54F365LMQB

Description
F/FAST SERIES, 6-BIT DRIVER, TRUE OUTPUT, CQCC20, CERAMIC, LCC-20
Categorylogic    logic
File Size844KB,5 Pages
ManufacturerRochester Electronics
Websitehttps://www.rocelec.com/
Download Datasheet Parametric Compare View All

54F365LMQB Overview

F/FAST SERIES, 6-BIT DRIVER, TRUE OUTPUT, CQCC20, CERAMIC, LCC-20

54F365LMQB Parametric

Parameter NameAttribute value
Parts packaging codeQLCC
package instructionQCCN,
Contacts20
Reach Compliance Codeunknown
Other featuresWITH DUAL OUTPUT ENABLE
seriesF/FAST
JESD-30 codeS-CQCC-N20
length8.89 mm
Logic integrated circuit typeBUS DRIVER
Number of digits6
Number of functions1
Number of ports2
Number of terminals20
Maximum operating temperature125 °C
Minimum operating temperature-55 °C
Output characteristics3-STATE
Output polarityTRUE
Package body materialCERAMIC, METAL-SEALED COFIRED
encapsulated codeQCCN
Package shapeSQUARE
Package formCHIP CARRIER
propagation delay (tpd)7 ns
Certification statusCOMMERCIAL
Maximum seat height1.91 mm
Maximum supply voltage (Vsup)5.5 V
Minimum supply voltage (Vsup)4.5 V
Nominal supply voltage (Vsup)5 V
surface mountYES
technologyTTL
Temperature levelMILITARY
Terminal formNO LEAD
Terminal pitch1.27 mm
Terminal locationQUAD
width8.89 mm
Base Number Matches1
