PRELIMINARY
Notice. This is not a final specification.
Some parametric limits are subject to change.
MITSUBISHI ICs (AV COMMON)
M52797SP/FP
AV SWITCH with I2C BUS CONTROL
DESCRIPTION
The M52797 is AV switch semiconductor integrated circuit with
I2C bus control .
This IC contains 1-channel of 4-input audio switches and 1-
channel of 4-input video switches. Each audio switches and
video switches can be controled independently .
The video switches contain amplifiers can be controled a gain of
output 0dB or 6dB .
PIN CONFIGURATION ( TOP VIEW )
FEATURES
•Video and stereo sound switches in one package
•Wide frequency range ( video switch )...........DC~20MHz
•High separation ( video switch )
.........................Crosstalk -60dB ( typ. ) at 1MHz
•Two types of packages are provided : SDIP with a lead pitch of
1.778mm ( M52797SP ) ; and SOP with a lead pitch of 1.27mm
( M52797FP ) .
VCC
VCC
Lch 2 IN
VIDEO 2 IN
Rch 2 IN
Lch 3 IN
VIDEO 3 IN
Rch 3 IN
Lch 4 IN
VIDEO 4 IN
Rch 4 IN
SCL
SDA
NC
1
2
3
4
5
6
7
8
9
10
11
12
13
14
28
27
26
25
24
23
22
21
20
19
18
17
16
15
NC
Lch T IN
TUNER IN
Rch T IN
Lch 1 OUT
V 1 OUT
Rch 1 OUT
BIAS
V 2 OUT
D4
D5
CHIP SELECT
GND
GND
Outline 28P4B
(Lead pitch :1.778mm)
APPLICATION
Video equipment
NC: No connection
PIN CONFIGURATION ( TOP VIEW )
RECOMMENDED OPERATING CONDITION
Supply voltage
Rated supply voltage
Maximum output current
4.7V~9.3V
5V,9V
24mA(at 9V)
VCC
Lch 2 IN
VIDEO 2 IN
Rch 2 IN
Lch 3 IN
VIDEO 3 IN
Rch 3 IN
Lch 4 IN
VIDEO 4 IN
Rch 4 IN
SCL
SDA
1
2
3
4
5
6
7
8
9
10
11
12
24
23
22
21
20
19
18
17
16
15
14
13
Lch T IN
TUNER IN
Rch T IN
Lch 1 OUT
V 1 OUT
Rch 1 OUT
BIAS
V 2 OUT
D4
D5
CHIP SELECT
GND
Outline 24P2N-B
(Lead pitch :1.27mm)
MITSUBISHI
1-9
AUG.'98
PRELIMINARY
Notice. This is not a final specification.
Some parametric limits are subject to change.
MITSUBISHI ICs (AV COMMON)
M52797SP/FP
AV SWITCH with I2C BUS CONTROL
BLOCK DIAGRAM
VCC
TUNER IN
VIDEO 2 IN
VIDEO 3 IN
VIDEO 4 IN
1
26
2
0/6dB
4
7
10
0dB
V-SW
23
V 1 OUT
20
V 2 OUT
Rch T IN
Rch 2 IN
Rch 3 IN
Rch 4 IN
11
25
5
8
R-SW
R-MODE
R
M
L
0dB
22
Rch 1 OUT
Lch T IN
Lch 2 IN
Lch 3 IN
Lch 4 IN
6
9
L-SW
27
3
L-MODE
L
M
R
0dB
24
Lch 1 OUT
BIAS
21
BIAS
14
28
15
GND
16
I C Control
12
19 18
D4
D5
17
CHIP SELECT
SCL
2
13
SDA
NC
(at 28P4B)
MITSUBISHI
2-9
AUG.'98
PRELIMINARY
Notice. This is not a final specification.
Some parametric limits are subject to change.
MITSUBISHI ICs (AV COMMON)
M52797SP/FP
AV SWITCH with I2C BUS CONTROL
DESCRIPTION OF PIN
Pin No.
1
2
3
5
6
8
9
11
25
27
4
7
10
26
Name
Vcc
Lch 2 IN
Rch 2 IN
Lch 3 IN
Rch 3 IN
Lch 4 IN
Rch 4 IN
Rch T IN
Lch T IN
VIDEO 2 IN
VIDEO 3 IN
VIDEO 4 IN
TUNER IN
Peripheral circuit pins
DC voltage(V)
9V
4.7V
Remarks
5
~
9V
30K
3.6V
Clamp in
12
SCL
V
IL
max.=1.5V
V
IH
min.=3.0V
13
SDA
V
IL
max.=1.5V
V
IH
min.=3.0V
V
OL
max.=0.4V
(at Iin=3mA)
15
16
17
GND
CHIP
SELECT
70K
30K
SLAVE
ADDRESS
0
~
1.5V-----90H
2.5V
~
Vcc--92H
OPEN------90H
MITSUBISHI
3- 9
AUG.'98
PRELIMINARY
Notice. This is not a final specification.
Some parametric limits are subject to change.
MITSUBISHI ICs (AV COMMON)
M52797SP/FP
AV SWITCH with I2C BUS CONTROL
DESCRIPTION OF PIN (cont.)
Pin No.
18
19
Name
D5
D4
Peripheral circuit pins
DC voltage(V)
Remarks
V
OL
max.=0.4V
(at Iin=1mA)
20
V 2 OUT
SYNC CHIP
DC=2.2V
23
V 1 OUT
SYNC CHIP
DC=2.9V
5K
5K
21
BIAS
4.2V
30K
22
24
Rch 1 OUT
Lch 1 OUT
4.0V
1.5K
1.5K
15K
MITSUBISHI
4 -9
AUG.'98
PRELIMINARY
Notice. This is not a final specification.
Some parametric limits are subject to change.
MITSUBISHI ICs (AV COMMON)
M52797SP/FP
AV SWITCH with I2C BUS CONTROL
I C BUS
I
2
C BUS(Inter IC BUS)is multi master bus system developed by PHILIPS . Two wires ( SDA - serial data,
SCL - serial clock ) realize functions of start , stop , transferring data , synchronization and arbitration. The
output stages of device connected to the bus must have an open drain or open collector in order to perform the
wired-AND function .
2
SDA
A
MSB
SCL
S
P
A
MSB
LSB
LSB
1
2
3
4
5
6
7
8
9
1
2
9
S ; Start condition, a high to low transition of the SDA line while SCL is high
P ; Stop condition, a low to high transition of the SDA line while SCL is high
A ; Acknownledge
Every byte put on the SDA line must be 8-bits long . Each byte has to be followed by an acknowledge bit. Data
is transferred with the most significant bit (MSB ) first . The data on the SDA line must be stable during the
HIGH period of the clock . The HIGH or LOW state of the data line can only change when the clock signal on
the SCL line is LOW .
CONTROL
This IC controls channel switchs with 1-byte data ( DATA1) .
S
SLAVE ADDRESS A
DATA1
A
P
S : Start
A : Acknowledge
P : Stop
SLAVE ADDRESS
1
0
0
1
0
0
X
0
R/W bit
Usually ` 0 ` ( W : Master transmitter transmits to slave
receiver )
Possible to select
17PIN Hi:1,Lo:0
(at 28P4B)
MITSUBISHI
5 -9
AUG.'98
