IMC0402EB19NJ01 datasheet, PDF

Datasheet> All Categories > Passive components> inductor> IMC0402EB19NJ01

IMC0402EB19NJ01: DescriptionGeneral Fixed Inductor, 1 ELEMENT, 0.019 uH, GENERAL PURPOSE INDUCTOR, SMD; CategoryPassive components inductor; File Size142KB，2 Pages; ManufacturerVishay; Websitehttp://www.vishay.com

Download Datasheet Parametric View All

IMC0402EB19NJ01 Overview

General Fixed Inductor, 1 ELEMENT, 0.019 uH, GENERAL PURPOSE INDUCTOR, SMD

IMC0402EB19NJ01 Parametric

Parameter Name	Attribute value
Maker	Vishay
Reach Compliance Code	unknown
ECCN code	EAR99
DC Resistance	0.202 Ω
Nominal inductance(L)	0.019 µH
Inductor Applications	RF INDUCTOR
Inductor type	GENERAL PURPOSE INDUCTOR
JESD-609 code	e4
Manufacturer's serial number	IMC-0402-01
Number of functions	1
Number of terminals	2
Maximum operating temperature	125 °C
Minimum operating temperature	-40 °C
Minimum quality factor (at nominal inductance)	26
Maximum rated current	0.48 A
self resonant frequency	3040 MHz
Shape/Size Description	RECTANGULAR PACKAGE
shield	NO
surface mount	YES
Terminal surface	GOLD
Terminal location	DUAL ENDED
Terminal shape	WRAPAROUND
Test frequency	250 MHz
Tolerance	5%
Base Number Matches	1

Preview

Download Datasheet

View All

IMC-0402-01

Vishay Dale

Surface Mount Inductor, Wirewound

FEATURES

Excellent solderability and resistance to soldering heat.

Suitable for reflow soldering.

High reliability and easy surface mount assembly.

Wide range of inductance values available.

Tape and reel packaging for automatic handling,

10,000/reel, EIA 481.

•

Lead (Pb)-free construction.

•

STANDARD ELECTRICAL SPECIFICATIONS

IND.

(nH)

1.0

2.0

2.2

3.3

3.6

3.9

5.1

5.6

6.2

7.5

8.2

9.0

10.0

11.0

12.0

15.0

19.0

23.0

27.0

36.0

40.0

47.0

TEST FREQ.

L and Q

(MHz)

250

200

MIN

SELF-

RESONANT

FREQ. MIN.

(MHz)

6000

5800

4400

4160

3900

3680

3600

3280

3040

2720

2480

2320

2240

2100

DCR

MAX.

(Ohms)

0.045

0.070

0.066

0.083

0.104

0.195

0.120

0.172

0.202

0.214

0.298

0.403

0.438

0.830

*RATED

CURRENT

(mA)

1360

1040

960

840

800

760

680

480

640

560

480

400

320

150

ELECTRICAL SPECIFICATIONS

Inductance Range:

1nH to 47nH.

Operating Temperature:

-40°C to +125°C.

Storage Temperature:

-40°C to +125°C.

TOL.

0.3nH, 0.2nH

10%, 5%

5%, 2%

TEST EQUIPMENT

• Inductance is measured in HP-4287A RF LCR

meter with HP-16193 fixture.

• Q is measured in HP-4287A RF LCR meter with

HP-16193 fixture.

• SRF is measured in HP-8753E RF network

analyzer.

• DCR is measured in HP-4338B millohmeter.

DIMENSIONS

in inches [millimeters]

0.039

0.004

[1.00

0.1]

0.022

0.004

[0.55

0.1]

0.008

0.004

[0.20

0.1]

* for a 15°C rise.

DESCRIPTION

IMC-0402-01

MODEL

10nH

INDUCTANCE

VALUE

INDUCTANCE

TOLERANCE

0.010 ref.

[0.25]

0.020

0.004

[0.5

0.1]

SAP PART NUMBERING GUIDELINES (INTERNAL)

SIZE

TOL.

SERIES

PRODUCT FAMILY

PACKAGE

CODE

INDUCTANCE

VALUE

See the end of this data book for conversion tables

www.vishay.com

For technical questions, contact Magnetics@vishay.com

Document Number 34163

Revision 31-Mar-04
