ICL7109EQH-D datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Analog mixed-signal IC> converter> ICL7109EQH-D

Preview

ICL7109EQH-D: DescriptionAnalog to Digital Converters - ADC 12-Bit A/D Converter with 3-State Binary Outputs; CategoryAnalog mixed-signal IC converter; File Size8MB，20 Pages; ManufacturerMaxim; Websitehttps://www.maximintegrated.com/en.html

Download Datasheet Parametric Compare View All

ICL7109EQH-D Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	ICL7109EQH-D	-	-	View	Buy Now

ICL7109EQH-D Overview

Analog to Digital Converters - ADC 12-Bit A/D Converter with 3-State Binary Outputs

ICL7109EQH-D Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Maxim
Parts packaging code	LCC
package instruction	0.653 INCH, PLASTIC, LCC-44
Contacts	44
Reach Compliance Code	not_compliant
ECCN code	EAR99
Is Samacsys	N
Maximum analog input voltage	3.5 V
Minimum analog input voltage	-3.5 V
Converter type	ADC, DUAL-SLOPE
JESD-30 code	S-PQCC-J44
JESD-609 code	e0
length	16.585 mm
Maximum linear error (EL)	0.0244%
Humidity sensitivity level	1
Nominal negative supply voltage	-5 V
Number of analog input channels	1
Number of digits	12
Number of functions	1
Number of terminals	44
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Output bit code	BINARY
Output format	PARALLEL, WORD
Package body material	PLASTIC/EPOXY
encapsulated code	QCCJ
Encapsulate equivalent code	LDCC44,.7SQ
Package shape	SQUARE
Package form	CHIP CARRIER
Peak Reflow Temperature (Celsius)	240
power supply	+-5 V
Certification status	Not Qualified
Maximum seat height	4.57 mm
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Tin/Lead (Sn85Pb15)
Terminal form	J BEND
Terminal pitch	1.27 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	20
width	16.585 mm
Base Number Matches	1

Preview

Download Datasheet

View All
