S:\part\s8\80\807-1913OF3.prt
807-191
REVISIONS
TABLE IV
ALTERNATE KEY AND
KEYWAY POSITION
POSITION
A
B
C
D
A°
150°
75°
95°
140°
B°
210°
210°
230°
275°
SYM.
SEE SHEET 1
DESCRIPTION
DATE
APPROVED
B° A°
ALTERNATE POSITION
KEY ROTATION
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONS
DECIMALS
ANGLES
+ 1/16
-
+ .030
.XX
-
.XXX + .015
-
+ 1
-
DRAWN
CHECK
ENGR
R L
GSB
05/13/04
05/13/04
1211 AIR WAY - GLENDALE - CALIFORNIA 91201
CAD 2000
C
APPROVED
CONNECTOR PLUG, PUSH/PULL TYPE.
#23 CONTACTS, CRIMP REAR RELEASE
SHELL SIZE 5-15
CODE IDENT. NO.
SIZE
APPROVED
RELEASE DATE
ORIGINAL
RELEASE DATE
DO NOT SCALE THIS DRAWING
06324
SCALE
N/A
C
WEIGHT
807-191
N/A
SHEET
REV.
B
3 OF 3
B/F 04-3857
P/C 807
NON REPARABLE COMMERCIAL ITEM
1 of 1
S:\part\s8\80\807-1911OF3.prt
807-191
TABLE I
CLASS
C
M
ALUMINUM
NF
ZN
Z1
STAINLESS STEEL
SHELL MATERIAL
FINISH DESCRIPTION
BLACK ANODIZE FINISH
ELECTROLESS NICKEL FINISH
OLIVE DRAB CADMINUM OVER
ELECTROLESS NICKEL FINISH
ZINC-NICKEL/O. D. OVER
ELECTROLESS NICKEL
PASSIVATE
.060
.950 MAX
.561
8
MASTER
KEY
REVISIONS
SYM.
DESCRIPTION
DATE
APPROVED
A
B
RELEASED
REVISED PER DCN 24511
03/16/05 GSB
08/24/05 GSB
1
4
3
7
12
16
ø B
ø C
ø D
8
13
17
19
6
A THREAD
10. FOR BACKSHELL TERMINATION, REFERENCE GLENAIR
HOLDING TOOL 607-004.
9. THIS PUSH/PULL PLUG REQUIRES 10 ±4 POUNDS
TO FULLY DISENGAGE CONNECTOR.
8
RED STRIPE INDICATOR FOR ALLIGNMENT DURING MATING.
L-3 COMM APPLICATION
NO CHANGES PERMITTED
UNLESS APPROVED BY
L-3 COMM
7. GLENAIR SERIES OF 807-191 PLUG CONNECTOR IS DESIGNED TO MATE WITH
GLENAIR SERIES OF 807-192, OR 807-211 RECEPTACLE CONNECTOR.
6
INSERT ARRANGEMENT SHOWN IS FOR REFERENCE ONLY, SEE TABLE III.
TOOL DATA (23 GA):
CRIMP FRAME: M22520/2-01
POSITIONER FOR USE WITH CRIMP FRAME: GLENAIR PART NO. 809-005.
INSERTION TOOL: GLENAIR PART NO. 809-006 (METAL TWEEZERS TYPE TOOL).
EXTRACTION TOOL: GLENAIR PART NO. 809-007 (METAL TWEEZERS TYPE TOOL).
CRIMP BARREL ACCOMMODATES 22, 24, 26 AND 28 GAGE WIRE.
5. CRIMP
a)
b)
c)
d)
4. 23 GA
3. THE CONTACTS ARE SIZE 23 CRIMP TYPE, AND ARE USED IN A
REAR RELEASE RETENTION SYSTEM. (EXCEPT FOR 9-4 ARRANGEMENT)
2. MATERIAL / FINISH:
SHELL - AL ALLOY OR CRES/SEE TABLE I.
INSULATORS - HIGH GRADE RIGID DIELECTRIC/N.A.
INTERFACIAL SEAL/GROMET SEAL - FLUOROSILICONE.
CONTACT- COPPER ALLOY / GOLD PLATE PER ASTM B 488, TYPE 3,
CLASS 1.25 (.00005 MIN THK), OVER A SUITABLE UNDERPLATE.
1. ASSEMBLY TO BE IDENTIFIED WITH GLENAIR'S NAME PART NUMBER
AND DATE CODE SPACE PERMITTING.
DRAWN
CHECK
ENGR
R L
JLT
05/13/04
05/13/04
1211 AIR WAY - GLENDALE - CALIFORNIA 91201
CAD 1997
C
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONS
DECIMALS
ANGLES
+ 1/16
-
+.030
.XX
-
.XXX +.015
-
+ 1
-
APPROVED
CONNECTOR PLUG, PUSH/PULL TYPE.
