BLM21B151SBPB datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> filter> BLM21B151SBPB

BLM21B151SBPB: DescriptionFerrite Chip, 1 Function(s), 0.2A, EIA STD PACKAGE SIZE 0805, 2 PIN; CategoryAnalog mixed-signal IC filter; File Size255KB，6 Pages; ManufacturerMurata; Websitehttps://www.murata.com

Download Datasheet Parametric View All

BLM21B151SBPB Overview

Ferrite Chip, 1 Function(s), 0.2A, EIA STD PACKAGE SIZE 0805, 2 PIN

BLM21B151SBPB Parametric

Parameter Name	Attribute value
package instruction	EIA STD PACKAGE SIZE 0805, 2 PIN
Reach Compliance Code	unknown
ECCN code	EAR99
Other features	HIGH SPEED SIGNAL
Maximum DC resistance	0.25 Ω
filter type	FERRITE CHIP
high	0.85 mm
length	2 mm
Manufacturer's serial number	BLM21B
Installation type	SURFACE MOUNT
Number of functions	1
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Output impedance	150 OHM Ω
method of packing	BULK
physical size	L2XB1.25XH0.85 (mm)
Rated current	0.2 A
Base Number Matches	1

Preview

Download Datasheet

View All

SURFACE MOUNT EMI FILTERS

CHIP FERRITE BEADS

BLM

B Series

The BLM

B Series ferrite beads have been developed to

pass signal frequencies from 10MHz to 100MHz while

exhibiting high impedance characteristics to reduce EMI noise

above these specific frequencies.

FEATURES

Designed to reduce noise above operating frequencies

from 10 to 100MHz

High impedance characteristics

Small size

Suitable for flow and reflow soldering

APPLICATIONS

Computers and peripheral equipment

Consumer products

High speed circuits

Suitable for circuits with unstable ground

PART NUMBERING SYSTEM

BLM

152

CHIP FERRITE

SERIES

SIZE

10: 1.0 x 0.5mm

11: 1.6 x 0.8mm

21: 2.0 x 1.25mm

31: 3.2 x 1.6mm

HIGH SPEED SIGNALS

B: High Speed

IMPEDANCE CODE

at 100MHz

601: 600 ohms

152: 1500 ohms

CHARACTERISTICS

PACKAGING CODE

PB: Bulk

PT: Tape 7” Reel

PT1: Tape 13” Reel

SPECIFICATIONS

Dimensions: mm

Part Number

BLM10B750SB

BLM10B121SB

BLM10B221SB

BLM10B421SD

BLM10B601SD

BLM10B102SD

BLM11B050SB

BLM11B050SA

BLM11B100SB

BLM11B100SA

BLM11B220SB

BLM11B220SA

BLM11B470SB

BLM11B470SA

BLM11B600SB

BLM11B750S

BLM11B750SA

BLM11B121SB

BLM11B121SA

BLM11B121SD

BLM11B141S

BLM11B151SB

BLM11B151SD

BLM11B221SB

BLM11B221SD

BLM11B331SB

BLM11B331SD

BLM11B421S

BLM11B471SB

BLM11B471SD

BLM11B601S

Impedance

(Ohms)

Typ. at 100MHz

Rated

Current

(mA)

DCR

(Ohms max.)

Operating

Temperature

Range

0402

0.25 ± 0.1

0.5 ± 0.1

1.0 ± 0.1

0.5 ± 0.1

0603

0.4 ± 0.2

0.8 ± 0.15

1.6 ± 0.15

0.8 ± 0.15

120

220

420

600

1000

120

140

150

220

330

420

470

600

100

700

500

300

200

300

200

0.8

1.1

1.4

1.3

1.5

1.4

0.1

0.20

0.15

0.25

0.35

0.3

0.55

0.35

0.70

0.5

0.90

0.4

0.55

0.4

0.65

0.45

0.75

0.5

0.55

1.0

0.55

0.65

–55 ~ +125°C

Available as standard through authorized Murata Electronics Distributors.

166

CG01-J
