34404634 Product Details
PCB Mounted Jacks Single Port, Multiport and Stacked
5 of 6 EU RoHS/ELV Compliant
(
Statement of Compliance
)
No Image Available
Share
Print
Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
34404634
TE Internal Number: 34404634
Product Highlights:
Connector
Preloaded
Single Port Configuration
1 x 1 Jack Configuration
Jack Type = RJ45
View all Features
Superseded
Contact Product Information
Center
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
None Available
Catalog Pages/Data Sheets:
None Available
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files:
None Available
Additional Information:
Product Line Information
Related Products:
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Product Type = Connector
Jack Type = RJ45
PCB Mounting Orientation = Side Entry (Right Angle)
PCB Mount Style = Through Hole
Performance Category = Cat 3
LED = With
Grounding Options = Panel Ground and PCB Ground
Panel Stops = Without
Keyed = No
Profile = Standard
Color = Black
Mechanical Attachment:
Panel Mount Retention = With
Flanged = No
Termination Features:
Termination Method to PC Board = Solder
Dimensions:
Height (mm [in]) = 13.25 [0.522]
PCB Tail Length (mm [in]) = 2.62 [0.103]
PCB Thickness, Recommended (mm [in]) = 1.57 [0.062]
Body Features:
Inverted Jack Face = Yes
Shield Plating = TinLead
Shield Material = Copper Alloy
PCB Ground Tab Location (mm [in]) = 3.43 [0.135]
Contact Features:
Solder Tail Contact Plating = TinLead over Nickel
Housing Features:
Housing Material = High Temperature Thermoplastic
Configuration Features:
Preloaded = Yes
Port Configuration = Single
Jack Configuration = 1 x 1
Number of Positions = 8
Shielded = Yes
Number of Contacts Loaded = 8
Number of PCB Ground Tabs = 2
Panel Ground Location = Top and Side
Industry Standards:
RoHS/ELV Compliance = ELV compliant, 5 of 6 Compliant
Lead Free Solder Processes = Wave solder capable to 240°C
UL Flammability Rating = UL 94V0
Identification Marking:
LED Position 1 Color = None
LED Position 2 Color = Green
LED Position 3 Color = None
Packaging Features:
Packaging Method = Tray
Packaging Quantity = 2,500/Box
Product Availability:
Region = Asia, North America
Other:
Brand = AMP
