1. See Figure 10 (High Efficiency Red), 15 (Yellow), or 20 (Green) to establish pulsed operating conditions.
2. For High Efficiency Red and Green Series, derate linearly from 50°C at 0.5 mA/°C. For Red and Yellow Series, derate linearly from 50°C at 0.2 mA/°C.
3. For High Efficiency Red and Green Series, derate power linearly from 25°C at 1.8 mW/°C. For Red and Yellow Series, derate power linearly from 50°C at
1.6 mW/°C.
4. The transient peak current is the maximum non-recurring peak current that can be applied to the device without damaging the LED die and wirebond. It
is not recommended that the device be operated at peak current beyond the peak forward current listed in the Absolute Maximum Ratings.
1.0
HIGH
EFFICIENCY
RED
RELATIVE INTENSITY
T
A
= 25°C
RED
0.5
GREEN
YELLOW
500
550
600
650
700
750
WAVELENGTH – nm
Figure 1. Relative intensity vs. wavelength.
3
High Efficiency Red HLMP-335x/-336x Series
Electrical Specifications at T
A
= 25°C
Symbol
2θ
1
/
2
Description
Including Angle Between Half
Luminous Intensity Points
Device
HLMP-
3366
Min.
Typ.
50
50
45
45
635
626
40
90
11
260
1.9
5.0
145
2.4
Max.
Units
Deg.
Test Conditions
Note 1 (Figure 11)
λ
PEAK
λ
d
∆λ
1/2
τ
s
C
Rθ
J-PIN
V
F
V
R
η
V
Peak Wavelength
Dominant Wavelength
Spectral Line Halfwidth
Speed of Response
Capacitance
Thermal Resistance
Forward Voltage
Reverse Breakdown Voltage
Luminous Efficacy
nm
nm
nm
ns
pF
°C/W
V
V
lm/W
Measurement at
Peak (Figure 1)
Note 2
V
F
= 0; f = 1 MHz
Junction to
Cathode Lead
I
F
= 10 mA
(Figure 7)
I
R
= 100
µA
Note 3
Notes:
1.
θ
1
/
2
is the off-axis angle at which the luminous intensity is half the axial luminous intensity.
2. Dominant wavelength,
λ
d
, is derived from the CIE chromaticity diagram and represents the single wavelength which defines the color of the device.
3. Radiant Intensity, I
e
, in watts/steradian may be found from the equation I
e
= I
v
/η
v
, where I
v
is the luminous intensity in candelas and
η
v
is the luminous
efficacy in lumens/watt.
Figure 7. Forward current vs. forward voltage.
Figure 8. Relative luminous intensity vs.
forward current.
Figure 9. Relative efficiency (luminous
intensity per unit current) vs. peak current.
4
Figure 10. Maximum tolerable peak current
vs. pulse duration. (I
DC
MAX as per MAX
ratings).
Figure 11. Relative luminous intensity vs. angular displacement.
Yellow HLMP-345x/-346x Series
Electrical Specifications at T
A
= 25°C
Symbol
2θ
1/2
Description
Including Angle Between Half
Luminous Intensity Points
Device
HLMP-
3466
Min.
Typ.
50
50
45
45
583
585
36
90
15
260
2.0
5.0
500
2.4
Max.
Units
Deg.
Test Conditions
Note 1 (Figure 16)
λ
PEAK
λ
d
∆λ
1/2
τ
s
C
Rθ
J-PIN
V
F
V
R
η
V
Peak Wavelength
Dominant Wavelength
Spectral Line Halfwidth
Speed of Response
Capacitance
Thermal Resistance
Forward Voltage
Reverse Breakdown Voltage
Luminous Efficacy
nm
nm
nm
ns
pF
°C/W
V
V
lm/W
Measurement at
Peak (Figure 1)
Note 2
V
F
= 0; f = 1 MHz
Junction to
Cathode Lead
I
F
= 10 mA
(Figure 12)
I
R
= 100
µA
Note 3
Notes:
1.
θ
1
/
2
is the off-axis angle at which the luminous intensity is half the axial luminous intensity.
2. Dominant wavelength,
λ
d
, is derived from the CIE chromaticity diagram and represents the single wavelength which defines the color of the device.
3. Radiant Intensity, I
e
, in watts/steradian may be found from the equation I
