D Subminiature
Part numbers with plastic bracket and
captive nut M3
Shell Layout
size
P/N without pushfit
P/N with pushfit
Combo D
®
/European Version
Part numbers with plastic bracket with
bushing diam. 3,05
P/N without pushfit
P/N with pushfit
40 A High power 90° – European footprint, size DD, with plastic bracket
Part numbers with plastic bracket
with post M3
P/N without pushfit
P/N with pushfit
DD
DD
DD
DD
24W7
36W4
43W2
47W1
DDM-24P7S-1ATN-A191-A197
DDM-36P4S-1ATN-A191-A197
DDM-43P2S-1ATN-A191-A197
DDM-47P1S-1ATN-A191-A197
DDM-24P7S-1ATN-A191-A197-146
DDM-36P4S-1ATN-A191-A197-146
DDM-43P2S-1ATN-A191-A197-146
DDM-47P1S-1ATN-A191-A197-146
DDM-24P7S-1A5N-A191-A197
DDM-36P4S-1A5N-A191-A197
DDM-43P2S-1A5N-A191-A197
DDM-47P1S-1A5N-A191-A197
DDM-24P7S-1A5N-A191-A197-146
DDM-36P4S-1A5N-A191-A197-146
DDM-43P2S-1A5N-A191-A197-146
DDM-47P1S-1A5N-A191-A197-146
DDM-24P7S-1APN-A191-A197
DDM-36P4S-1APN-A191-A197
DDM-43P2S-1APN-A191-A197
DDM-47P1S-1APN-A191-A197
DDM-24P7S-1APN-A191-A197-146
DDM-36P4S-1APN-A191-A197-146
DDM-43P2S-1APN-A191-A197-146
DDM-47P1S-1APN-A191-A197-146
For performance class 1 replace A191 with A190.
For performance class 3 delete A191.
For pushfit 90° hole diameter 3,2 mm replace 146 with 162.
For captive nut 4-40 UNC replace 1ATN with 1AUN and
1APN with 1A6N.
Socket
67,3
3,7
±0,3
61,1
52,55
2,54
2,54
8,7
±0,15
13,1
±0,2
A4
8
15
7
14
6
13
5
12
4
11
3
10
2
9
1
A3
A2
A1
q
q
q
q
For contact cavity arrangements, see page 53.
For pcb hole pattern, see page 72 – 75.
For mounting methods, see page 86 – 87.
For panel cut-outs, see our D Subminiature
catalogue.
ITT
32
31
30
29
28
CANNON
27
26
36W4P
25
24
23
22
21
20
19
18
17
16
10
°
Ø 2,9
17,5
±0,2
Ø 0,6
D
E
Dimensions
Shell
size
A
±
0,38
B
±
0,13
52,4
C
L
±
0,13
D
±
0,13
E
±
0,13
F
±
0,25
L
+
0,2
W
±
0,4
DD
66,95
61,1
10,75
15,4
10,9
0,8
6,95
W
E
21
