PTC307C Series
Vishay Cera-Mite
PTC Thermistors Motor Start Pellets
FEATURES
•
Rugged silver electrodes well suited for long life
OEM pressure contact mounting
•
Various pellet sizes for optimum inrush current
and switching time
•
Withstanding voltage is 2 times the maximum voltage
rating
•
UL approved pellets
•
Compliant to RoHS directive 2002/95/EC
APPLICATIONS
•
Single Phase motorstart assist in
- Refrigerator systems
- Airconditioning systems
PARAMETER
VALUE
UNIT
Ω
QUICK REFERENCE DATA
- Heat-pumps
- Small compressors
•
Inrush current generation
Resistance value at 25 °C
3.3 to 75
Tolerance on resistance value
± 30
%
DESCRIPTION
These directly heated thermistors have a positive
temperature coefficient and are primarily intended for inrush
current generation. They consist of a high grade ceramic disk
with two rugged pattern silver electrodes for contact pressure
mounting. These ceramic pellets can be build into proprietary
motor start devices for compressor, refrigerator and HVAC
OEMs.
Current ratings
4 to 16
A
RMS
Switching times (typical)
0.25 to 1.0
s
Maximum voltage rating
160 to 450
V
RMS
Operating temperature range
- 10 to + 85
°C
MOUNTING
The PTC thermistor pellets are suitable for pressure contact
mounting in application specific housing assemblies.
Examples of such assemblies can be found in the PTC305C
series. Assembly housing must be appropriate for usage up
to 180 °C surface temperature of the PTC pellets.
The pellets are not solderable.
Storage temperature range
- 25 to + 105
°C
MARKING
The pellets are not marked. Marking is available on request
for customized parts.
SAFETY AGENCY RECOGNITION
Vishay Cera-Mite motor start PTC pellet thermistors are
recognized by Underwriter Laboratories file E148885 in
accordance with Standard for Thermistor Type Devices
UL 1434; and Canadian Standards C22.2 No. 0-1991.
www.vishay.com
1
For technical questions, contact:
ceramitesupport@vishay.com
Document Number: 22998
Revision: 11-Aug-10
PTC307C Series
PTC Thermistors Motor Start Pellets
Vishay Cera-Mite
ELECTRICAL DATA AND ORDERING INFORMATION
PART NUMBER
PTC307C1674P
PTC307C1700P
PTC307C1711P
PTC307C1668P
PTC307C1644P
PTC307C1651P
PTC307C1720P
PTC307C1411P
PTC307C1484P
PTC307C1544P
PTC307C1399P
PTC307C1489P
PTC307C1476P
PTC307C1530P
PTC307C1531P
PTC307C1282P
PTC307C1533P
PTC307C1292P
PTC307C1487P
PTC307C1529P
PTC307C1545P
PTC307C1640P
PTC307C1740P
PTC307C1024P
PTC307C1409P
PTC307C1410P
R
25 (1)
± 30 %
(Ω)
5.0
6.8
10
5.0
6.8
10
20
3.3
4.7
5.6
6.8
10
12
15
22
33
47
68
3.9
12
14
30
30
38
50
75
R
DYN (2)
(Ω)
4.0
5.0
7.2
4.0
5.0
7.2
13
2.6
3.5
4.1
5.0
7.2
8.5
10.5
15
22
30
42
3.0
10.3
12
15.9
15.9
25
35
50
V
meas.
R
DYN
(V
RMS
)
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
50
100
100
240
240
240
240
240
MAX.
VOLTAGE
(3)
(V
RMS
)
200
200
200
180
200
200
320
160
180
180
200
230
250
300
400
355
400
430
175
350
320
380
450
400
400
400
MAX.
CURRENT
(A
RMS
)
10
10
10
12
10
10
8
12
12
12
10
9
8.5
8
8
6
5
4
16
8
8
12
7
9
7.5
5.5
SIZE
ØxT
(mm)
16 + 0.2/- 0.4
x 2.5 ± 0.25
UL
(4)
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
Y
T
switch
(°C)
105
105
105
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
17.5 ± 0.3
x 2.5 ± 0.25
20 + 0.2/- 0.8
x 2.5 ± 0.25
20 + 0.2/- 0.8
x 3.2 ± 0.25
20 + 0.2/- 0.8
x 5.0 ± 0.25
Notes
(1)
R
= zero power resistance measured at < 0.5 V , standard tolerance ± 30 %, other tolerances and values on request.
25
DC
(2)
R
DYN
= nominal dynamic resistance during inrush, measured with V
meas.
applied, for information only.
(3)
The maximum voltage is the voltage that appears across the PTC in a motor start application. This is not the applied line voltage.
Withstanding voltage of all UL approved types is minimum twice the specified maximum operating voltage.
(4)
UL recoginition following XGPU2 category of standard UL1434, file E148885.
TYPICAL PTC CURRENT VS. TIME SHOWING DEFINITION OF
R
DYN
AND SWITCH TIME (t)
Peak current
V
meas.
I
PTC
max.
Switch time t
≈
R
DYN
=
h x V x (T
switch
- T
0
)
PTC Resistance (Ω)
I
2PTC
x
R
DYN
10 000
Current
10.0
I
PTC
(A
RMS
)
(Normalized)
h = Specific heatcapacity = 2.3 J/Kcm
3
T
0
= PTC temp. at time 0
V = PTC volume in cm
3
(D/2)
2
Tπ
1000
1.0
100
Switch time (t)
Resistance
0.1
20 % peak current
0
0.1
Motor contactor
closes
Switch time (t)
0.2
0.3 0.4 0.5 0.6 0.7 0.8
Time to Switch (s)
PTC switchout
Solid ceramic disc
10
50
100
PTC Temperature °C
150
0.01
Base electrode
D
Silver electrode
T
Document Number: 22998
Revision: 11-Aug-10
for technical questions, contact:
ceramitesupport@vishay.com
www.vishay.com
2
PTC Current (A
RMS
)
