HF2150/HF2151
MINIATURE HIGH POWER RELAY
Features
*
30A switching capabilities
*
PCB coil terminals, ideal for heavy duty load
File No.:E134517
*
Heavy load up to 7,200VA
*
Sealed IP67 & Unsealed type available
*
Class B, Class F insulation available
File No.:CQC02001001951
CONTACT DATA
Contact
Arrangement
Initial Contact
Resistance
Contact Material
Contact Rating
(Res. Load)
Max. Switching
Capacity
Max. switching
voltage
Max. switching
current
Mechanical life
Electrical life
30A
15A
1A
1B
1C(NO)
1C(NC)
COIL
Coil Power
Coil Voltage
Coil Resistance
DC:
0.9W
5 to 110VDC
See table below
20m (
at rated Load
)
AgCdO
30A 240VAC 15A 240VAC 20A 240VAC 10A 240VAC
20A 30VDC
10A 30VDC
20A 30VDC
10A 30VDC
General Purpose Power Relays HF2150
COIL DATA
Nominal
Voltage
VDC
5
6
9
12
15
18
24
Pick-up
Voltage
VDC
3.75
4.50
6.75
9.00
11.25
13.50
18.00
36.00
52.50
82.50
Drop-out
Voltage
VDC
0.5
0.6
0.9
1.2
1.5
1.8
2.4
4.8
7.0
11.0
Coil Resistance
7200VA
600W
3600VA
300W
4800VA
600W
2400VA
300W
277VAC/30VDC
20A
10A
1 x 10
7
OPS
1 x 10
5
OPS
27
40
97
155
256
380
660
2560
5500
13450
10%
10%
10%
10%
10%
10%
10%
10%
10%
10%
CHARACTERISTICS
Initial Insulation Resistance
Dielectric Between coil and Contacts
Strength Between open contacts
Operate time (at nomi. Volt.)
Release time (at nomi. Volt.)
Ambient temperature
Shock Resistance
Vibration Resistance
Humidity
Termination
Unit weight
Construction
Class B
Class F
Functional
Destructive
-55
-55
1000M , 500VDC
2500VAC 1min.
1500VAC 1min.
Max. 15ms
Max. 10ms
to +100
to +125
98 m/s
2
980 m/s
2
DA: 1.5mm, 10 to 55Hz
98%, +40
PCB
Approx. 35g
Sealed IP67& Unsealed
48
70
110
Note:When
requiring pull-in voltage <75% of nominal voltage, special order allowed.
