The AD586 represents a major advance in the state-of-the-art in
monolithic voltage references. Using a proprietary ion-implanted
buried Zener diode and laser wafer trimming of high stability
thin-film resistors, the AD586 provides outstanding perfor-
mance at low cost.
The AD586 offers much higher performance than most other
5 V references. Because the AD586 uses an industry standard
pinout, many systems can be upgraded instantly with the
AD586. The buried Zener approach to reference design pro-
vides lower noise and drift than bandgap voltage references. The
AD586 offers a noise reduction pin which can be used to further
reduce the noise level generated by the buried Zener.
The AD586 is recommended for use as a reference for 8-, 10-,
12-, 14- or 16-bit D/A converters which require an external
precision reference. The device is also ideal for successive
approximation or integrating A/D converters with up to 14 bits
of accuracy and, in general, can offer better performance than
the standard on-chip references.
The AD586J, K, L and M are specified for operation from 0°C
to +70°C, the AD586A and B are specified for –40°C to +85°C
operation, and the AD586S and T are specified for –55°C to
+125°C operation. The AD586J, K, L and M are available in an
8-pin plastic DIP. The AD586J, K, L, A and B are available in
an 8-pin plastic surface mount small outline (SO) package. The
AD586J, K, L, S and T are available in an 8-pin cerdip package.
1. Laser trimming of both initial accuracy and temperature
coefficients results in very low errors over temperature with-
out the use of external components. The AD586M has a
maximum deviation from 5.000 V of
±
2.45 mV between
0°C and +70°C, and the AD586T guarantees
±
7.5 mV
maximum total error between –55°C and +125°C.
2. For applications requiring higher precision, an optional fine-
trim connection is provided.
3. Any system using an industry standard pinout reference can
be upgraded instantly with the AD586.
4. Output noise of the AD586 is very low, typically 4
µV
p-p. A
noise reduction pin is provided for additional noise filtering
using an external capacitor.
5. The AD586 is available in versions compliant with MIL-
STD-883. Refer to the Analog Devices Military Products
Databook or current AD586/883B data sheet for detailed
specifications.
REV. C
Information furnished by Analog Devices is believed to be accurate and
reliable. However, no responsibility is assumed by Analog Devices for its
use, nor for any infringements of patents or other rights of third parties
which may result from its use. No license is granted by implication or
otherwise under any patent or patent rights of Analog Devices.
One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106, U.S.A.
Tel: 617/329-4700
Fax: 617/326-8703
AD586–SPECIFICATIONS
(@ T = + 25°C, V
A
IN
= +15 V unless otherwise noted)
AD586M
AD586S
Min Typ Max Min Typ Max
5.002 4.990
AD586T
Min Typ Max
Model
Output Voltage
Output Voltage Drift
l
0°C to +70°C
–55°C to +125°C
Gain Adjustment
Line Regulation
1
10.8 V < +V
IN
< 36 V
T
MIN
to T
MAX
11.4 V < +V
IN
< 36 V
T
MIN
to T
MAX
Load Regulation
l
Sourcing 0 < I
OUT
< 10 mA
25°C
T
MIN
to T
MAX
Sinking –10 < I
OUT
< 0 mA
25°C
Quiescent Current
Power Consumption
Output Noise
0.1 Hz to 10 Hz
Spectral Density, 100 Hz
Long-Term Stability
Short-Circuit Current-to-Ground
Temperature Range
Specified Performance
2
Operating Performance
3
AD586J
AD586K/A
Min Typ Max Min Typ Max
4.980
5.020 4.995
AD586L/B
Min Typ Max
Units
5.005 4.9975
5.0025 4.998
5.010 4.9975
5.0025
V
25
15
5
2
20
10
+6
–2
ppm/°C
+6
–2
+6
–2
+6
–2
+6
–2
+6
–2
%
100
100
100
100
150
150
±µV/V
100
100
400
2
30
3
2
30
100
100
400
3
2
30
100
100
400
3
2
30
100
100
400
3
2
30
150
150
400
3
2
30
150
150
400
3
µV/mA
mA
mW
µV
p-p
nV/√Hz
ppm/1000 Hr
mA
°C
4
100
15
45
60
4
100
15
45
60
4
100
15
45
60
4
100
15
45
60
4
100
15
45
60
4
100
15
45
60
0
–40
+70
+85
0
–40
–40
+70
+85
+85
0
–40
–40
+70
+85
+85
0
–40
+70
+85
–55
–55
+125 –55
+125 –55
+125
+125
NOTES
1
Maximum output voltage drift is guaranteed for all packages and grades. Cerdip packaged parts are also 100°C production tested.
2
Lower row shows specified performance for A and B grades.
3
The operating temperature range is defined as the temperatures extremes at which the device will still function. Parts may deviate from their specified performance outside their
specified temperature range.
Specifications subject to change without notice.
Specifications in boldface are rested on all production units at final electrical test. Results from those tests are used to calculate outgoing quality levels. All min and max specifica-
tions are guaranteed, although only those shown in boldface are tested on all production units unless otherwise specified.
