415 Series - Screw Terminal
SPDT, DPDT, 15 Amps
File No.
E13224
The 415 series is a compact, 15 Amp base mounted industrial relay. It is a versatile relay that offers a
variety of contact configurations and options. Excellent contact life assures long mechanical life and
contact reliability on low level loads. Screw terminals are standard. Options include: high voltage or
high inrush contacts, quick connect terminals, permanent magnet blowout and low power DC coils.
GENERAL SPECIFICATIONS (@ 25° C)
Contacts:
Contact Configuration
Contact Material
Contact Rating
120 / 240VAC Resistive
28VDC Resistive
Motor 120VAC 1 Phase
Motor 240VAC 3 Phase
Contact Resistance, Initial
Coil:
Coils Available
Nominal Coil Power
Input Voltage Tolerance - AC
Input Voltage Tolerance - DC
Drop-out voltge
Duty
Timing:
Operate Time (max)
Release Time (max)
Dielectric Strength:
Across Open Contacts
Between mutally insulated point
Insulation resistance
Temperature:
Operating
Storage
Life Expectancy:
Electrical (full load)
Mechanical (no load)
Miscellaneous:
Mounting Position
Enclosure
Weight
DPDT
Silver Alloy
15 Amp
15 Amp
1/2Hp
1Hp
50 milliohms max. @ 6VDC
AC and DC
AC: 6VA, DC: 3.5W
85% to 110% of nominal
80% to 110% of nominal
10% of nominal
Continous
25 mS
10 mS
1,000Vrms
1,500Vrms
1000 Mohms min. @ 500VDC
AC: -40 to 55°C (-49 to 131°F)
DC: -40 to 70°C (-49 to 158°F)
-40 to 105°C (-40 to 221°F)
200,000
20,000,000
Vertical - Contacts Up
Open
4.0 oz. (113 grams)
415 Wire Diagram
(Top View)
415XAX
415XBX
415BXX
415XHX
415HXX
415XXH
1/13
www.struthers-dunn.com
(843) 664-3303
General Purpose Relays
415 AC Coils Specifications
mAmps @ nominal voltage
Nominal Votages Resistance
Inrush
Sealed
(VAC)
ohms ± 10% current
coil
6
1.5
1800
1000
12
6.3
900
500
24
25
450
250
48
100
225
125
120
620
90
50
240
2500
45
25
415 DC Coils Specifications
mAmps @ nominal voltage
Nominal Votages Resistance
Coils
Coils
(VDC)
ohms ± 10% Cold
Hot
6
10
600
500
12
40
300
250
24
155
150
125
32
390
112
95
48
620
75
62
115/125
4000
31
26
1.87
(47.4)
Coil Data
Dimensions Shown in inches & (millimeters)
Outline Dimensions
2.75
(69.8)
2.35
(59.6)
1.50
(38.1)
4 Holes 0.18 ± .005 DIA
(4.5 ± .13)
Ordering Code
Series
415
415
XBX
18
-120VAC
Contact Arrangement
BBX (DPDT - N.O.)
HXX (SPST-N.O. - DM)
XAX (SPDT)
XBX (DPDT)
XHX (SPDT - DB - DM)
XXH (SPST - N.C. - DB)
Optional Features
0.25 Inch quick connect terminals - CODE 18
Permanent Magnet Blowout - CODE 69
(Consult factory for other options)
Coil Voltage
AC: 6, 12, 24, 48, 120, 240, (Add VAC)
DC: 6, 12, 24, 32, 48, 115-125, (Add VDC)
Coil voltages and frequencies must be specified
Special coils: Low power (mW), series coils
High inrush contacts: 10 Amps continuous, 150 Amp inrush.
High voltage contacts: Up to 4KV
UP
Vertical mounting recommended
with contacts up
www.struthers-dunn.com
(843) 664-3303
1/14
