5681F Series T-1 2 High Right Angle Assembly
Description and Features
Features
• 2 T-1 LEDs mounted in single block.
• Less PC board space needed, height and spacing
alignment saves assembly cost.
• High Brite and Super Brite LEDs, diffused lens .
• S tandoffs prevent flux entrapment.
• Black Nylon plastic block UL94V-O
Alternate LEDs are also available in this package
as a standard variation.
Electro-Optical Characteristics and Ratings
P art Number
5681F 1;1
5681F 3;3
5681F 5;5
5681F 7;7
E mitted
C olor
R ed/R ed
Amber/Amber
G reen/G reen
Y ellow/Y ellow
T ypical
Intensity
(mcd)
10.0
7
16
6.3
R ated
C urrent
(mA)
10
10
10
10
C ontinuous
F orward
C urrent Max.
(mA)
F orward V oltage
T yp.
(V )
2.0
2.0
2.2
2.1
Max.
(V )
3.0
3.0
3.0
3.0
R everse
B reakdown
V oltage Min.(V )
5.0
5.0
5.0
5.0
P eak
Wavelength
(nm)
650
603
562
585
30
30
30
30
The model numbers listed above are standard off the shelf parts, for the user who may have a requirement calling for
various color/electrical specifications, a part number can be determined by referring to the chart shown below.
Model No. is as follows : 5681F
LE D
C ode
1LC
5LC
7LC
1-5V
3-5V
5-5V
1
3
5
7
T ypical
Intensity
(mcd)
2.5
2.1
1.8
8.0
8.0
8.0
10
7
16
6.3
LE D 1
LE D 2
LE D C olor
R ed
G reen
Y ellow
R ed
Amber
G reen
R ed
Amber
G reen
Y ellow
R ated
C urrent
(mA)
2.0
2.0
2.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
F orward
C urrent Max.
(mA)
F orward V oltage
T yp.
(V )
2.2
1.8
1.9
5.0
5.0
5.0
2.0
2.0
2.2
2.1
Max.
(V )
2.2
2.2
2.7
7.5
7.5
7.5
3.0
3.0
3.0
3.0
7
7
7
20
15
15
30
30
30
30
R everse
B reakdown
V oltage Min.
(V )
P eak
Wavelength
(nm)
650
565
583
655
583
565
635
603
562
583
5
5
5
5
5
5
5
5
5
5
