MK51N256CLQ100: Description32-BIT, FLASH, 100MHz, RISC MICROCONTROLLER, PQFP144, 20 X 20 MM, LQFP-144; CategoryThe embedded processor and controller Microcontrollers and processors; File Size2MB，74 Pages; ManufacturerNXP; Websitehttps://www.nxp.com

Download Datasheet Parametric Compare View All

MK51N256CLQ100 Overview

32-BIT, FLASH, 100MHz, RISC MICROCONTROLLER, PQFP144, 20 X 20 MM, LQFP-144

MK51N256CLQ100 Parametric

Parameter Name	Attribute value
Parts packaging code	QFP
package instruction	LFQFP, QFP144,.87SQ,20
Contacts	144
Reach Compliance Code	unknow
ECCN code	3A001.A.3
Has ADC	YES
Address bus width
bit size	32
CPU series	CORTEX-M4
maximum clock frequency	50 MHz
DAC channel	YES
DMA channel	YES
External data bus width
JESD-30 code	S-PQFP-G144
length	20 mm
Number of I/O lines	94
Number of terminals	144
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
PWM channel	YES
Package body material	PLASTIC/EPOXY
encapsulated code	LFQFP
Encapsulate equivalent code	QFP144,.87SQ,20
Package shape	SQUARE
Package form	FLATPACK, LOW PROFILE, FINE PITCH
power supply	1.8/3.3 V
Certification status	Not Qualified
RAM (bytes)	131072
rom(word)	262144
ROM programmability	FLASH
Maximum seat height	1.6 mm
speed	100 MHz
Maximum supply voltage	3.6 V
Minimum supply voltage	1.71 V
Nominal supply voltage	3.3 V
surface mount	YES
technology	CMOS
Temperature level	INDUSTRIAL
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	QUAD
width	20 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER, RISC
Base Number Matches	1

Preview

Download Datasheet

View All

Freescale Semiconductor

Data Sheet: Product Preview

Document Number: K51P144M100SF2

Rev. 4, 3/2011

Supports the following:

MK51N256CLQ100,

MK51N256CMD100,

MK51N512CLQ100,

MK51N512CMD100

K51 Sub-Family Data Sheet

K51P144M100SF2

Features

• Operating Characteristics

– Voltage range: 1.71 to 3.6 V

– Flash write voltage range: 1.71 to 3.6 V

– Temperature range (ambient): -40 to 85°C

• Performance

– Up to 100 MHz ARM Cortex-M4 core with DSP

instructions delivering 1.25 Dhrystone MIPS per

MHz

• Memories and memory interfaces

– Up to 512 KB program flash memory on non-

FlexMemory devices

– Up to 128 KB RAM

– Serial programming interface (EzPort)

– FlexBus external bus interface

• Clocks

– 3 to 32 MHz crystal oscillator

– 32 kHz crystal oscillator

– Multi-purpose clock generator

• System peripherals

– 10 low-power modes to provide power optimization

based on application requirements

– Memory protection unit with multi-master

protection

– 16-channel DMA controller, supporting up to 64

request sources

– External watchdog monitor

– Software watchdog

– Low-leakage wakeup unit

• Security and integrity modules

– Hardware CRC module to support fast cyclic

redundancy checks

– 128-bit unique identification (ID) number per chip

• Human-machine interface

– Segment LCD controller supporting up to 40

frontplanes and 8 backplanes, or 44 frontplanes and

4 backplanes

– Low-power hardware touch sensor interface (TSI)

– General-purpose input/output

• Analog modules

– Two 16-bit SAR ADCs

– Programmable gain amplifier (up to x64) integrated

into each ADC

– Two 12-bit DACs

– Two operational amplifiers

– Two transimpedance amplifiers

– Three analog comparators (CMP) containing a 6-bit

DAC and programmable reference input

– Voltage reference

• Timers

– Programmable delay block

– Eight-channel motor control/general purpose/PWM

timer

– Two 2-channel quadrature decoder/general purpose

timers

– Periodic interrupt timers

– 16-bit low-power timer

– Carrier modulator transmitter

– Real-time clock

• Communication interfaces

– USB full-/low-speed On-the-Go controller with on-

chip transceiver

– Three SPI modules

– Two I2C modules

– Six UART modules

– Secure Digital host controller (SDHC)

– I2S module
