MAC320-10FP

Description
ISOLATED TRIACs THYRISTORS 20 AMPERES RMS 200 thru 800 VOLTS
CategoryAnalog mixed-signal IC    Trigger device
File Size75KB,6 Pages
ManufacturerMotorola ( NXP )
Websitehttps://www.nxp.com
Download Datasheet Parametric Compare View All

MAC320-10FP Overview

ISOLATED TRIACs THYRISTORS 20 AMPERES RMS 200 thru 800 VOLTS

MAC320-10FP Parametric

Parameter NameAttribute value
Is it Rohs certified?incompatible
MakerMotorola ( NXP )
package instructionFLANGE MOUNT, R-PSFM-T3
Reach Compliance Codeunknow
Shell connectionISOLATED
ConfigurationSINGLE
Maximum DC gate trigger current50 mA
Maximum DC gate trigger voltage2 V
Maximum holding current40 mA
JESD-30 codeR-PSFM-T3
JESD-609 codee0
Maximum leakage current2 mA
Number of components1
Number of terminals3
Maximum operating temperature125 °C
Minimum operating temperature-40 °C
Package body materialPLASTIC/EPOXY
Package shapeRECTANGULAR
Package formFLANGE MOUNT
Peak Reflow Temperature (Celsius)NOT SPECIFIED
Certification statusNot Qualified
Maximum rms on-state current20 A
Maximum repetitive peak off-state leakage current10 µA
Off-state repetitive peak voltage800 V
surface mountNO
Terminal surfaceTin/Lead (Sn/Pb)
Terminal formTHROUGH-HOLE
Terminal locationSINGLE
Maximum time at peak reflow temperatureNOT SPECIFIED
Trigger device typeTRIAC
MOTOROLA
SEMICONDUCTOR TECHNICAL DATA
Order this document
by MAC320FP/D
Triacs
Silicon Bidirectional Thyristors
. . . designed primarily for full-wave ac control applications, such as solid-state relays,
motor controls, heating controls and power supplies; or wherever full-wave silicon
gate controlled solid-state devices are needed. Triac type thyristors switch from a
blocking to a conducting state for either polarity of applied anode voltage with positive
or negative gate triggering.
Blocking Voltage to 800 Volts
All Diffused and Glass Passivated Junctions for Greater Parameter Uniformity
and Stability
Small, Rugged, Thermowatt Construction for Low Thermal Resistance, High Heat
Dissipation and Durability
Gate Triggering Guaranteed in Three Modes (MAC320FP Series) or
Four Modes (MAC320AFP Series)
MAC320FP
Series
MAC320AFP
Series
ISOLATED TRIACs
THYRISTORS
20 AMPERES RMS
200 thru 800 VOLTS
MT2
G
MT1
CASE 221C-02
STYLE 3
MAXIMUM RATINGS
(TC = 25°C unless otherwise noted.)
Rating
Peak Repetitive Off-State Voltage(1) (TJ = –40 to +125°C,
1/2 Sine Wave 50 to 60 Hz, Gate Open)
MAC320-4FP, MAC320A4FP
MAC320-6FP, MAC320A6FP
MAC320-8FP, MAC320A8FP
MAC320-10FP, MAC320A10FP
Peak Gate Voltage
On-State RMS Current (TC = +75°C, Full Cycle Sine Wave 50 to 60 Hz)(2)
Peak Nonrepetitive Surge Current (One Full Cycle, 60 Hz, T C = +75°C,
preceded and followed by rated current)
Peak Gate Power (T C = +75°C, Pulse Width = 2
µs)
Average Gate Power (T C = +75°C, t = 8.3 ms)
Peak Gate Current
RMS Isolation Voltage (TA = 25°C, Relative Humidity
Operating Junction Temperature
Storage Temperature Range
Symbol
VDRM
200
400
600
800
VGM
IT(RMS)
ITSM
PGM
PG(AV)
10
20
150
20
0.5
2
1500
–40 to +125
–40 to +150
Volts
Amps
Amps
Watts
Watt
Amps
Volts
°C
°C
Value
Unit
Volts
p
20%)
IGM
V(ISO)
TJ
Tstg
THERMAL CHARACTERISTICS
Characteristic
Thermal Resistance, Junction to Case
Thermal Resistance, Case to Sink
Thermal Resistance, Junction to Ambient
Symbol
R
θJC
R
θCS
R
θJA
Max
1.8
2.2 (typ)
60
Unit
°C/W
°C/W
°C/W
1. VDRM for all types can be applied on a continuous basis. Blocking voltages shall not be tested with a constant current source such that the
voltage ratings of the devices are exceeded.
2. The case temperature reference point for all TC measurements is a point on the center lead of the package as close as possible to the
plastic body.
Motorola Thyristor Device Data
©
Motorola, Inc. 1995
1

