IMC0402ER8N7J01 datasheet, PDF

Datasheet> All Categories > Passive components> inductor> IMC0402ER8N7J01

IMC0402ER8N7J01: DescriptionFixed Inductors IMC-0402-01 .0087 5% ER E4; CategoryPassive components inductor; File Size158KB，3 Pages; ManufacturerVishay; Websitehttp://www.vishay.com; Environmental Compliance

Download Datasheet Parametric Compare View All

IMC0402ER8N7J01 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	IMC0402ER8N7J01	-	-	View	Buy Now

IMC0402ER8N7J01 Overview

Fixed Inductors IMC-0402-01 .0087 5% ER E4

IMC0402ER8N7J01 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Vishay
package instruction	0402
Reach Compliance Code	unknown
ECCN code	EAR99
uppercase and lowercase codes	0402
structure	Chip
DC Resistance	0.2 Ω
Nominal inductance(L)	0.0087 µH
Inductor Applications	RF INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
JESD-609 code	e4
Manufacturer's serial number	IMC-0402-01
Number of functions	1
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Package height	0.5 mm
Package length	1 mm
Package form	SMT
Package width	0.55 mm
method of packing	TR, 7 Inch
Minimum quality factor (at nominal inductance)	18
Maximum rated current	0.48 A
self resonant frequency	4100 MHz
series	IMC-0402-01
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
surface mount	YES
Terminal surface	Gold (Au)
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Test frequency	250 MHz
Tolerance	5%

Preview

Download Datasheet

View All

IMC-0402-01

www.vishay.com

Vishay Dale

Wirewound, Surface Mount Inductors

FEATURES

• Excellent solderability and resistance to

soldering heat

• Suitable for reflow soldering

• High reliability and easy surface mount

assembly

• Wide range of inductance values available

• Tape and reel packaging for automatic handling,

10 000/reel EIA 481

• Material categorization: For definitions of compliance

please see

www.vishay.com/doc?99912

STANDARD ELECTRICAL SPECIFICATIONS

IND.

(nH)

TEST

SRF DCR RATED DC

FREQ.

MIN. MAX. CURRENT

(MHz)

(MHz) ()

(mA)

(1)

L & Q MIN.

250

6000 0.045

1360

250

6000 0.070

1040

250

6000 0.070

1040

250

6000 0.070

960

250

6000 0.068

790

250

6000 0.120

640

250

6000 0.066

840

250

6000 0.066

840

250

6000 0.066

840

250

6000 0.091

700

250

4775 0.130

640

250

5800 0.083

800

250

5800 0.083

760

250

5800 0.083

760

250

4800 0.083

680

250

5800 0.104

680

250

4400 0.104

680

250

4100 0.200

480

250

4160 0.104

680

250

4000 0.200

680

250

3900 0.195

480

250

3680 0.120

640

250

3600 0.120

640

250

3450 0.210

560

250

3280 0.172

560

250

3100 0.220

560

250

3100 0.230

420

250

3040 0.202

480

250

3000 0.250

420

250

2800 0.300

400

250

2720 0.214

400

250

2700 0.298

400

250

2480 0.300

400

250

2350 0.300

400

250

2350 0.350

400

250

2320 0.403

320

250

2100 0.550

320

250

2240 0.438

320

250

2030 0.810

100

200

2100 0.830

150

200

1750 0.820

100

200

1760 0.970

100

200

1620 1.120

100

150

1500 1.250

100

150

1300 2.520

100

150

1100 2.660

100

TOL.

1.0 0.3 nH, 0.2 nH

1.9 0.3 nH, 0.2 nH

2.0 0.3 nH, 0.2 nH

2.2 0.3 nH, 0.2 nH

2.4 0.3 nH, 0.2 nH

2.7 0.3 nH, 0.2 nH

3.3 0.3 nH, 0.2 nH

3.6 0.3 nH, 0.2 nH

3.9

10 %, 5 %

4.3

10 %, 5 %

4.7

10 %, 5 %

5.1

10 %, 5 %

5.6

10 %, 5 %

6.2

10 %, 5 %

6.8

10 %, 5 %

7.5

10 %, 5 %

8.2

10 %, 5 %

8.7

10 %, 5 %

9.0

10 %, 5 %

9.5

10 %, 5 %

5 %, 2 %

100

120

Note

(1)

Value obtained when current flows and temperature has risen 15 °C

ELECTRICAL SPECIFICATIONS

Inductance Range:

1 nH to 47 nH

Operating Temperature:

- 40 °C to + 125 °C

Storage Temperature:

- 40 °C to + 125 °C

TEST EQUIPMENT

• Inductance is measured in HP4287A RF LCR meter with

HP16193 fixture

• Q is measured in HP4287A RF LCR meter with HP16193

fixture

• SRF is measured in HP8753E RF network analyzer

• DCR is measured in HP4338B millohmeter

DIMENSIONS

in inches [millimeters]

0.039 ± 0.004

[1.00 ± 0.1]

0.022 ± 0.004

[0.55 ± 0.1]

0.008 ± 0.004

[0.20 ± 0.1]

0.010 ref.

[0.25]

0.020 ± 0.004

[0.50 ± 0.1]

DESCRIPTION

IMC-0402-01

MODEL

10 nH

INDUCTANCE VALUE

±5%

INDUCTANCE TOLERANCE

PACKAGE CODE

JEDEC LEAD (Pb)-FREE STANDARD

GLOBAL PART NUMBER

SIZE

INDUCTANCE

VALUE

TOL.

PRODUCT FAMILY

PACKAGE

CODE

SERIES

Revision: 18-Sep-13

Document Number: 34163

For technical questions, contact:

magnetics@vishay.com

THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT

ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT

www.vishay.com/doc?91000

Legal Disclaimer Notice

www.vishay.com

Vishay

Disclaimer



ALL PRODUCT, PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE

RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE.

Vishay Intertechnology, Inc., its affiliates, agents, and employees, and all persons acting on its or their behalf (collectively,

“Vishay”), disclaim any and all liability for any errors, inaccuracies or incompleteness contained in any datasheet or in any other

disclosure relating to any product.

Vishay makes no warranty, representation or guarantee regarding the suitability of the products for any particular purpose or

the continuing production of any product. To the maximum extent permitted by applicable law, Vishay disclaims (i) any and all

liability arising out of the application or use of any product, (ii) any and all liability, including without limitation special,

consequential or incidental damages, and (iii) any and all implied warranties, including warranties of fitness for particular

purpose, non-infringement and merchantability.

Statements regarding the suitability of products for certain types of applications are based on Vishay’s knowledge of

typical requirements that are often placed on Vishay products in generic applications. Such statements are not binding

statements about the suitability of products for a particular application. It is the customer’s responsibility to validate that a

particular product with the properties described in the product specification is suitable for use in a particular application.

Parameters provided in datasheets and / or specifications may vary in different applications and performance may vary over

time. All operating parameters, including typical parameters, must be validated for each customer application by the customer’s

technical experts. Product specifications do not expand or otherwise modify Vishay’s terms and conditions of purchase,

including but not limited to the warranty expressed therein.

Except as expressly indicated in writing, Vishay products are not designed for use in medical, life-saving, or life-sustaining

applications or for any other application in which the failure of the Vishay product could result in personal injury or death.

Customers using or selling Vishay products not expressly indicated for use in such applications do so at their own risk.

Please contact authorized Vishay personnel to obtain written terms and conditions regarding products designed for

such applications.

No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document

or by any conduct of Vishay. Product names and markings noted herein may be trademarks of their respective owners.

Revision: 08-Feb-17

Document Number: 91000
