390195-6 Product Details
Live Product Chat
Product View
Memory Sockets
Not EU R oHS or ELV C om pliant
(
Find R oHS C om pliant Alte rnate s
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
390195-6
T E I nternal N umber: 3 9 0 1 9 5 - 6
Product Highlights:
l
DIMM 2P
l
Gold Flash over Palladium Nickel or Gold (30) over
Nickel C ontact Mating Area Plating Material
l
Number of Positions = 168
l
DRAM Type = Non-Buffered
l
DRAM Voltage = 3.3 V
View all Features
Obsolete
C ontact Product Information C enter
View 3D PDF
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
(C
AD Format & C ompression Information)
l
2D Drawing
(DXF, Version D)
l
3D Model
(IGES, Version D)
l
3D Model
(STEP, Version D)
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = DIMM 2P
l
Number of Positions
= 168
l
DRAM Type
= Non-Buffered
l
PC B Mount Style = Through Hole
l
Module Orientation
= 25°
l
PC B Retention Feature = Yes
l
Profile = Low
Mechanical Attachment:
l
C enter Retention Hole Diameter (mm [in])
= 2.40 [0.094]
Electrical Characteristics:
l
DRAM Voltage
= 3.3 V
Termination Related Features:
l
Termination Post Length (mm [in])
= 2.60 [0.102]
l
Solder Tail C ontact Plating = Tin-Lead over Nickel
Body Related Features:
l
Row-to-Row Spacing (mm [in])
= 1.60 [0.063]
l
C enterline (mm [in])
= 1.27 [0.050]
l
Number of Rows
= Dual
l
Ejector Type = Standard
l
Ejector Location
= Both Ends
l
C enter Post = With
l
Number of Keys
= 2
l
PC B Retention Method = Boardlock(s)
l
Mount Type = Printed C ircuit Board
l
Module Key Type = Key1= Offset Right / Key2= C enter
Contact Related Features:
l
C ontact Mating Area Plating Material = Gold Flash over Palladium
Nickel or Gold (30) over Nickel
l
C ontact Base Material = Phosphor Bronze
l
Retention Post(s) Location
= C enter
Housing Related Features:
l
Housing Material = High Temperature Thermoplastic
l
Housing C olor = Black
l
Housing Flammability Rating = UL 94V-0
Configuration Related Features:
l
Insertion Style
= Direct Insert
l
C enter Key (mm [in]) = C enter
Industry Standards:
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C
Packaging Related Features:
l
Packaging Method = Tray
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
