PO3B3253A
www.potatosemi.com
Dual 4:1 Mux/DeMux
High Bandwidth Potato Chip
FEATURES:
• Patented technology
• High signal -3db passing bandwidth at 750 MHz
• Near-Zero propagation delay
• VCC = 1.65V to 3.6V
• Ultra-Low Quiescent Power: 0.1µA typical
• Ideally suited for low power applications
• Industrial operating temperature: -40°C to +85°C
• Available in 16pin 173mil wide TSSOP package
• Available in 16pin 150mil wide SOIC package
• Available in 16pin 150mil wide QSOP package
DESCRIPTION:
Potato Semiconductor’s PO3B3253A is
designed for world top performance using
submicron CMOS technology to achieve
750 MHz
high bandwidth.
The PO3B3253A is a Dual 4:1 Multiplexer /
Demultiplexer with 3-state outputs. The switch
introduces no additional ground bounce noise or
propagation delay.
Pin Configuration
EA
S1
IA3
IA2
IA1
IA0
1
2
3
4
5
16
Block Diagram
V
CC
EB
S0
IB3
IB2
IB1
IB0
YB
YA
YB
EA
EB
S0
S1
IA0
SW
SW
SW
SW
SW
SW
SW
SW
IA1
IA2
IA3
IB0
IB1
IB2
IB3
15
14
13
12
11
10
9
SW
I
Y
6
E
YA
GND
7
8
Pin Description
Pin Name
I
A
N
,
I
B
N
S
0-1
E
A
, E
B
Y
A
, Y
B
GND
V
CC
Description
Data Inputs
Select Inputs
Enable
Data Outputs
Ground
Power
Truth Table
Enable
E
A
H
X
L
L
L
L
E
B
X
H
L
L
L
L
Select
S
1
X
X
L
L
H
H
S
0
X
X
L
H
L
H
Y
A
Hi-Z
X
I
A
0
I
A
1
I
A
2
I
A
3
Y
B
X
Hi-Z
I
B
0
I
B
1
I
B
2
I
B
3
Function
Disable A
Disable B
S1-0 = 0
S1-0 = 1
S1-0 = 2
S1-0 = 3
Potato Semiconductor Corporation
1
01/01/10
PO3B3253A
www.potatosemi.com
Dual 4:1 Mux/DeMux
High Bandwidth Potato Chip
Maximum Ratings
(Above which the useful life may be impaired. For user guidelines, not tested.)
Note:
Storage Temperature ................................................ –65°C to +150°C
Ambient Temperature with Power Applied ............... –40°C to +85°C
Supply Voltage to Ground Potential ........................... –0.5V to +4.6V
DC Input Voltage ........................................................ –0.5V to +Vcc
DC Output Current................................................................... 120mA
Power Dissipation ....................................................................... 0.5W
Stresses greater than those listed under
MAXIMUM RATINGS may cause permanent
damage to the device. This is a stress rating
only and functional operation of the device at
these or any other conditions above those
indicated in the operational sections of this
specification
is not implied. Exposure to
absolute maximum rating conditions for
extended periods may affect reliability.
(Over the Operating Range, T
A
= –40°C to +85°C, V
CC
= 3.3V ±10%)
Parameters
V
IH
V
IL
I
IH
I
IL
I
OZH
R
ON
Description
Input HIGH Voltage
Input LOW Voltage
Input HIGH Current
Input LOW Current
DC Electrical Characteristics, 3.3V Supply
Test Conditions
Guaranteed Logic HIGH Level
Guaranteed Logic LOW Level
V
CC
= Max., V
IN
= V
CC
V
CC
= Max., V
IN
= GND
Y, In
V
CC
17
17
V
CC
= Min., V
IN
= 0.0V,
Switch On-Resistance
I
ON
= -48 mA or -64mA
V
CC
= Min., V
IN
= V
CC
, I
ON
= -15 mA
Min.
2.0
0.8
±1
±1
±1
22
22
A
Typ.
Max.
Units
V
High Impedance Output Current 0
(Over Operating Range, T
A
= –40°C to +85°C, V
CC
= 2.5V ± 10%)
Parameters
V
IH
V
IL
I
IH
I
IL
I
OZH
R
ON
Description
Input HIGH Voltage
Inout LOW Voltage
Input HIGH Current
Input LOW Current
High Impedance Current
Switch On Resistance
DC Electrical Characteristics, 2.5V Supply
Test Conditions
Guaranteed Logic HIGH Level
Guaranteed Logic LOW Level
V
CC
= Max., V
IN
= V
CC
V
CC
= Max., V
IN
= GND
0
Y, In
V
CC
18
18
V
CC
= Min., V
IN
= 0.0V,
I
ON
= –48mA
V
CC
= Min., V
IN
= 2.25V,
I
ON
= -15mA
Min.
