MIL-STD-1760 Type 1 (MIL-DTL-83538)
Stores Management Systems
The 1760 Type 1 range of connectors is
designed to meet the electrical interface
requirements of MIL-STD-1760.
The first tri-start threaded plug and lanyard
release plugs can be used between aircraft
and pylon.
For applications which require instant
disconnection the lanyard release plug offers
a viable solution.
FEATURES
Tri-Start threaded plugs
Lanyard release
Complies with MIL-C-38999 Series III
Full environmental performance
BENEFITS
Easy connection
Instant disconnection through lanyard release
QUALITY APPROVALS
Civil Aviation Authority A8-1
BS EN ISO 9001
Military Spec Approvals 38999
BS9000 and CECC
Underwriters Laboratories
GENERAL SPECIFICATION
Material:
Shell/coupling ring:
Plating:
Contacts:
Material:
Type:
Insulators:
Interface Seal:
Temperature:
Aluminium Alloy
Cadmium plate olive drab over nickel
Gold plated Copper Alloy
Crimp
Thermoplastic
Fluorinated Silicone
-55°C to +175°C
No electrical or mechanical defects
after 500 cycles
As per Mil-DTL-38999
As per Mil-DTL-38999
With 30 years experience in designing and
manufacturing at its own facilities, Deutsch Ltd
can provide interconnection solutions for the
most demanding of environments
Durability:
Vibration:
Thermal Shock:
Castleham Industrial Estate
4 Stanier Road, St Leonard-On-Sea
East Sussex TN38 9RF England
Telephone +44 (0) 1424 852721
Fax
+44 (0) 1424 857142
Email
milaero@deutsch.co.uk
www.deutschltd.com
ORDERING INFORMATION - DEUTSCH PART NUMBER
DTS 20 W 25 - 20 P N E
Lanyard Length:
Shell Keying:
Contact Type:
Insert Arrangement:
Shell Size:
Class W:
Shell Style:
Deutsch Range Identifier
E=153mm, F=166mm, G=178mm, H=191mm, I=203mm,
J=216mm, K=229mm, L=242mm (Style 31 only)
N only for 25-20
P = Pin, S = Socket, (Pins only in Style 31)
20 only
25 only
Cadmium Plate, Olive Drab Aluminium
20=Square Flange Receptacle, 24=Jam Nut Receptacle
26=Straight Plug,
31=Lanyard Release Plug
MILITARY NUMBER - STANDARD PLUGS/RECEPTACLES
D38999/20 W J - 20 P N
Shell Keying:
Contact Type:
Insert Arrangement:
Shell Size:
Class W:
Shell Style:
Military Range Identifier
N only for 25-20
P = Pin, S = Socket
20 only
25 only
Cadmium Plate, Olive Drab Aluminium
20=Square Flange Receptacle, 24=Jam Nut Receptacle,
26=Straight Plug
MILITARY NUMBER - LANYARD RELEASE PLUGS
D38999/31 W E
20 P N 1
D38999/31:
Shell Keying:
Contact Type:
Insert Arrangement:
Lanyard Length:
Class W:
Shell Style 31:
Military Range Identifier
2” diameter (51 mm)
N only for 25-20
P=Pin (supplied with Pins only)
20 only
E=153mm, F=166mm, G=178mm, H=191mm,
I=203mm, J=216mm, K=229mm, L=242mm
Cadmium Plate, Olive Drab Aluminium
31=Lanyard Release Plug (supplied with Pins only)
For further options of Lanyard Release and Snatch Connectors please consult Deutsch
CONTACTS, TOOLING & FILLER PLUGS
Contact Size
& Type
20 Pin
20 Socket
16 Pin
16 Socket
12 Shielded Pin
12 Shielded Socket
12 Coax Pin
12 Coax Socket
10 Pin
10 Socket
8 Twinax Pin
8 Twinax Socket
8 Twinax Pin
(Speedy Crimp)
8 Twinax Socket
(Speedy Crimp)
8 Twinax Socket
(Speed Crimp
Short-Lenght)
Deutsch
Part Number
39841-20
39843-20
39841-16
39843-16
62290-211
602272-416
602177
602176
602078-10
602079-10
Military Spec.
Part Number
NB: Filller plugs must be ordered seperately as they are not supplied with the connectors
Crimping
Tool
Crimping Tool
Locator
M22520/1-04
M22520/1-04
M22520/1-04
M22520/1-04
M22520/2-34
M22520/31-02
Not applicable
M2252/5-03
Integral with tool
Integral with tool
K709
Y631 Close B
Y631 Close A
Integral with tool
Integral with tool
Insert/Extract
Tool
M18969/14-02
M18969/14-02
M18969/14-03
M18969/14-03
M18969/14-04
M18969/14-04
M18969/14-04
M18969/14-04
M18969/14-05
M18969/14-05
M18969/14-06
M18969/14-06
M18969/14-06
M18969/14-06
Filler
Plugs
600300-20
600300-20
600300-16
600300-16
602064
602065
602064
602065
602068
602068
602066
602067
602066
602067
gkkbg
k m gr
r mm
m kf
r frr b
gtfn
M22520/1-01
M39029/58-363
M22520/1-01
M39029/56-351
M22520/1-01
M39029/58-364
M22520/1-01
M39029/56-352
M39029/28-211 Inner M22520/2-01
M39029/75-416 Outer M22520/31-01
Inner Soldered
M39029/102-558
M39029/103-559 Outer M22520/5-01
1716 P-I
M39029/58-528
DMC
M39029/56-527
Ctr M22520/2-01
602081-A-9734* M39029/90-529
Int M22520/5-01
602091-A-9734 M39029/91-530
Outer M22520/5-01
602080-A-9734*
602090-A-9734*
Awaiting
allocation
Ctr TDB-CT-08
Int TDB-CT-08
Outer M22520/5-01
60269-A-9734*
Y631 Close A
M18969/14-06
602067
* MOD 9734 - Includes Contact sealing boot
Subject to change without prior notification
©2005 Deutsch Ltd 1760-TYPE1 issue 1A 01/06
