SAB-C504-LM datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> SAB-C504-LM

SAB-C504-LM: DescriptionMicrocontroller, 8-Bit, 8051 CPU, 12MHz, CMOS, PQFP44, METRIC, PLASTIC, QFP-44; CategoryThe embedded processor and controller Microcontrollers and processors; File Size893KB，71 Pages; ManufacturerInfineon; Websitehttp://www.infineon.com/

Download Datasheet Parametric Compare View All

SAB-C504-LM Overview

Microcontroller, 8-Bit, 8051 CPU, 12MHz, CMOS, PQFP44, METRIC, PLASTIC, QFP-44

SAB-C504-LM Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	Infineon
Parts packaging code	QFP
package instruction	METRIC, PLASTIC, QFP-44
Contacts	44
Reach Compliance Code	unknown
ECCN code	3A991.A.2
Has ADC	YES
Address bus width	16
bit size	8
CPU series	8051
maximum clock frequency	40 MHz
DAC channel	NO
DMA channel	NO
External data bus width	8
JESD-30 code	S-PQFP-G44
JESD-609 code	e0
length	10 mm
Number of I/O lines	32
Number of terminals	44
Maximum operating temperature	70 °C
Minimum operating temperature
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	QFP
Encapsulate equivalent code	QFP44,.52SQ,32
Package shape	SQUARE
Package form	FLATPACK
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	5 V
Certification status	Not Qualified
RAM (bytes)	256
rom(word)	0
Maximum seat height	2.45 mm
speed	12 MHz
Maximum supply voltage	5.5 V
Minimum supply voltage	4.25 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal pitch	0.8 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	NOT SPECIFIED
width	10 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER
Base Number Matches	1

Preview

Download Datasheet

View All

D a ta S h e et , M ay 2 00 0

C504

8-Bit Single-Chip Microcontroller

Microcontrollers

N e v e r

s t o p

t h i n k i n g .

SAB-C504-LM Related Products

	SAB-C504-LM	SAB-C504-2RM	SAF-C504-LM	SAB-C504-2EM	SAK-C504-2EM	SAK-C504-2RM	SAK-C504-LM
Description	Microcontroller, 8-Bit, 8051 CPU, 12MHz, CMOS, PQFP44, METRIC, PLASTIC, QFP-44	Microcontroller, 8-Bit, MROM, 8051 CPU, 12MHz, CMOS, PQFP44, METRIC, PLASTIC, QFP-44	Microcontroller, 8-Bit, 8051 CPU, 12MHz, CMOS, PQFP44, METRIC, PLASTIC, QFP-44	Microcontroller, 8-Bit, OTPROM, 12MHz, CMOS, PQFP44, METRIC, PLASTIC, QFP-44	Microcontroller, 8-Bit, OTPROM, 12MHz, CMOS, PQFP44, METRIC, PLASTIC, QFP-44	Microcontroller, 8-Bit, MROM, 8051 CPU, 12MHz, CMOS, PQFP44, METRIC, PLASTIC, QFP-44	Microcontroller, 8-Bit, 8051 CPU, 12MHz, CMOS, PQFP44, METRIC, PLASTIC, QFP-44
Parts packaging code	QFP	QFP	QFP	QFP	QFP	QFP	QFP
package instruction	METRIC, PLASTIC, QFP-44	METRIC, PLASTIC, QFP-44	METRIC, PLASTIC, QFP-44	QFP,	QFP,	METRIC, PLASTIC, QFP-44	METRIC, PLASTIC, QFP-44
Contacts	44	44	44	44	44	44	44
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown
ECCN code	3A991.A.2	3A991.A.2	3A991.A.2	3A991.A.2	3A991.A.2	3A991.A.2	3A991.A.2
Has ADC	YES	YES	YES	YES	YES	YES	YES
Address bus width	16	16	16	16	16	16	16
bit size	8	8	8	8	8	8	8
maximum clock frequency	40 MHz	40 MHz	40 MHz	40 MHz	40 MHz	40 MHz	40 MHz
DAC channel	NO	NO	NO	NO	NO	NO	NO
DMA channel	NO	NO	NO	NO	NO	NO	NO
External data bus width	8	8	8	8	8	8	8
JESD-30 code	S-PQFP-G44	S-PQFP-G44	S-PQFP-G44	S-PQFP-G44	S-PQFP-G44	S-PQFP-G44	S-PQFP-G44
length	10 mm	10 mm	10 mm	10 mm	10 mm	10 mm	10 mm
Number of I/O lines	32	32	32	32	32	32	32
Number of terminals	44	44	44	44	44	44	44
Maximum operating temperature	70 °C	70 °C	85 °C	70 °C	125 °C	125 °C	125 °C
Minimum operating temperature	-	-	-40 °C	-	-40 °C	-40 °C	-40 °C
PWM channel	YES	YES	YES	YES	YES	YES	YES
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	QFP	QFP	QFP	QFP	QFP	QFP	QFP
Package shape	SQUARE	SQUARE	SQUARE	SQUARE	SQUARE	SQUARE	SQUARE
Package form	FLATPACK	FLATPACK	FLATPACK	FLATPACK	FLATPACK	FLATPACK	FLATPACK
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum seat height	2.45 mm	2.45 mm	2.45 mm	2.45 mm	2.45 mm	2.45 mm	2.45 mm
speed	12 MHz	12 MHz	12 MHz	12 MHz	12 MHz	12 MHz	12 MHz
Maximum supply voltage	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V	5.5 V
Minimum supply voltage	4.25 V	4.25 V	4.25 V	4.25 V	4.25 V	4.25 V	4.25 V
Nominal supply voltage	5 V	5 V	5 V	5 V	5 V	5 V	5 V
surface mount	YES	YES	YES	YES	YES	YES	YES
technology	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	COMMERCIAL	COMMERCIAL	INDUSTRIAL	COMMERCIAL	AUTOMOTIVE	AUTOMOTIVE	AUTOMOTIVE
Terminal form	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING	GULL WING
Terminal pitch	0.8 mm	0.8 mm	0.8 mm	0.8 mm	0.8 mm	0.8 mm	0.8 mm
Terminal location	QUAD	QUAD	QUAD	QUAD	QUAD	QUAD	QUAD
width	10 mm	10 mm	10 mm	10 mm	10 mm	10 mm	10 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER
Is it Rohs certified?	incompatible	incompatible	incompatible	-	-	incompatible	incompatible
Maker	Infineon	Infineon	Infineon	Infineon	Infineon	-	Infineon
CPU series	8051	8051	8051	-	-	8051	8051
JESD-609 code	e0	e0	e0	-	-	e0	e0
Encapsulate equivalent code	QFP44,.52SQ,32	QFP44,.5SQ,32	QFP44,.52SQ,32	-	-	QFP44,.5SQ,32	QFP44,.52SQ,32
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	-	-	NOT SPECIFIED	NOT SPECIFIED
power supply	5 V	5 V	5 V	-	-	5 V	5 V
RAM (bytes)	256	512	256	-	-	512	256
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	-	-	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	-	-	NOT SPECIFIED	NOT SPECIFIED
Base Number Matches	1	1	1	1	1	1	-
ROM programmability	-	MROM	-	OTPROM	OTPROM	MROM	-
