thick film 0.25%, 0.5%, 1% tolerance, 50ppm/°C
chip resistor
EU
features
•
High precision resistor with T.C.R. of
±50 ppm/°C and tolerance of ±0.25%, ±0.5% or ±1%
•
Marking: 1H, 1E: no marking on black protective coating
1J: no marking for E-96, white 3-digits for E-24,
on dark blue protective coating
2A, 2B: white 4-digit on dark blue protective coating
•
Products with lead-free terminations meet EU RoHS
requirements. EU RoHS regulation is not intended for
Pb-glass contained in electrode, resistor element and glass.
•
AEC-Q200 Qualified: 0201 (1H), 0402 (1E), 0603 (1J),
0805 (2A), 1206 (2B)
dimensions and construction
c
L
c
Type
(Inch Size Code)
L
Dimensions
inches
(mm)
W
c
d
t
W
Solder
Plating
t
d
Protective
Coating
Resistive Inner
Film
Electrode
Ni
Plating
1H
(0201)
1E
(0402)
1J
(0603)
2A
(0805)
2B
(1206)
.024±.001 .012±.001 .004±.002 .006±.002 .009±.001
(0.6±0.03) (0.3±0.03) (0.1±0.05) (0.15±0.05) (0.23±0.03)
.039
(1.0
+.004
-.002
+0.1
)
-0.05
+.002
.02±.002 .008±.004 .01
-.004
.014±.002
(0.5±0.05) (0.2±0.1) (0.25
+0.05
) (0.35±0.05)
-0.1
.063±.008 .031±.004 .012±.004 .012±.004 .018±.004
(1.6±0.2)
(0.8±0.1)
(0.3±0.1) (0.45±0.1)
(0.3±0.1)
.079±.008 .049±.004 .016±.008
(2.0±0.2) (1.25±0.1) (0.4±0.2)
.126±.008 .063±.008
(3.2±0.2)
(1.6±0.2)
.02±.012
(0.5±0.3)
.012
(0.3
.016
(0.4
+.008
-.004
+0.2
)
-0.1
+.008
-.004
+0.2
-0.1
)
Ceramic
Substrate
.02±.004
(0.5±0.1)
.024±.004
(0.6±0.1)
ordering information
New Part #
RK73G
Type
1J
Size
1H
1E
1J
2A
2B
T
Termination
Material
T: Sn
(1H, 1E, 1J,
2A, 2B)
L: SnPb
(1E, 1J, 2A, 2B)
TD
Packaging
TA: 0201 only: 1mm pitch pressed paper
TC: 0201 only: 7" 2mm pitch pressed paper
(TC: 10,000 pcs/reel, TCM: 15,000 pcs/reel)
TPL: 0402 only: 2mm pitch punch paper
TP: 0402, 0603, 0805: 7" 2mm pitch
punch paper
TD: 0603, 0805, 1206: 7" 4mm pitch
punched paper
TDD: 0603, 0805, 1206: 10" paper tape
TE: 0805, 1206: 7" embossed plastic
TED: 0805, 1206: 10" embossed plastic
For further information on packaging,
please refer to Appendix A
1003
Nominal
Resistance
3 significant
figures +
1 multiplier
“R” indicates
decimal on
value <100Ω
F
Tolerance
New
C: ±0.25%
D: ±0.5%
F: ±1%
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
10/12/16
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
17
resistors
RK73G
RK73G
thick film 0.25%, 0.5%, 1% tolerance, 50ppm/°C
chip resistor
applications and ratings
Part
Designation*
RK73G1H
(0201)
RK73G1E
(0402)
RK73G1J
(0603)
RK73G2A
(0805)
RK73G2B
(1206)
Power
Rating
1/20W (.05W)
1/10W (.10W)
1/10W (.10W)
1/8W (.125W)
1/4W (.25W)
70°C
125°C
±50
100Ω - 1MΩ
10Ω - 1MΩ
10Ω - 1MΩ
150V
200V
200V
400V
Rated
Ambient
Temp.
T.C.R.
Rated
Terminal (ppm/°C)
Max.
Part Temp.
––
New
E-24, E-96
(C±0.25%)
––
Resistance Range
E-24, E-96
(D±0.5%)
E-24, E-96
(F±1%)
Absolute Absolute
Maximum Maximum
Working Overload
Voltage
Voltage
25V
50V
75V
50V
100V
150V
% Rated Power
60
40
20
0
-60 -40
-55
1H, 1E, 1J
, 2A, 2B
% Rated Power
resistors
100Ω - 1MΩ** 100Ω - 1MΩ**
Operating Temperature Range: -55°C ~ +155°C
* Parentheses indicate EIA package size codes.
** RK73G1H available in E-24 decade values only
Derating Curve
100
80
100
80
60
40
20
0
-60 -40
-55
-20
0
80
70
Ambient Temperature
(°C)
20
40
60
100 120
140
155
-20
0
20
40
60
80
100 120
140
125
155
Terminal Part Temperature
(°C)
For resistors operated at an ambient temperature of 70°C
or above, a power rating shall be derated in accordance
with the derating curve.
For resistors operated terminal part temperature of described for each size
or above, a power rating shall be derated in accordance with derating curve.
Please refer to “Introduction of the derating curves based on the terminal
part temperature” in the beginning of our catalog before use.
environmental applications
Performance Characteristics
Parameter
Resistance
T.C.R.
Overload (Short time)
Resistance to Solder Heat
Rapid Change of Temperature
Moisture Resistance
Endurance at 70°C
High Temperature Exposure
Requirement
∆
R ±(%+0.1Ω)
Limit
Typical
Within specified
—
tolerance
Within specified
—
T.C.R.
±2%
±1%
±0.5%
±2%: 1J, 2A, 2B
±3%: 1H, 1E
±2%: 1J, 2A, 2B
±3%: 1H, 1E
±1%
±0.6%
Test Method
25°C
1H: +25°C/+125°C, 1E, 1J, 2A, 2B: +25°C/-55°C and +25°C/+125°C
Rated Voltage x 2.5 for 5 seconds
(1E, 2B: Rated Voltage x 2 for 5 seconds)
±1%: 1H, ±0.4%:
260°C ± 5°C, 10 seconds ± 1 second
1E, 1J, 2A, 2B
±0.3%
±0.6%: 1J, 2A,
2B; ±1%: 1H, 1E
±0.6%: 1J, 2A,
2B; ±1%: 1H, 1E
±0.6%
-55°C (30 minutes), +125°C (30 minutes), 100 cycles
40°C ± 2°C, 90%-95% RH, 1000 hours, 1.5 hr ON, 0.5 hr OFF cycle
70°C ± 2°C, 1000 hours, 1.5 hr ON, 0.5 hr OFF cycle
+155°C, 1000 hours
For Surface Temperature Rise Graph see Environmental Applications. Additional environmental applications can also be found at www.koaspeer.com
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
6/20/17
18
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
