5962R9569001V9A amplifier basic information:
5962R9569001V9A is an OPERATIONAL AMPLIFIER. Commonly used packaging methods are DIE, DIE OR CHIP
5962R9569001V9A amplifier core information:
The minimum operating temperature of 5962R9569001V9A is -55 °C and the maximum operating temperature is 125 °C. Its peak reflow temperature is NOT SPECIFIED Its maximum bias current at 25°C is: 1 µA Its maximum average bias current is 0.3 µA
How to simply check the efficiency of an amplifier? Looking at its slew rate, the nominal slew rate of 5962R9569001V9A is 2 V/us. The maximum slew rate of the 5962R9569001V9A given by the manufacturer is 7.5 mA, while the minimum slew rate is 0.5 V/us. Its minimum voltage gain is 40000. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the gain of 5962R9569001V9A becomes 0.707 times the low-frequency gain is 8000 kHz.
The nominal supply voltage of 5962R9569001V9A is 15 V, and its corresponding nominal negative supply voltage is -15 V. The input offset voltage of 5962R9569001V9A is 3000 µV (Input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).)
Related dimensions of 5962R9569001V9A:
5962R9569001V9A has 14 terminals. Its terminal position type is: UPPER. Total pins: 14
5962R9569001V9A amplifier additional information:
5962R9569001V9A adopts the VOLTAGE-FEEDBACK architecture. It does not belong to the low offset class of amplifiers. The frequency compensation status of 5962R9569001V9A is: YES. Its temperature grade is: MILITARY. 5962R9569001V9A does not comply with Rohs certification.
The corresponding JESD-30 code is: R-XUUC-N14. The corresponding JESD-609 code is: e4. The packaging code of 5962R9569001V9A is: DIE. The materials used in the 5962R9569001V9A package are mostly UNSPECIFIED. The package shape is RECTANGULAR.
The 5962R9569001V9A package pin format is: UNCASED CHIP. Its terminal forms are: NO LEAD.
5962R9569001V9A amplifier basic information:
5962R9569001V9A is an OPERATIONAL AMPLIFIER. Commonly used packaging methods are DIE, DIE OR CHIP
5962R9569001V9A amplifier core information:
The minimum operating temperature of 5962R9569001V9A is -55 °C and the maximum operating temperature is 125 °C. Its peak reflow temperature is NOT SPECIFIED Its maximum bias current at 25°C is: 1 µA Its maximum average bias current is 0.3 µA
How to simply check the efficiency of an amplifier? Looking at its slew rate, the nominal slew rate of 5962R9569001V9A is 2 V/us. The maximum slew rate of the 5962R9569001V9A given by the manufacturer is 7.5 mA, while the minimum slew rate is 0.5 V/us. Its minimum voltage gain is 40000. When the op amp is used in closed loop, at a certain closed-loop gain (usually 1 or 2, 10, etc.), the frequency when the gain of 5962R9569001V9A becomes 0.707 times the low-frequency gain is 8000 kHz.
The nominal supply voltage of 5962R9569001V9A is 15 V, and its corresponding nominal negative supply voltage is -15 V. The input offset voltage of 5962R9569001V9A is 3000 µV (Input offset voltage: the compensation voltage added between the two input terminals to make the output terminal of the operational amplifier 0V (or close to 0V).)
Related dimensions of 5962R9569001V9A:
5962R9569001V9A has 14 terminals. Its terminal position type is: UPPER. Total pins: 14
5962R9569001V9A amplifier additional information:
5962R9569001V9A adopts the VOLTAGE-FEEDBACK architecture. It does not belong to the low offset class of amplifiers. The frequency compensation status of 5962R9569001V9A is: YES. Its temperature grade is: MILITARY. 5962R9569001V9A does not comply with Rohs certification.
The corresponding JESD-30 code is: R-XUUC-N14. The corresponding JESD-609 code is: e4. The packaging code of 5962R9569001V9A is: DIE. The materials used in the 5962R9569001V9A package are mostly UNSPECIFIED. The package shape is RECTANGULAR.
The 5962R9569001V9A package pin format is: UNCASED CHIP. Its terminal forms are: NO LEAD.
