PANEL INDICATOR LEDs - Ø 6.35mm Mounting
•
Low profile styling
lens options
fresnel lens to optimise
viewing characteristics
•
Smoked & water clear
•
Flying lead terminations
& AC versions available
•
•
Supplied complete with
Sealed to IP40
mounting hardware
Dimensions in mm (Typical)
Scale 1:1
Anode termination indicated by long tag.
315
SERIES
MLQ = 20
Ordering Information & Typical Technical Characteristics (Ta = 25°C)
LEDs
Mean Time Between Failure = 90,000 Hours. Luminous intensity figures refer to the unmodified discrete LED.
PART NUMBER
COLOUR
LENS
VOLTAGE
DC
Vopr
CURRENT
DC
lopr
LUMINOUS
INTENSITY
lv@20mA
WAVE
LENGTH
λp
VIEWING
ANGLE
OPERATING
TEMP
Topr
STORAGE
TEMP
Tstg
STANDARD INTENSITY
STANDARD INTENSITY
315-505-04
315-506-04
315-511-04
315-512-04
315-505-22
315-506-22
315-511-22
315-512-22
Red
Orange
Yellow
Green
Red
Orange
Yellow
Green
Coloured Diffused
2.0*
2.0*
2.1*
2.2*
24
24
24
24
20
20
20
20
20
20
20
20
15
90@10mA
20
50
15
90@10mA
20
50
625
610
590
565
625
610
590
565
Wide
0~+85
0~+85
HIGH INTENSITY
315-501-04
315-521-04
315-532-04
315-930-04
315-997-04
315-501-22
315-521-22
315-532-22
315-930-22
315-997-22
UNITS
Red
Yellow
Green
Blue
White
Red
Yellow
Green
Blue
White
Coloured Diffused
1.9*
2.0*
3.4*
3.4*
3.4*
24
24
24
24
24
Vdc
20
20
20
20
20
20
20
20
20
20
mA
2750
4500
6000
2000
3000
2750
4500
6000
2000
3000
mcd
660
590
525
470
•
660
590
525
470
*
nm
°C
°C
Wide
0~+85
0~+85
* = Voltage DC for 20mA product is Vf@20mA, not Vopr
• = Typical emission colour: x=0.31, y=0.32. Colour temperature 8000K. Intensities (Iv) and colour shades of white (x,y co-ordinates) may vary between LEDs within a batch.
Please note - This product is also available at 5, 12 and 28Vdc. Please contact our Sales department for further details.
ISO 9001: 1994 APPROVED
Telephone
+44 (0)1229 582430 •
Fax: +44 (0)1229 585155
•
email: sales@marl.co.uk
•
website: www.marl.co.uk
•
website: www.marl-leds.com
