LM431CIMX Overview

Two Terminal Voltage Reference, 1 Output, 2.5V, Trim/Adjustable, BIPolar, PDSO8, SOIC-8

LM431CIMX Parametric

Parameter Name	Attribute value
Maker	Rochester Electronics
package instruction	SOP,
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	OUTPUT VOLTAGE ADJUSTABLE FROM 2.5 TO 36V WITH TWO EXTERNAL RESISTORS
Analog Integrated Circuits - Other Types	TWO TERMINAL VOLTAGE REFERENCE
JESD-30 code	R-PDSO-G8
length	4.9 mm
Number of functions	1
Output times	1
Number of terminals	8
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Maximum output voltage	2.51 V
Minimum output voltage	2.485 V
Nominal output voltage	2.5 V
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Maximum seat height	1.75 mm
surface mount	YES
technology	BIPOLAR
Maximum voltage temperature coefficient	54.4 ppm/°C
Temperature level	INDUSTRIAL
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Fine-tuning/adjustable output	YES
width	3.9 mm
Base Number Matches	1

Preview

Download Datasheet

View All

LM431 Adjustable Precision Zener Shunt Regulator

September 2, 2010

LM431

Adjustable Precision Zener Shunt Regulator

General Description

The LM431 is a 3-terminal adjustable shunt regulator with

guaranteed temperature stability over the entire temperature

range of operation. The output voltage may be set at any level

greater than 2.5V (V

REF

) up to 36V merely by selecting two

external resistors that act as a voltage divided network. Due

to the sharp turn-on characteristics this device is an excellent

replacement for many zener diode applications.

Features

■

Average temperature coefficient 50 ppm/°C

■

Temperature compensated for operation over the full

temperature range

■

Programmable output voltage

■

Fast turn-on response

■

Low output noise

Connection Diagrams

TO-92: Plastic Package

SOT-23: 3-Lead Small Outline

1005528

1005501

Top View

SO-8: 8-Pin Surface Mount

1005502

Top view

Note: NC = Not internally connected.

10055

www.national.com
