21_N-50-12-40/033_-E datasheet, PDF

Datasheet> All Categories > The connector> The connector> 21_N-50-12-40/033_-E

21_N-50-12-40/033_-E: DescriptionRF N Connector, Female, Cable Mount, Clamp Terminal, Jack, ROHS COMPLIANT; CategoryThe connector The connector; File Size70KB，1 Pages; ManufacturerHUBER+SUHNER

Download Datasheet Parametric View All

21_N-50-12-40/033_-E Overview

RF N Connector, Female, Cable Mount, Clamp Terminal, Jack, ROHS COMPLIANT

21_N-50-12-40/033_-E Parametric

Parameter Name	Attribute value
package instruction	ROHS COMPLIANT
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	STANDARDS: IEC 60169-16; MIL-STD-348A/304, VSWR MAX AT 3GHZ
Body/casing type	JACK
Characteristic impedance	50 Ω
Connector type	RF N CONNECTOR
Contact to complete cooperation	SILVER
Contact completed and terminated	SILVER
Contact point gender	FEMALE
Coupling type	THREADED
DIN compliance	NO
Filter function	NO
IEC compliance	YES
insulator material	PFA/PTFE
JESD-609 code	e4
MIL compliance	YES
Manufacturer's serial number	N
Installation method	STRAIGHT
Installation type	CABLE
Maximum operating frequency	11 GHz
Options	GENERAL PURPOSE
Panel mounting	NO
Termination type	CLAMP
voltage standing wave ratio	13.14
Base Number Matches	1

Preview

Download Datasheet

View All

HUBER+SUHNER

DATA SHEET

Coaxial Cable Connector: 21_N-50-12-40/033_-

Description

Rev.: D.00

Straight cable jack

SMART QUICK-FIT connector

For outdoor applications

Water protection according to IP 68

Technical Data

Electrical Data

Impedance

Interface frequency max.

Frequency range

Return loss

Intermodulation

Ω

11 GHz

DC to 2.5 GHz

2.5 to 3 GHz

≥ 30 dB

≥ 28 dB

≤ -155 dBc (2 x 43 dBm carrier)

plugged

clamped

-40 °C to 85 °C

compliant

Material

Copper Beryllium Alloy

Brass

PFA / PTFE

NR (Natural Rubber)

DOU-00086891.1

DOC-0000243742

21_N-50-12-40/033_-E

SUCOFEED_1/2, Heliax LDF4-50A, NK Cables RF(A) 1/2-50, Cellflex LCF12-50J

IEC 61169-16_MIL-STD-348A/304_CECC 22210

Surface Plating

Silver Plating

SUCOPLATE (R) Plating

Epoxy

Mechanical Data

Centre contact

Outer contact

Environmental Data

Operating Temperature

2002/95/EC (RoHS)

Material Data

Piece Parts

Centre contact

Outer contact

Body

Other body part

Insulator

Gasket
