ISPLSI1024-60LT datasheet, PDF

Datasheet> All Categories > Programmable logic devices> Programmable logic> ISPLSI1024-60LT

ISPLSI1024-60LT: DescriptionEE PLD, 25ns, 96-Cell, CMOS, PQFP100, TQFP-100; CategoryProgrammable logic devices Programmable logic; File Size394KB，14 Pages; ManufacturerLattice; Websitehttp://www.latticesemi.com

Download Datasheet Parametric Compare View All

ISPLSI1024-60LT Overview

EE PLD, 25ns, 96-Cell, CMOS, PQFP100, TQFP-100

ISPLSI1024-60LT Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Lattice
Parts packaging code	QFP
package instruction	TQFP-100
Contacts	100
Reach Compliance Code	not_compliant
ECCN code	EAR99
Other features	IN-SYSTEM PROGRAMMABLE; 4 EXTERNAL CLOCKS
maximum clock frequency	38 MHz
In-system programmable	YES
JESD-30 code	S-PQFP-G100
JESD-609 code	e0
JTAG BST	NO
length	14 mm
Humidity sensitivity level	3
Dedicated input times	2
Number of I/O lines	48
Number of macro cells	96
Number of terminals	100
Maximum operating temperature	70 °C
Minimum operating temperature
organize	2 DEDICATED INPUTS, 48 I/O
Output function	MACROCELL
Package body material	PLASTIC/EPOXY
encapsulated code	LFQFP
Encapsulate equivalent code	QFP100,.63SQ,20
Package shape	SQUARE
Package form	FLATPACK
Peak Reflow Temperature (Celsius)	240
power supply	5 V
Programmable logic type	EE PLD
propagation delay	25 ns
Certification status	Not Qualified
Maximum seat height	1.6 mm
Maximum supply voltage	5.25 V
Minimum supply voltage	4.75 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	30
width	14 mm
Base Number Matches	1

Preview

Download Datasheet

View All

ispLSI

1024 Device Datasheet

June 2010

All Devices Discontinued!

Product Change Notification (PCN) #09-10 has been issued to discontinue all devices in

this data sheet.

The original datasheet pages have not been modified and do not reflect those changes.

Please refer to the table below for reference PCN and current product status.

