DS2102SV20 Overview

Rectifier Diode, 1 Phase, 1 Element, 6654A, 2000V V(RRM), Silicon, V, 2 PIN

DS2102SV20 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	Dynex
package instruction	O-CEDB-N2
Contacts	2
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	FREE WHEELING DIODE
application	GENERAL PURPOSE
Configuration	SINGLE
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
JESD-30 code	O-CEDB-N2
Maximum non-repetitive peak forward current	100000 A
Number of components	1
Phase	1
Number of terminals	2
Maximum output current	6654 A
Package body material	CERAMIC, METAL-SEALED COFIRED
Package shape	ROUND
Package form	DISK BUTTON
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	2000 V
surface mount	YES
Terminal form	NO LEAD
Terminal location	END
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

DS2102SY/DS2102SV

Rectifier Diode

Replaces December 2001 version, DS4171-5.1

DS4171-6.0 February 2003

FEATURES

Double Side Cooling

High Surge Capability

KEY PARAMETERS

RRM

2000V

F(AV)

6654A

FSM

100000A

APPLICATIONS

Rectification

Freewheel Diode

DC Motor Control

Power Supplies

Welding

Battery Chargers

VOLTAGE RATINGS

Type Number

Repetitive Peak

Reverse Voltage

RRM

Conditions

DS2102SY20

2000

DS2102SY19

1900

DS2102SY18

1800

DS2102SY17

1700

DS2102SY16

1600

DS2102SY15

1500

Lower voltage grades available.

RSM

= V

RRM

+ 100V

Outline type code: Y

Outline type code: V

See Package Details for further information.

Fig. 1 Package outlines

ORDERING INFORMATION

When ordering, select the required part number shown in the

Voltage Ratings selection table, e.g.:

DS2102SY18

for a 1800V device in a Y outline

DS2102SV37

for a 1800V device in a V outline

Note: Please use the complete part number when ordering

and quote this number in any future correspondance relating

to your order.

1/8

www.dynexsemi.com

DS2102SV20 Related Products

	DS2102SV20	DS2102SV15	DS2102SV16	DS2102SV19	DS2102SV18	DS2102SV17
Description	Rectifier Diode, 1 Phase, 1 Element, 6654A, 2000V V(RRM), Silicon, V, 2 PIN	Rectifier Diode, 1 Phase, 1 Element, 6654A, 1500V V(RRM), Silicon, V, 2 PIN	Rectifier Diode, 1 Phase, 1 Element, 6654A, 1600V V(RRM), Silicon, V, 2 PIN	Rectifier Diode, 1 Phase, 1 Element, 6654A, 1900V V(RRM), Silicon, V, 2 PIN	Rectifier Diode, 1 Phase, 1 Element, 6654A, 1800V V(RRM), Silicon, V, 2 PIN	Rectifier Diode, 1 Phase, 1 Element, 6654A, 1700V V(RRM), Silicon, V, 2 PIN
Is it lead-free?	Lead free	Lead free	Lead free	Lead free	Lead free	Lead free
Is it Rohs certified?	conform to	conform to	conform to	conform to	conform to	conform to
package instruction	O-CEDB-N2	O-CEDB-N2	O-CEDB-N2	O-CEDB-N2	O-CEDB-N2	O-CEDB-N2
Contacts	2	2	2	2	2	2
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown
ECCN code	EAR99	EAR99	EAR99	EAR99	EAR99	EAR99
Other features	FREE WHEELING DIODE	FREE WHEELING DIODE	FREE WHEELING DIODE	FREE WHEELING DIODE	FREE WHEELING DIODE	FREE WHEELING DIODE
application	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE	GENERAL PURPOSE
Configuration	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE	SINGLE
Diode component materials	SILICON	SILICON	SILICON	SILICON	SILICON	SILICON
Diode type	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE	RECTIFIER DIODE
JESD-30 code	O-CEDB-N2	O-CEDB-N2	O-CEDB-N2	O-CEDB-N2	O-CEDB-N2	O-CEDB-N2
Maximum non-repetitive peak forward current	100000 A	100000 A	100000 A	100000 A	100000 A	100000 A
Number of components	1	1	1	1	1	1
Phase	1	1	1	1	1	1
Number of terminals	2	2	2	2	2	2
Maximum output current	6654 A	6654 A	6654 A	6654 A	6654 A	6654 A
Package body material	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED	CERAMIC, METAL-SEALED COFIRED
Package shape	ROUND	ROUND	ROUND	ROUND	ROUND	ROUND
Package form	DISK BUTTON	DISK BUTTON	DISK BUTTON	DISK BUTTON	DISK BUTTON	DISK BUTTON
Peak Reflow Temperature (Celsius)	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
Maximum repetitive peak reverse voltage	2000 V	1500 V	1600 V	1900 V	1800 V	1700 V
surface mount	YES	YES	YES	YES	YES	YES
Terminal form	NO LEAD	NO LEAD	NO LEAD	NO LEAD	NO LEAD	NO LEAD
Terminal location	END	END	END	END	END	END
Maximum time at peak reflow temperature	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED	NOT SPECIFIED
Maker	Dynex	-	Dynex	-	Dynex	Dynex
Base Number Matches	1	1	1	1	-	-
