Datasheet> All Categories > Programmable logic devices> Programmable logic> 5962-89841033X
PDF
Preview

5962-89841033X

Description
Flash PLD, 15ns, CMOS, CQCC28, CERAMIC, LCC-28
CategoryProgrammable logic devices    Programmable logic
File Size536KB，15 Pages
Manufacturere2v technologies
Download Datasheet Parametric Compare View All

5962-89841033X Overview

Flash PLD, 15ns, CMOS, CQCC28, CERAMIC, LCC-28

5962-89841033X Parametric

Parameter NameAttribute value
Is it lead-free?Contains lead
Is it Rohs certified?incompatible
Parts packaging codeQLCC
package instructionQCCN,
Contacts28
Reach Compliance Codecompliant
ECCN code3A001.A.2.C
maximum clock frequency55.5 MHz
JESD-30 codeS-CQCC-N28
JESD-609 codee0
length11.45 mm
Dedicated input times11
Number of I/O lines10
Number of terminals28
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
organize11 DEDICATED INPUTS, 10 I/O
Output functionMACROCELL
Package body materialCERAMIC, METAL-SEALED COFIRED
encapsulated codeQCCN
Package shapeSQUARE
Package formCHIP CARRIER
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Programmable logic typeFLASH PLD
propagation delay15 ns
Certification statusQualified
Filter levelMIL-STD-883
Maximum seat height2.54 mm
Maximum supply voltage5.5 V
Minimum supply voltage4.5 V
Nominal supply voltage5 V
surface mountYES
technologyCMOS
Temperature levelMILITARY
Terminal surfaceTIN LEAD
Terminal formNO LEAD
Terminal pitch1.27 mm
Terminal locationQUAD
Maximum time at peak reflow temperatureNOT SPECIFIED
width11.45 mm
Base Number Matches1

Preview

Download Datasheet
Features
•
Industry Standard Architecture
– Low-cost Easy-to-use Software Tools
•
High-speed, Electrically-erasable Programmable Logic Devices
– 7.5 ns Maximum Pin-to-pin Delay
•
Several Power Saving Options
Device
ATF22V10B
ATF22V10BQ
(1)
ATF22V10BQL
Notes:
(2)
I
CC
, Standby
85 mA
35 mA
5 mA
I
CC
, Active
90 mA
40 mA
20 mA
1. The shaded devices are obsolete. Suggested replacement: ATF22V10CQ
2. The shaded devices are obsolete. Suggested replacement: ATF22V10CQZ
High-
performance
EE PLD
ATF22V10B
•
CMOS and TTL Compatible Inputs and Outputs
•
•
– Input and I/O Pull-up Resistors
Advanced Flash Technology
– Reprogrammable
– 100% Tested
High-reliability CMOS Process
– 20-year Data Retention
– 100 Erase/Write Cycles
– 2,000V ESD Protection
– 200 mA Latchup Immunity
Full Military, Commercial, and Industrial Temperature Ranges
Dual-in-line and Surface Mount Packages in Standard Pinouts
PCI Compliant
•
•
•
Logic Diagram
TSSOP
CLK/IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
GND
1
2
3
4
5
6
7
8
9
10
11
12
24
23
22
21
20
19
18
17
16
15
14
13
VCC
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
IN
Pin Configurations
All Pinouts Top View
Pin Name
CLK
Function
Clock
IN
I/O
*
V
CC
Logic Inputs
Bidirectional Buffers
No Internal Connection
+5V Supply
CLK/IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
IN
GND
DIP/SOIC
1
2
3
4
5
6
7
8
9
10
11
12
24
23
22
21
20
19
18
17
16
15
14
13
VCC
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
I/O
IN
LCC/PLCC
IN
IN
CLK/IN
*
VCC
I/O
I/O
4
3
2
1
28
27
26
IN
IN
IN
*
IN
IN
IN
5
6
7
8
9
10
11
25
24
23
22
21
20
19
I/O
I/O
I/O
*
I/O
I/O
I/O
IN
IN
GND
*
IN
I/O
I/O
12
13
14
15
16
17
18
Rev. 0250L–PLD–06/03
1