MAC320-10FP Related Products

MAC320-10FP MAC320A4FP MAC320-6FP MAC320-4FP
Description ISOLATED TRIACs THYRISTORS 20 AMPERES RMS 200 thru 800 VOLTS ISOLATED TRIACs THYRISTORS 20 AMPERES RMS 200 thru 800 VOLTS ISOLATED TRIACs THYRISTORS 20 AMPERES RMS 200 thru 800 VOLTS ISOLATED TRIACs THYRISTORS 20 AMPERES RMS 200 thru 800 VOLTS
Is it Rohs certified? incompatible incompatible incompatible incompatible
Maker Motorola ( NXP ) Motorola ( NXP ) Motorola ( NXP ) Motorola ( NXP )
package instruction FLANGE MOUNT, R-PSFM-T3 FLANGE MOUNT, R-PSFM-T3 FLANGE MOUNT, R-PSFM-T3 FLANGE MOUNT, R-PSFM-T3
Reach Compliance Code unknow unknow unknow unknow
Shell connection ISOLATED ISOLATED ISOLATED ISOLATED
Configuration SINGLE SINGLE SINGLE SINGLE
Maximum DC gate trigger current 50 mA 50 mA 50 mA 50 mA
Maximum DC gate trigger voltage 2 V 2 V 2 V 2 V
Maximum holding current 40 mA 40 mA 40 mA 40 mA
JESD-30 code R-PSFM-T3 R-PSFM-T3 R-PSFM-T3 R-PSFM-T3
JESD-609 code e0 e0 e0 e0
Maximum leakage current 2 mA 2 mA 2 mA 2 mA
Number of components 1 1 1 1
Number of terminals 3 3 3 3
Maximum operating temperature 125 °C 125 °C 125 °C 125 °C
Minimum operating temperature -40 °C -40 °C -40 °C -40 °C
Package body material PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY PLASTIC/EPOXY
Package shape RECTANGULAR RECTANGULAR RECTANGULAR RECTANGULAR
Package form FLANGE MOUNT FLANGE MOUNT FLANGE MOUNT FLANGE MOUNT
Peak Reflow Temperature (Celsius) NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED
Certification status Not Qualified Not Qualified Not Qualified Not Qualified
Maximum rms on-state current 20 A 20 A 20 A 20 A
Maximum repetitive peak off-state leakage current 10 µA 10 µA 10 µA 10 µA
Off-state repetitive peak voltage 800 V 200 V 400 V 200 V
surface mount NO NO NO NO
Terminal surface Tin/Lead (Sn/Pb) Tin/Lead (Sn/Pb) Tin/Lead (Sn/Pb) Tin/Lead (Sn/Pb)
Terminal form THROUGH-HOLE THROUGH-HOLE THROUGH-HOLE THROUGH-HOLE
Terminal location SINGLE SINGLE SINGLE SINGLE
Maximum time at peak reflow temperature NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED NOT SPECIFIED
Trigger device type TRIAC TRIAC TRIAC TRIAC