#23 CONTACTS, CRIMP REAR RELEASE
SHELL SIZE 5-15
CODE IDENT. NO.
SIZE
APPROVED
RELEASE DATE
ORIGINAL
RELEASE DATE
NOTES: UNLESS OTHERWISE SPECIFIED
DO NOT SCALE THIS DRAWING
06324
SCALE
N/A
C
807-191
N/A
SHEET
REV.
B
1 OF 3
B/F
04-3857
P/C 807
NON REPARABLE COMMERCIAL ITEM
WEIGHT
1 of 1
S:\part\s8\80\807-1912OF3.prt
807-191
TABLE II
DIMENSIONS
SHELL
SIZE
5
6
7
9
12
14
15
A THREAD
.2500-32 UNEF-2A
.3125-32 UNEF-2A
.4375-28 UNEF-2A
.5625-24 UNEF-2A
.6875-24 UNEF-2A
.9375-20 UNEF-2A
.9375-20 UNEF-2A
ø B
.220
.285
.350
.455
.645
.770
.830
ø C
.255
.315
.380
.485
.680
.800
.860
ø D,MAX
.440
.490
.570
.665
.860
.980
1.040
12
14
15
7
9
9-4
12-37
14-55
15-85
16
23
23
23
4
37
55
85
3
3
7
10
8
1
4
7
12
16
19
13
17
1
4
8
9 4
15
22
28
33
37
ARRANGEMENT NO. 9-19
PIN FACE SHOWN
(SOCKET FACE OPPOSITE)
1
5
10
16
23
29
34
TABLE III
INSERT ARRANGEMENT
SHELL
SIZE
ARR NO.
5-3
6-4
6
6-7
7-10
9-19
23
23
23
7
10
19
ARRANGEMENT NO. 9-4
PIN FACE SHOWN
(SOCKET FACE OPPOSITE)
1
2
3
REVISIONS
SYM.
SEE SHEET 1
DESCRIPTION
DATE
APPROVED
CONTACT
SIZE
23
23
CONTACT
QTY
3
3
1
4
10
17
25
32
40
52
55
53
47
19
28
38
47
57
66
74
81
85
82
4
9
16
24
39
46
11
1
5
12
20
29
39
48
58
67
75
5
4
4
ARRANGEMENT NO. 14-55
PIN FACE SHOWN
(SOCKET FACE OPPOSITE)
ARRANGEMENT NO. 15-85
PIN FACE SHOWN
(SOCKET FACE OPPOSITE)
PART NUMBER DEVELOPMENT
EXAMPLE:
CONNECTOR SERIES
SHELL STYLE
06 = PLUG
CLASS
(SEE TABLE I)
SHELL SIZE/INSERT ARRANGEMENT NO.
( SEE TABLE III)
CONTACT STYLE
S = SOCKET
P = PIN
KEY POSITION
A,B,C,D (SEE TABLE IV)
ADAPTER
A = MOLDING ADAPTER
B = MOLDING, BANDING ADAPTER
(OMIT FOR NONE)
ARRANGEMENT NO. 7-10
PIN FACE SHOWN
(SOCKET FACE OPPOSITE)
807-191 - 06 Z 9-19
S A A
A
B
ARRANGEMENT NO. 12-37
PIN FACE SHOWN
(SOCKET FACE OPPOSITE)
1
4
2
3
1
6
5
7
2
3
4
C
ARRANGEMENT NO. 5-3
PIN FACE SHOWN
(SOCKET FACE OPPOSITE)
ARRANGEMENT NO. 6-4
PIN FACE SHOWN
(SOCKET FACE OPPOSITE)
ARRANGEMENT NO. 6-7
PIN FACE SHOWN
(SOCKET FACE OPPOSITE)
DRAWN
UNLESS OTHERWISE SPECIFIED
CHECK
ENGR
R L
GSB
05/13/04
05/13/04
C
CAD 1997
DIMENSIONS ARE IN INCHES
TOLERANCES:
FRACTIONS
DECIMALS
ANGLES
+ 1/16
-
+ .010
.XX
-
.XXX + .005
-
+ 1
-
1211 AIR WAY - GLENDALE - CALIFORNIA 91201
APPROVED
CONNECTOR PLUG, PUSH/PULL TYPE.
#23 CONTACTS, CRIMP REAR RELEASE
SHELL SIZE 5-15
CODE IDENT. NO.
SIZE
APPROVED
RELEASE DATE
ORIGINAL
RELEASE DATE
DO NOT SCALE THIS DRAWING
06324
SCALE
N/A
C
807-191
N/A
SHEET
REV.
B
2 OF 3
B/F
04-3857
P/C 807
NON REPARABLE COMMERCIAL ITEM
WEIGHT
1 of 1
