SMD ESD Protection Diode
SMD Diodes Specialist
CPDQR5V0
Features
(RoHS Device)
Bi-directional ESD protection.
(16kV) IEC 61000-4-2 rating.
Surface mount package.
Ultra small SMD package:0402.
High component density.
0402(1005)
0.041(1.05)
0.037(0.95)
Mechanical data
Case: 0402(1005) standard package,
molded plastic.
Terminals: Gold plated, solderable per
MIL-STD-750,method 2026.
Marking Code:
CPDQR5V0: E5
Mounting position: Any.
Weight: 0.001 gram(approx.).
0.026(0.65)
0.022(0.55)
0.022(0.55)
0.018(0.45)
0.012(0.30) Typ.
0.020(0.50) Typ.
Dimensions in inches and (millimeter)
Electrical Characteristics
(at T
A
=25 C unless otherwise noted)
O
Parameter
Diode breakdown voltage
Leakage current
Junction capacitance
ESD capability
Clamping voltage
Peak pulse power
Operation temperature
Storage temperature
Conditions
I
R
= 1mA
V
R
= 5V
V
R
=0V,f =1MHz
IEC 61000-4-2(air)
IEC 61000-4-2(contact)
I
PP
= 5A,T
P
=8/20us
T
P
=8/20us
Symbol Min Typ Max Unit
V
BD
I
L
C
T
ESD
V
C
P
PP
T
j
T
STG
-55
5.1
7.0
0.1
15
2.0
20
V
uA
pF
kV
V
W
O
16
8
15
75
125
150
C
C
O
REV:D
QW-A7013
Page 1
Comchip Technology CO., LTD.
SMD ESD Protection Diode
SMD Diodes Specialist
RATING AND CHARACTERISTIC CURVES (CPDQR5V0)
Fig. 1 - 8/20us Peak pulse current wave
form acc. IEC 61000-4-5
100%
10u
8 us to 100%
Fig. 2 - Reverse characteristics
80%
Reverse current ( A )
20
30
40
1u
60%
I
PPM
20 us to 50us
40%
100n
20%
0%
0
10
10n
0
20
40
60
80
100
Time (us)
Reverse voltage (%)
Fig. 3 - Capacitance between
terminals characteristics
15
Fig. 4 - Power rating derating curve
Capacitance between terminals (
P
F)
Mounting on glass epoxy PCBs
CPDQR5V0
12
100
Power rating (%)
80
9
60
6
40
3
20
0
0
10
20
30
40
0
25
50
75
100
125
150
Reverse voltage (V)
Ambient temperature (
O
C)
REV:D
QW-A7013
Page 2
Comchip Technology CO., LTD.
SMD ESD Protection Diode
SMD Diodes Specialist
Reel Taping Specification
P
0
P
1
d
Index hole
E
T
F
B
Polarity
W
C
P
A
12
0
o
D
2
D
1
D
W
1
Trailer
.......
.......
10 pitches (min)
Device
.......
.......
.......
.......
Leader
.......
.......
10 pitches (min)
End
Start
Direction of Feed
SYMBOL
A
0.75 ± 0.10
0.026
±
0.004
B
1.15 ± 0.10
0.045
±
0.004
C
0.60 ± 0.10
0.024
±
0.004
d
1.55 ± 0.10
0.061
±
0.004
D
178 ± 1
7.008
±
0.04
D
1
60.0 MIN.
2.362 MIN.
D
2
13.0 ± 0.20
0.512
±
0.008
QR/0402
(mm)
(inch)
SYMBOL
E
1.75 ± 0.10
0.069
±
0.004
F
3.50 ± 0.05
0.138
±
0.002
P
4.00 ± 0.10
0.157
±
0.004
P
0
4.00 ± 0.10
0.157
±
0.004
P
1
2.00 ± 0.10
0.079
±
0.004
T
0.22 ± 0.05
0.009
±
0.002
W
8.00 ± 0.20
0.315
±
0.008
W
1
13.5 MAX.
0.531 MAX.
QR/0402
(mm)
(inch)
REV:D
QW-A7013
Page 3
Comchip Technology CO., LTD.
SMD ESD Protection Diode
SMD Diodes Specialist
Marking Code
Part Number
CPDQR5V0
Marking Code
E5
xx
xx = Product type marking code
Suggested PAD Layout
QR/0402
SIZE
(mm)
A
B
C
D
E
0.750
0.500
0.700
1.250
0.250
(inch)
0.030
0.020
C
D
A
E
0.028
0.049
0.010
B
Standard Package
Qty per Reel
Case Type
(Pcs)
QR/0402
5000
Reel Size
(inch)
7
REV:D
QW-A7013
Page 4
Comchip Technology CO., LTD.