Product Line

ispLSI 1024

Ordering Part Number

ispLSI 1024-60LJ

ispLSI 1024-80LJ

ispLSI 1024-90LJ

ispLSI 1024-60LJI

ispLSI 1024-60LT

ispLSI 1024-80LT

ispLSI 1024-90LT

ispLSI 1024-60LTI

Product Status

Reference PCN

Discontinued

PCN#09-10

5555 N.E. Moore Ct.

Hillsboro, Oregon 97124-6421 Phone (503) 268-8000

Internet: http://www.latticesemi.com

FAX (503) 268-8347

ISPLSI1024-60LT Related Products

	ISPLSI1024-60LT	ISPLSI 1024-60LJ	ISPLSI 1024-90LJ	ISPLSI1024-90LT	ISPLSI1024-80LT	ISPLSI1024-60LTI	ISPLSI1024-80LJ
Description	EE PLD, 25ns, 96-Cell, CMOS, PQFP100, TQFP-100	IC cpld 64mc 20ns 68plcc	IC cpld 64mc 12ns 68plcc	EE PLD, 17ns, 96-Cell, CMOS, PQFP100, TQFP-100	EE PLD, 20ns, 96-Cell, CMOS, PQFP100, TQFP-100	EE PLD, 25ns, 96-Cell, CMOS, PQFP100, TQFP-100	EE PLD, 20ns, 96-Cell, CMOS, PQCC68, PLASTIC, LCC-68
Is it Rohs certified?	incompatible	-	-	incompatible	incompatible	incompatible	incompatible
Maker	Lattice	-	-	Lattice	Lattice	Lattice	Lattice
Parts packaging code	QFP	-	-	QFP	QFP	QFP	LCC
package instruction	TQFP-100	-	-	TQFP-100	TQFP-100	TQFP-100	PLASTIC, LCC-68
Contacts	100	-	-	100	100	100	68
Reach Compliance Code	not_compliant	-	-	not_compliant	not_compliant	not_compliant	not_compliant
ECCN code	EAR99	-	-	EAR99	EAR99	EAR99	EAR99
Other features	IN-SYSTEM PROGRAMMABLE; 4 EXTERNAL CLOCKS	-	-	IN-SYSTEM PROGRAMMABLE; 4 EXTERNAL CLOCKS	IN-SYSTEM PROGRAMMABLE; 4 EXTERNAL CLOCKS	YES	IN-SYSTEM PROGRAMMABLE; 4 EXTERNAL CLOCKS
maximum clock frequency	38 MHz	-	-	58.8 MHz	50 MHz	38 MHz	50 MHz
In-system programmable	YES	-	-	YES	YES	YES	YES
JESD-30 code	S-PQFP-G100	-	-	S-PQFP-G100	S-PQFP-G100	S-PQFP-G100	S-PQCC-N68
JESD-609 code	e0	-	-	e0	e0	e0	e0
JTAG BST	NO	-	-	NO	NO	NO	NO
length	14 mm	-	-	14 mm	14 mm	14 mm	24.2316 mm
Humidity sensitivity level	3	-	-	3	3	3	3
Dedicated input times	2	-	-	2	2	2	2
Number of I/O lines	48	-	-	48	48	48	48
Number of macro cells	96	-	-	96	96	96	96
Number of terminals	100	-	-	100	100	100	68
Maximum operating temperature	70 °C	-	-	70 °C	70 °C	85 °C	70 °C
organize	2 DEDICATED INPUTS, 48 I/O	-	-	2 DEDICATED INPUTS, 48 I/O	2 DEDICATED INPUTS, 48 I/O	2 DEDICATED INPUTS, 48 I/O	2 DEDICATED INPUTS, 48 I/O
Output function	MACROCELL	-	-	MACROCELL	MACROCELL	MACROCELL	MACROCELL
Package body material	PLASTIC/EPOXY	-	-	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	LFQFP	-	-	LFQFP	LFQFP	LFQFP	QCCJ
Encapsulate equivalent code	QFP100,.63SQ,20	-	-	QFP100,.63SQ,20	QFP100,.63SQ,20	QFP100,.63SQ,20	LDCC68,1.0SQ
Package shape	SQUARE	-	-	SQUARE	SQUARE	SQUARE	SQUARE
Package form	FLATPACK	-	-	FLATPACK	FLATPACK	FLATPACK	CHIP CARRIER
Peak Reflow Temperature (Celsius)	240	-	-	240	240	240	225
power supply	5 V	-	-	5 V	5 V	5 V	5 V
Programmable logic type	EE PLD	-	-	EE PLD	EE PLD	EE PLD	EE PLD
propagation delay	25 ns	-	-	17 ns	20 ns	25 ns	20 ns
Certification status	Not Qualified	-	-	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	1.6 mm	-	-	1.6 mm	1.6 mm	1.6 mm	4.57 mm
Maximum supply voltage	5.25 V	-	-	5.25 V	5.25 V	5.5 V	5.25 V
Minimum supply voltage	4.75 V	-	-	4.75 V	4.75 V	4.5 V	4.75 V
Nominal supply voltage	5 V	-	-	5 V	5 V	5 V	5 V
surface mount	YES	-	-	YES	YES	YES	YES
technology	CMOS	-	-	CMOS	CMOS	CMOS	CMOS
Temperature level	COMMERCIAL	-	-	COMMERCIAL	COMMERCIAL	INDUSTRIAL	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)	-	-	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn85Pb15)
Terminal form	GULL WING	-	-	GULL WING	GULL WING	GULL WING	NO LEAD
Terminal pitch	0.5 mm	-	-	0.5 mm	0.5 mm	0.5 mm	1.27 mm
Terminal location	QUAD	-	-	QUAD	QUAD	QUAD	QUAD
Maximum time at peak reflow temperature	30	-	-	30	30	30	30
width	14 mm	-	-	14 mm	14 mm	14 mm	24.2316 mm
Base Number Matches	1	-	-	1	1	1	1
