3SMC70CABKLEADFREE datasheet, PDF

Datasheet> All Categories > Discrete semiconductor> diode> 3SMC70CABKLEADFREE

3SMC70CABKLEADFREE: DescriptionTrans Voltage Suppressor Diode, 3000W, 70V V(RWM), Bidirectional, 1 Element, Silicon, ROHS COMPLIANT, SMC, 2 PIN; CategoryDiscrete semiconductor diode; File Size658KB，3 Pages; ManufacturerCentral Semiconductor; Environmental Compliance

Download Datasheet Parametric Compare View All

3SMC70CABKLEADFREE Overview

Trans Voltage Suppressor Diode, 3000W, 70V V(RWM), Bidirectional, 1 Element, Silicon, ROHS COMPLIANT, SMC, 2 PIN

3SMC70CABKLEADFREE Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	R-PDSO-C2
Contacts	2
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	UL RECOGNIZED
Maximum breakdown voltage	89.5 V
Minimum breakdown voltage	77.8 V
Breakdown voltage nominal value	83.65 V
Maximum clamping voltage	113 V
Configuration	SINGLE
Diode component materials	SILICON
Diode type	TRANS VOLTAGE SUPPRESSOR DIODE
JESD-30 code	R-PDSO-C2
JESD-609 code	e3
Humidity sensitivity level	1
Maximum non-repetitive peak reverse power dissipation	3000 W
Number of components	1
Number of terminals	2
Maximum operating temperature	150 °C
Minimum operating temperature	-65 °C
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
polarity	BIDIRECTIONAL
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	70 V
surface mount	YES
technology	AVALANCHE
Terminal surface	Matte Tin (Sn)
Terminal form	C BEND
Terminal location	DUAL
Maximum time at peak reflow temperature	10
Base Number Matches	1

Preview

Download Datasheet

View All

3SMC5.0CA

THRU

3SMC170CA

SURFACE MOUNT

BI-DIRECTIONAL

GLASS PASSIVATED JUNCTION

SILICON TRANSIENT

VOLTAGE SUPPRESSOR

3000 WATTS, 5.0 THRU 170 VOLTS

w w w. c e n t r a l s e m i . c o m

DESCRIPTION:

The CENTRAL SEMICONDUCTOR 3SMC5.0CA

Series types are Surface Mount Bi-Directional Glass

Passivated Junction Transient Voltage Suppressors

designed to protect voltage sensitive components from

high voltage transients.

THIS DEVICE IS MANUFACTURED WITH A GLASS

PASSIVATED CHIP FOR OPTIMUM RELIABILITY.

Note: For Uni-directional devices, please refer to the

3SMC5.0A Series data sheet.

MARKING CODE: SEE MARKING CODE ON

ELECTRICAL CHARACTERISTIC TABLE

SMC CASE

• This series is UL listed, UL file number E130224

MAXIMUM RATINGS:

(TA=25°C unless otherwise noted)

Peak Power Dissipation (Note 1)

Peak Forward Surge Current (JEDEC Method)

Operating and Storage Junction Temperature

SYMBOL

PDM

IFSM

TJ, Tstg

3000

200

-65 to +150

UNITS

°C

ELECTRICAL CHARACTERISTICS:

(TA=25°C unless otherwise noted)

REVERSE

STAND-OFF

VOLTAGE

VRWM

(V)

3SMC5.0CA

3SMC6.0CA

3SMC6.5CA

3SMC7.0CA

3SMC7.5CA

3SMC8.0CA

3SMC8.5CA

3SMC9.0CA

3SMC10CA

3SMC11CA

3SMC12CA

3SMC13CA

3SMC14CA

3SMC15CA

3SMC16CA

3SMC17CA

3SMC18CA

3SMC20CA

3SMC22CA

3SMC24CA

3SMC26CA

3SMC28CA

3SMC30CA

5.0

6.0

6.5

7.0

7.5

8.0

8.5

9.0

BREAKDOWN

VOLTAGE

VBR @

MIN

(V)

6.40

6.67

7.22

7.78

8.33

8.89

9.44

10.0

11.1

12.2

13.3

14.4

15.6

16.7

17.8

18.9

20.0

22.2

24.4

26.7

28.9

31.1

33.3

MAX

(V)

7.25

7.67

8.30

8.95

9.58

10.23

10.82

11.5

12.8

14.0

15.3

16.5

17.9

19.2

20.5

21.7

23.3

25.5

28.0

30.7

33.2

35.8

38.3

(mA)

1.0

TEST

CURRENT

MAXIMUM

REVERSE

LEAKAGE

CURRENT

@ VRWM

(µA)

2000

1000

400

200

100

5.0

MAXIMUM

CLAMPING

VOLTAGE

@ IPP

(V)

9.2

10.3

11.2

12.0

12.9

13.6

14.4

15.4

17.0

18.2

19.9

21.5

23.2

24.4

26.0

27.6

29.2

32.4

35.5

38.9

42.1

45.4

48.4

PEAK

PULSE

CURRENT

(Note 1)

IPP

(A)

326.0

291.3

267.9

250.0

232.6

220.6

208.4

194.8

176.4

184.8

150.6

139.4

129.4

123.0

115.4

106.6

102.8

92.6

84.4

77.2

71.2

66.0

62.0

CIDE

CIDG

CIDK

CIDM

CIDP

CIDR

CIDT

CIDV

CIDX

CIDZ

CIEE

CIEG

CIEK

CIEM

CIEP

CIER

CIET

CIEV

CIEX

CIEZ

CIFE

CIFG

CIFK

TYPE

MARKING

CODE

Notes: (1) Non-repetitive 10x1,000µs pulse

R8 (20-November 2009)