1.8
–0.3
Typ.
Max.
V
CC
+ 0.3
0.8
±1
±1
±1
25
25
A
Units
V
Potato Semiconductor Corporation
2
01/01/10
PO3B3253A
www.potatosemi.com
Dual 4:1 Mux/DeMux
High Bandwidth Potato Chip
Power Supply Characteristics
Symbol
Description
Quiescent Power Supply Current
Test Conditions (1)
Vcc=Max, Vin=Vcc or GND
Min
Typ
Max
Unit
Icc
Notes:
1.
2.
3.
4.
5.
-
0.1
3
uA
For conditions shown as Max. or Min., use appropriate value specified under Electrical Characteristics for the applicable device type.
Typical values are at Vcc = 3.3V, 25°C ambient.
This parameter is guaranteed but not tested.
Not more than one output should be shorted at one time. Duration of the test should not exceed one second.
VoH = Vcc – 0.6V at rated current
Capacitance
Parameters
C
IN
C
OFFYN
C
OFFIN
C
ON
(T
A
= 25°C f = 1 MHz)
Description
Input Capacitance
Y
N
Capacitance, Switch OFF
I
N
Capacitance, Switch OFF
I
N
/Y
N
Capacitance, Switch ON
V
IN
= 0V
Test Conditions
Typical
3
5
3.7
8.7
pF
Units
Dynamic Electrical Characteristics Over the Operating Range
(T
A
= -40º to +85º, V
CC
= 3.3V ± 10%)
Parameter
X
TALK
O
IRR
BW
Description
Crosstalk
Off-Isolation
-3dB Bandwidth
Test Condition
R
L
= 100
R
L
= 100
R
L
= 100
Typ.
-60
-60
750
Units
dB
MHz
Switching Characteristics over 3.3V Operating Range
Parameters
t
PLH
t
PHL
t
PZH
t
PZL
t
PHZ
t
PLZ
Description
Propogation Delay
Bus Enable Time
See Test Diagram
Bus Disable Time
3.0
Conditions
See Test Diagram
Max.
0.3
2.0
ns
Units
Potato Semiconductor Corporation
3
01/01/10
PO3B3253A
www.potatosemi.com
Dual 4:1 Mux/DeMux
High Bandwidth Potato Chip
Switching Characteristics over 2.5V Operating Range
Parameters
t
PLH
t
PHL
t
PZH
t
PZL
t
PHZ
t
PLZ
Description
Propogation Delay
Bus Enable Time
See Test Diagram
Bus Disable Time
3.0
Conditions
See Test Diagram
Max.
0.3
2.0
ns
Units
Test Circuit for Electrical Characteristics
6.0V
V
CC
Switch Positions
Test
t
PLZ
, t
PZL
t
PHZ
, t
PZH
Prop Delay
Switch
6.0V
GND
Open
200-ohm
Pulse
Generator
V
IN
V
OUT
D.U.T
R
T
10pF
C
L
200-ohm
Switching Waveforms
SEL
Input
t
PLH
Output
2.5V
2.5V
t
PHL
2.5V
2.5V
3.5V
1.5V
V
OH
V
OL
Output
tPZL
1.25V
tPLZ
1.25V
2.5V
0V
VOH
VDD/2
tPZH
VOL +0.3V
tPHZ
VOH –0.3V
VOL
VOH
VOL
Output
VDD/2
Voltage Waveforms Propagation Delay Times
Voltage Waveforms Enable and Disable Times
Potato Semiconductor Corporation
4
01/01/10
PO3B3253A
www.potatosemi.com
Dual 4:1 Mux/DeMux
High Bandwidth Potato Chip
Packaging Mechanical Drawing: 16 pin QSOP
Packaging Mechanical Drawing: 16 pin SOIC
16
.149
.157
3.78
3.99
.2284
.2440
5.80
6.20
1
.386
.393
9.80
10.00
.0155 0.393
.0260 0.660
.053
.068
.0040
.0098
1.35
1.75
0.10
0.25
.0075
.0098
0.19
0.25
.016
.050
0.41
1.27
.050
BSC
1.27
.013
.020
0.330
0.508
X.XX
DENOTES DIMENSIONS
X.XX
IN MILLIMETERS
Potato Semiconductor Corporation
5
01/01/10
