X1G005151034600 datasheet, PDF

Datasheet> All Categories > Passive components> oscillator> X1G005151034600

X1G005151034600: DescriptionClipped Sine Output Oscillator,; CategoryPassive components oscillator; File Size501KB，8 Pages; ManufacturerSeiko Epson Corporation

Download Datasheet Parametric Compare View All

X1G005151034600 Overview

Clipped Sine Output Oscillator,

X1G005151034600 Parametric

Parameter Name	Attribute value
Maker	Seiko Epson Corporation
Reach Compliance Code	unknown
Other features	TR, 13 INCH
Ageing	0.5 PPM/FIRST YEAR
Frequency Adjustment - Mechanical	NO
frequency stability	0.5%
Installation features	SURFACE MOUNT
Nominal operating frequency	16.8 MHz
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Oscillator type	CLIPPED SINE
Output impedance	11000 Ω
Output level	0.8 V
physical size	2.5mm x 2.0mm x 0.8mm
Maximum supply voltage	3.63 V
Minimum supply voltage	1.7 V
surface mount	YES
Base Number Matches	1

Preview

Download Datasheet

View All

Temperature Compensated Crystal Oscillator (TCXO)

Data sheet

MODEL

：

TG2520SBN 16.800000 MHz TCGNNM

Product. No.

：

X1G0051510346xx

Please refer to the 10.Packing information about xx (last 2 digits)

SEIKO EPSON CORPORATION

Pb free.

Complies with EU RoHS directive.

*About the products without the Pb-free mark.

Contains Pb in products exempted by EU RoHS directive.

(Contains Pb in sealing glass, high melting temperature type solder or other.)

INTRODUCTION

1. Any part of this material may not be reproduced or duplicated in any form or any means without the

written permission of Seiko Epson.

2. This sheet is not intended to guarantee or provide an approval of implementation of industrial patents.

X1G005151034600 Related Products

	X1G005151034600	X1G005151034601	X1G005151034614	HS534180F25IER	X1G005151034611	X1G005151034612
Description	Clipped Sine Output Oscillator,	Clipped Sine Output Oscillator,	Clipped Sine Output Oscillator,	Parallel - Fundamental Quartz Crystal, 18MHz Nom,	Clipped Sine Output Oscillator,	Clipped Sine Output Oscillator,
Reach Compliance Code	unknown	unknown	unknown	compliant	unknown	unknown
Other features	TR, 13 INCH	TAPE	TR, 13 INCH	AT-CUT; TR, 7 INCH	TR, 13 INCH	TR, 13 INCH
Ageing	0.5 PPM/FIRST YEAR	0.5 PPM/FIRST YEAR	0.5 PPM/FIRST YEAR	5 PPM/YEAR	0.5 PPM/FIRST YEAR	0.5 PPM/FIRST YEAR
frequency stability	0.5%	0.5%	0.5%	0.005%	0.5%	0.5%
Installation features	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT
Nominal operating frequency	16.8 MHz	16.8 MHz	16.8 MHz	18 MHz	16.8 MHz	16.8 MHz
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
physical size	2.5mm x 2.0mm x 0.8mm	2.5mm x 2.0mm x 0.8mm	2.5mm x 2.0mm x 0.8mm	L5.0XB3.2XH0.7 (mm)/L0.197XB0.126XH0.028 (inch)	2.5mm x 2.0mm x 0.8mm	2.5mm x 2.0mm x 0.8mm
surface mount	YES	YES	YES	YES	YES	YES
Maker	Seiko Epson Corporation	Seiko Epson Corporation	Seiko Epson Corporation	-	Seiko Epson Corporation	Seiko Epson Corporation
Frequency Adjustment - Mechanical	NO	NO	NO	-	NO	NO
Oscillator type	CLIPPED SINE	CLIPPED SINE	CLIPPED SINE	-	CLIPPED SINE	CLIPPED SINE
Output impedance	11000 Ω	11000 Ω	11000 Ω	-	11000 Ω	11000 Ω
Output level	0.8 V	0.8 V	0.8 V	-	0.8 V	0.8 V
Maximum supply voltage	3.63 V	3.63 V	3.63 V	-	3.63 V	3.63 V
Minimum supply voltage	1.7 V	1.7 V	1.7 V	-	1.7 V	1.7 V
