE)
III
T3
T3
120 V AC
150 V AC
50 Hz
60 Hz
26 A (30 °C)
≤ 1.1 mA
≤ 200 mVA
≤ 2 µA
2.5 kA
3 kA (in acc. with UL 1449)
6 kV
≤ 620 V
≤ 850 V
≤ 850 V
≤ 620 V
≤ 330 V
04/18/2016 Page 2 / 6
https://www.phoenixcontact.com/us/products/2839334
Type 3 surge protection plug - PT 2-PE/S-120AC-ST - 2839334
Technical data
Protective circuit
Residual voltage at In, (N-PE)
Response time t
A
(L-N)
Response time t
A
(L-PE)
Response time t
A
(N-PE)
Max. required back-up fuse
Short-circuit resistance I
P
with max. backup fuse (effective)
Surge protection fault message
≤ 330 V
≤ 25 ns
≤ 100 ns
≤ 100 ns
25 A (gL)
25 A (MCB 25 A B/C)
1.5 kA
Optical, remote indicator contact
Standards and Regulations
Standards/specifications
IEC 61643-1 2005
EN 61643-11/A11 2007
UL 1449 ed. 2
Classifications
eCl@ss
eCl@ss 4.0
eCl@ss 4.1
eCl@ss 5.0
eCl@ss 5.1
eCl@ss 6.0
eCl@ss 7.0
eCl@ss 8.0
eCl@ss 9.0
27140201
27130801
27130801
27130801
27130806
27130806
27130806
27130806
ETIM
ETIM 2.0
ETIM 3.0
ETIM 4.0
ETIM 5.0
EC000942
EC000942
EC000942
EC000942
UNSPSC
UNSPSC 6.01
UNSPSC 7.0901
UNSPSC 11
UNSPSC 12.01
UNSPSC 13.2
30212010
39121610
39121610
39121610
39121620
04/18/2016 Page 3 / 6
https://www.phoenixcontact.com/us/products/2839334
Type 3 surge protection plug - PT 2-PE/S-120AC-ST - 2839334
Accessories
Accessories
Device marking
Zack marker strip - ZBN 18:UNBEDRUCKT - 2809128
Zack marker strip, Strip, white, unlabeled, can be labeled with: Plotter, Mounting type: Snap into tall marker groove, for
terminal block width: 18 mm, Lettering field: 18 x 5 mm
Labeled terminal marker
Zack Marker strip, flat - ZBF 5,LGS:FORTL.ZAHLEN - 0808671
Zack Marker strip, flat, Strip, white, labeled, Printed horizontally: Consecutive numbers 1 - 10, 11 - 20, etc. up to 491 -
500, Mounting type: Snap into flat marker groove, for terminal block width: 5 mm, Lettering field: 5.15 x 5.15 mm
Zack Marker strip, flat - ZBF 5,LGS:GERADE ZAHLEN - 0810821
Zack Marker strip, flat, Strip, white, labeled, Printed horizontally: Consecutive numbers 2 - 20, 22 - 40, etc. up to 82 - 100,
Mounting type: Snap into flat marker groove, for terminal block width: 5 mm, Lettering field: 5.15 x 5.15 mm
Zack Marker strip, flat - ZBF 5,LGS:UNGERADE ZAHLEN - 0810863
Zack Marker strip, flat, Strip, white, labeled, Printed horizontally: Odd numbers 1 - 19, 21 - 39, etc. up to 81 - 99,
Mounting type: Snap into flat marker groove, for terminal block width: 5 mm, Lettering field: 5.15 x 5.15 mm
04/18/2016 Page 4 / 6
https://www.phoenixcontact.com/us/products/2839334
Type 3 surge protection plug - PT 2-PE/S-120AC-ST - 2839334
Accessories
Zack Marker strip, flat - ZBF 5,QR:FORTL.ZAHLEN - 0808697
Zack Marker strip, flat, Strip, white, labeled, Printed vertically: Consecutive numbers 1 - 10, 11 - 20, etc. up to 91 - 100,
Mounting type: Snap into flat marker groove, for terminal block width: 5 mm, Lettering field: 5.15 x 5.15 mm
Marker pen
Marker pen - X-PEN 0,35 - 0811228
Marker pen without ink cartridge, for manual labeling of markers, labeling extremely wipe-proof, line thickness 0.35 mm
Terminal marking
Zack Marker strip, flat - ZBF 5:UNBEDRUCKT - 0808642
Zack Marker strip, flat, Strip, white, unlabeled, can be labeled with: Plotter, Mounting type: Snap into flat marker groove,
for terminal block width: 5 mm, Lettering field: 5.1 x 5.2 mm
Zack Marker strip, flat - ZBF 5/WH-100:UNBEDRUCKT - 0808668
Zack Marker strip, flat, Strip, white, unlabeled, can be labeled with: Plotter, Mounting type: Snap into flat marker groove,
for terminal block width: 5 mm, Lettering field: 5.15 x 5.15 mm
Required add-on products
04/18/2016 Page 5 / 6