| Parameter Name | Attribute value |
| Is it Rohs certified? | conform to |
| Maker | Renesas Electronics Corporation |
| Parts packaging code | DIE |
| package instruction | DIE, DIE OR CHIP |
| Contacts | 14 |
| Reach Compliance Code | compliant |
| ECCN code | USML XV(E) |
| Amplifier type | OPERATIONAL AMPLIFIER |
| Architecture | VOLTAGE-FEEDBACK |
| Maximum average bias current (IIB) | 0.3 µA |
| Maximum bias current (IIB) at 25C | 1 µA |
| Nominal Common Mode Rejection Ratio | 80 dB |
| frequency compensation | YES |
| Maximum input offset voltage | 3000 µV |
| JESD-30 code | R-XUUC-N14 |
| JESD-609 code | e4 |
| low-dissonance | NO |
| Negative supply voltage upper limit | -20 V |
| Nominal Negative Supply Voltage (Vsup) | -15 V |
| Number of functions | 4 |
| Number of terminals | 14 |
| Maximum operating temperature | 125 °C |
| Minimum operating temperature | -55 °C |
| Package body material | UNSPECIFIED |
| encapsulated code | DIE |
| Encapsulate equivalent code | DIE OR CHIP |
| Package shape | RECTANGULAR |
| Package form | UNCASED CHIP |
| Peak Reflow Temperature (Celsius) | NOT SPECIFIED |
| power supply | +-15 V |
| Certification status | Not Qualified |
| Filter level | MIL-PRF-38535 Class V |
| minimum slew rate | 0.5 V/us |
| Nominal slew rate | 2 V/us |
| Maximum slew rate | 7.5 mA |
| Supply voltage upper limit | 20 V |
| Nominal supply voltage (Vsup) | 15 V |
| surface mount | YES |
| technology | BIPOLAR |
| Temperature level | MILITARY |
| Terminal surface | Gold (Au) |
| Terminal form | NO LEAD |
| Terminal location | UPPER |
| Maximum time at peak reflow temperature | NOT SPECIFIED |
| total dose | 100k Rad(Si) V |
| Nominal Uniform Gain Bandwidth | 8000 kHz |
| Minimum voltage gain | 40000 |
| Base Number Matches | 1 |
| 5962R9569001V9A | 5962R9569001VCC | |
|---|---|---|
| Description | QUAD OP-AMP, 3000uV OFFSET-MAX, 8MHz BAND WIDTH, UUC14, DIE-14 | QUAD OP-AMP, 5000uV OFFSET-MAX, CDIP14, CERAMIC, DIP-14 |
| Is it Rohs certified? | conform to | conform to |
| Maker | Renesas Electronics Corporation | Renesas Electronics Corporation |
| Parts packaging code | DIE | DIP |
| package instruction | DIE, DIE OR CHIP | DIP, DIP14,.3 |
| Contacts | 14 | 14 |
| Reach Compliance Code | compliant | compli |
| ECCN code | USML XV(E) | EAR99 |
| Amplifier type | OPERATIONAL AMPLIFIER | OPERATIONAL AMPLIFIER |
| Architecture | VOLTAGE-FEEDBACK | VOLTAGE-FEEDBACK |
| Maximum average bias current (IIB) | 0.3 µA | 1 µA |
| Maximum bias current (IIB) at 25C | 1 µA | 1 µA |
| Nominal Common Mode Rejection Ratio | 80 dB | 80 dB |
| frequency compensation | YES | YES |
| Maximum input offset voltage | 3000 µV | 5000 µV |
| JESD-30 code | R-XUUC-N14 | R-GDIP-T14 |
| JESD-609 code | e4 | e4 |
| low-dissonance | NO | NO |
| Negative supply voltage upper limit | -20 V | -20 V |
| Nominal Negative Supply Voltage (Vsup) | -15 V | -15 V |
| Number of functions | 4 | 4 |
| Number of terminals | 14 | 14 |
| Maximum operating temperature | 125 °C | 125 °C |
| Minimum operating temperature | -55 °C | -55 °C |
| Package body material | UNSPECIFIED | CERAMIC, GLASS-SEALED |
| encapsulated code | DIE | DIP |
| Encapsulate equivalent code | DIE OR CHIP | DIP14,.3 |
| Package shape | RECTANGULAR | RECTANGULAR |
| Package form | UNCASED CHIP | IN-LINE |
| Peak Reflow Temperature (Celsius) | NOT SPECIFIED | NOT SPECIFIED |
| power supply | +-15 V | +-15 V |
| Certification status | Not Qualified | Not Qualified |
| Filter level | MIL-PRF-38535 Class V | MIL-PRF-38535 Class V |
| minimum slew rate | 0.5 V/us | 0.5 V/us |
| Nominal slew rate | 2 V/us | 2 V/us |
| Supply voltage upper limit | 20 V | 20 V |
| Nominal supply voltage (Vsup) | 15 V | 15 V |
| surface mount | YES | NO |
| technology | BIPOLAR | BIPOLAR |
| Temperature level | MILITARY | MILITARY |
| Terminal surface | Gold (Au) | Gold (Au) |
| Terminal form | NO LEAD | THROUGH-HOLE |
| Terminal location | UPPER | DUAL |
| Maximum time at peak reflow temperature | NOT SPECIFIED | NOT SPECIFIED |
| total dose | 100k Rad(Si) V | 100k Rad(Si) V |
| Nominal Uniform Gain Bandwidth | 8000 kHz | 8000 kHz |
| Minimum voltage gain | 40000 | 40000 |
