MAW
-SERIES
Features
(1) For equipment designed to conform EMI regulations
such as VCCI, CISPR, FCC, VDE, etc.
(2) Attenuation effect against high voltage pulse noise
(3) Attenuates conductive emission from power supply
(4) Leakage current: 1mA max. (250V, 60Hz)
(5) High shielded effect (covered by metal case)
Safety standard
MAW-1203-22
MAW-1205-22
UL1283 applied/approval in process
CSA Std. C22.2 No. 8 applied/approval in process
EN133200 applied/approval in process
MAW-12R5-22
MAW-1201-22
MAW-1202-22
Specifications
Item
1 Rated voltage (AC, DC)
2
3
4
5
6
7
8
9
Rated current (AC, DC)
Test voltage (terminal to case, AC 1 minute)
Isolation resistance (terminal to case, 500 VDC)
Leakage current
DC resistance
Temperature rise
Operating temperature
Operating humidity
125V, 60Hz
250V, 60Hz
5Ω max.
1.5Ω max.
Model
MAW-12R5-22
MAW-1201-22
MAW-1202-22
250V
0.5A
1A
2A
2500V
100MΩ min.
0.5mA max.
1mA max.
0.6Ω max.
30°C max.
–25 ~ +85°C
30% ~ 95% (No dewdrop)
–40 ~ +85°C
95g
95g
10% ~ 95% (No dewdrop)
95g
(Note) : Value at Ta
MAW-1203-22
MAW-1205-22
3A
5A
0.3Ω max.
0.2Ω max.
10 Storage temperature
11 Storage humidity
12 Weight
CASE
1
3
2
4
Output current (%)
Noise Filter
160g
160g
*Request supply specification sheets for further details of specs, outline drawing,
characteristics, etc.
Please read instruction manual before use.
*Contact us about the delivery time before ordering.
55°C. Refer to the derating curve shown below at Ta > 55°C.
Circuit
Derating
R: Breeder resistance
Temperature (°C)