5962-89841033X Related Products

5962-89841033X 5962-8984106LA 5962-8984103LA 5962-89841063X
Description Flash PLD, 15ns, CMOS, CQCC28, CERAMIC, LCC-28 Flash PLD, 10ns, PAL-Type, CMOS, CDIP24, CERAMIC, DIP-24 Flash PLD, 15ns, PAL-Type, CMOS, CDIP24, CERAMIC, DIP-24 Flash PLD, 10ns, CMOS, CQCC28, CERAMIC, LCC-28
Is it lead-free? Contains lead Contains lead Contains lead Contains lead
Is it Rohs certified? incompatible incompatible incompatible incompatible
Parts packaging code QLCC DIP DIP QLCC
package instruction QCCN, DIP, DIP24,.3 DIP, DIP24,.3 QCCN,
Contacts 28 24 24 28
Reach Compliance Code compliant compli compliant compliant
ECCN code 3A001.A.2.C 3A001.A.2.C 3A001.A.2.C 3A001.A.2.C
maximum clock frequency 55.5 MHz 76.9 MHz 50 MHz 90 MHz
JESD-30 code S-CQCC-N28 R-CDIP-T24 R-CDIP-T24 S-CQCC-N28
JESD-609 code e0 e0 e0 e0
length 11.45 mm 32 mm 32 mm 11.45 mm
Dedicated input times 11 11 11 11
Number of I/O lines 10 10 10 10
Number of terminals 28 24 24 28
Maximum operating temperature 125 °C 125 °C 125 °C 125 °C
Minimum operating temperature -55 °C -55 °C -55 °C -55 °C
organize 11 DEDICATED INPUTS, 10 I/O 11 DEDICATED INPUTS, 10 I/O 11 DEDICATED INPUTS, 10 I/O 11 DEDICATED INPUTS, 10 I/O
Output function MACROCELL MACROCELL MACROCELL MACROCELL
Package body material CERAMIC, METAL-SEALED COFIRED CERAMIC, METAL-SEALED COFIRED CERAMIC, METAL-SEALED COFIRED CERAMIC, METAL-SEALED COFIRED
encapsulated code QCCN DIP DIP QCCN
Package shape SQUARE RECTANGULAR RECTANGULAR SQUARE
Package form CHIP CARRIER IN-LINE IN-LINE CHIP CARRIER
Peak Reflow Temperature (Celsius) NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED
Programmable logic type FLASH PLD FLASH PLD FLASH PLD FLASH PLD
propagation delay 15 ns 10 ns 15 ns 10 ns
Certification status Qualified Qualified Qualified Qualified
Filter level MIL-STD-883 MIL-STD-883 MIL-STD-883 MIL-STD-883
Maximum seat height 2.54 mm 5.08 mm 5.08 mm 2.54 mm
Maximum supply voltage 5.5 V 5.5 V 5.5 V 5.5 V
Minimum supply voltage 4.5 V 4.5 V 4.5 V 4.5 V
Nominal supply voltage 5 V 5 V 5 V 5 V
surface mount YES NO NO YES
technology CMOS CMOS CMOS CMOS
Temperature level MILITARY MILITARY MILITARY MILITARY
Terminal surface TIN LEAD TIN LEAD TIN LEAD TIN LEAD
Terminal form NO LEAD THROUGH-HOLE THROUGH-HOLE NO LEAD
Terminal pitch 1.27 mm 2.54 mm 2.54 mm 1.27 mm
Terminal location QUAD DUAL DUAL QUAD
Maximum time at peak reflow temperature NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED
width 11.45 mm 7.62 mm 7.62 mm 11.45 mm
Base Number Matches 1 1 1 1
